aston martin dbs (2013) wiper blade assembly, 12my parts diagram

011601-B1 - Wiper Blade Assembly, 12MY

Aston Martin DBS (2013) Wiper Blade Assembly, 12MY Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
          #
          Part number
          Description
          Key
          Price
          # 1
          MPN: CG43-17526-DA
          ARM ASSY, WIPER, RHS, RHD
          12MY
          from £235.03
          from £235.03
          ARM ASSEMBLY, WIPER, RHS, RHD Genuine Aston Martin - New (to order)
          # 1
          MPN: CG43-17527-CA
          ARM ASSY, WIPER, LHS, LHD
          12MY
          from £393.29
          from £393.29
          ARM ASSEMBLY, WIPER, LHS, LHD Genuine Aston Martin - New (to order)
          # 2
          MPN: CG43-17528-BA
          BLADE ASSY, RHS, RHD
          12MY
          from £49.30
          from £49.30
          BLADE ASSEMBLY, RHS, RHD Genuine Aston Martin - New (to order)
          # 2
          MPN: CG43-17B437-AA
          BLADE ASSY, LHS, LHD
          12MY
          Supersession
          Supersession
          Genuine Aston Martin (no longer available to order)
          # 3
          MPN: CG43-17527-BA
          ARM ASSY WIPER, LHS, RHD
          12MY
          ARM ASSEMBLY WIPER, LHS, RHD Genuine Aston Martin - New (to order)
          # 3
          MPN: CG43-17526-AA
          ARM ASSY WIPER, RHS, LHD
          12MY
          ARM ASSEMBLY WIPER, RHS, LHD Genuine Aston Martin - New (to order)
          # 4
          MPN: CG43-17B437-BA
          BLADE ASSY, LHS, RHD
          12MY
          from £47.18
          from £47.18
          BLADE ASSEMBLY, LHS, RHD Genuine Aston Martin - New (to order)
          # 4
          MPN: CG43-17528-AA
          BLADE ASSY, RHS, LHD
          12MY
          Supersession
          Supersession
          Genuine Aston Martin (no longer available to order)
          # 5
          MPN: 703161
          NUT M8
          from £0.54
          from £0.54
          NUT HEX M8 FL Genuine Aston Martin - New (to order)
          # 6
          MPN: 703160-PK
          NUT, FLG, M10
          from £10.76
          from £10.76
          NUT-M10 HEX FLNG(10) Genuine Aston Martin - New (to order)
          # 7
          MPN: 4G43-17D559-BA
          SEAL, W/S WIPER SPINDLE
          from £3.50
          from £3.50
          SE W/SHLD WPR SPDL Genuine Aston Martin - New (to order)
          # 8
          MPN: 703085
          BOLT, M6 X 12
          from £0.48
          from £0.48
          BOLT M6X12 PC TI8 Genuine Aston Martin - New (to order)
