aston martin cygnet (2012) electronic brake control sensors parts diagram

06.0902.01 - Electronic Brake Control Sensors

Aston Martin Cygnet (2012) Electronic Brake Control Sensors Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
              #
              Part number
              Description
              Key
              Price
              # 1
              MPN: 89183-48030
              SENSOR, YAWRATE
              SENSOR Genuine Aston Martin - New (to order)
              # 2
              MPN: 91673-80616
              BOLT, FLANGE W/WASHER
              from £0.74
              from £0.74
              BOLT Genuine Aston Martin - New (to order)
              # 3
              MPN: 89543-74010
              SENSOR, SPEED, FRONT LH
              SENSOR Genuine Aston Martin - New (to order)
              # 3
              MPN: 89542-74010
              SENSOR, SPEED, FRONT RH
              SENSOR Genuine Aston Martin - New (to order)
              # 4
              MPN: 90119-08868
              BOLT W/WASHER
              1 per side
              from £1.06
              from £1.06
              BOLT Genuine Aston Martin - New (to order)
              # 5
              MPN: 91671-A0616
              BOLT W/PK05
              from £0.74
              from £0.74
              BOLT Genuine Aston Martin - New (to order)
              # 6
              MPN: 90179-06274
              NUT UZJ100
              Front (One Per Side) Rear (LHS)
              from £0.93
              from £0.93
              NUT Genuine Aston Martin - New (to order)
              # 7
              MPN: 90179-06178
              BOLT, REAR RHS
              from £1.29
              from £1.29
              NUT Genuine Aston Martin - New (to order)
              # 8
              MPN: 89516-74010
              WIRE, SKID CONTROL SENSOR, RH
              WIRE Genuine Aston Martin - New (to order)
              # 8
              MPN: 89516-74020
              WIRE, SKID CONTROL SENSOR, LH
              from £30.65
              from £30.65
              WIRE Genuine Aston Martin - New (to order)
