aston martin one-77 (2011) rear stabiliser bar parts diagram

04.0014 - REAR STABILISER BAR

Aston Martin One-77 (2011) Rear Stabiliser Bar Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                        #
                        Part number
                        Description
                        Key
                        Price
                        # 1
                        MPN: 12023-12-1068-AB
                        ANTI ROLL BAR, REAR
                        from £1,260.87
                        from £1,260.87
                        REAR ANTI ROLL BAR Genuine Aston Martin - New (to order)
                        # 3
                        MPN: 3H42-3932-AA
                        WASHER, M12 2.5
                        WASHER Genuine Aston Martin - New (to order)
                        # 5
                        MPN: 4G43-5487-AC
                        STRAP, ANTI ROLL BAR BUSH
                        from £114.86
                        from £114.86
                        CLMP-STAB BAR INS Genuine Aston Martin - New (to order)
                        # 6
                        MPN: 8D33-4A037-AA
                        BUSH, ANTI ROLL BAR
                        from £127.42
                        from £127.42
                        REAR ARB BUSH Genuine Aston Martin - New (to order)
                        # 7
                        MPN: 8D33-5A493-AB
                        SPACER, MOUNTING BRACKET
                        from £106.30
                        from £106.30
                        SPACER, STABILIZER BAR MOUNTING BRACKET Genuine Aston Martin - New (to order)
                        # 8
                        MPN: 12023-12-1070-AB
                        BRACKET, ANTI ROLL BAR
                        from £946.20
                        from £946.20
                        REAR ARB BRACKET Genuine Aston Martin - New (to order)
                        # 9
                        MPN: 703703
                        BOLT, FLANGE HEAD M8 X 16
                        from £0.47
                        from £0.47
                        SCREW, M4 X 12 Genuine Aston Martin - New (to order)
                        # 10
                        MPN: W500034-S442
                        SCREW M10-1.5X30 HEX HD
                        SCREW M10-1.5X30 HEX HD Genuine Aston Martin - New (to order)
                        # 11
                        MPN: 12023-09-6114-AA
                        WASHER M10, FLAT ID10.5XOD20X2.0
                        from £0.77
                        from £0.77
                        M10 FLAT WASHER Genuine Aston Martin - New (to order)
