aston martin rapide (2012) single amplifier, 13my on parts diagram

150103-20 - Single Amplifier, 13MY on

Aston Martin Rapide (2012) Single Amplifier, 13MY on Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
    #
    Part number
    Description
    Key
    Price
    # 1
    MPN: CD33-18C808-AH
    AMPLIFIER P3
    Bang and Olfusen
    from £7,224.79
    from £7,224.79
    This part replaces part number CD33-18C808-AG
    AMPLIFIER P3 Genuine Aston Martin - New (to order)
    # 1
    MPN: GD43-70G443-AA
    AMPLIFIER
    From 16MY, ASK
    from £2,555.20
    from £2,555.20
    AMPLIFIER Genuine Aston Martin - New (to order)
    # 2
    MPN: AD43-601A66-AA
    GASKET, AMP BASE PLATE
    GASKET, AMP BASE PLATE Genuine Aston Martin - New (to order)
    # 3
    MPN: ED43-18C808-CC
    BASE PLATE, AMPLIFIER
    Bang and Olfusen
    from £83.29
    from £83.29
    BASE PLATE, AMPLIFIER Genuine Aston Martin - New (to order)
    # 3
    MPN: GD43-18C808-AA
    BASE PLATE, AMPLIFIER
    ASK
    BASE PLATE, AMPLIFIER Genuine Aston Martin - New (to order)
    # 4
    MPN: 703729
    SCREW, M6X16, HEX FLANGE HEAD
    from £0.47
    from £0.47
    SCREW-M6X16 HEX FLANGE Genuine Aston Martin - New (to order)
    # 4
    MPN: 700607
    SCREW, M6X20, HEX FLANGE HEAD
    16MY
    from £0.47
    from £0.47
    SCREW M6X20 HEX FLANGE Genuine Aston Martin - New (to order)
    # 5
    MPN: 4G43-18B804-AB
    MICROPHONE
    16MY
    from £40.91
    from £40.91
    MICROPHONE Genuine Aston Martin - New (to order)
    MICROPHONE Genuine Aston Martin - Used In stock
