aston martin rapide (2012) multi-function control parts diagram

191001 - Multi-Function Control

Aston Martin Rapide (2012) Multi-Function Control Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Key
Price
# 1
MPN: AD43-14C235-AB
MODULE, ELECTRONIC DOOR CONTROL
Up To VIN F03108
Supersession
Supersession
Genuine Aston Martin (no longer available to order)
# 1
MPN: CD33-14C235-AD
MODULE, ELECTRONIC DOOR CONTROL
FROM VIN F03109 TO VIN F04404
Supersession
Supersession
Genuine Aston Martin (no longer available to order)
# 1
MPN: CD33-14C235-AF
MODULE, ELECTRONIC DOOR CONTROL
FROM VIN F04405
Supersession
Supersession
Genuine Aston Martin (no longer available to order)
# 2
MPN: 9G43-FG0193-KA
SCREW, M6 X 55, POWERLOK
4 per Module
from £0.49
from £0.49
BOLT M6X55 TORQUE HD Genuine Aston Martin - New (to order)
