aston martin rapide (2013) parking aid camera parts diagram

131303-01 - Parking Aid Camera

Aston Martin Rapide (2013) Parking Aid Camera Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Key
Price
# 1
MPN: CD43-19G490-AD
CAMERA, REAR FACING 90 DEGREE
Up To VIN F03108
from £311.67
from £311.67
CAMERA, REAR FACING 90 DEGREE Genuine Aston Martin - New (to order)
# 1
MPN: DD43-19G490-AC
CAMERA, REVERSING
From VIN F03109, to 16MY
from £313.42
from £313.42
CAMERA, REVERSING Genuine Aston Martin - New (to order)
# 1
MPN: GD43-19G490-AA
CAMERA, REVERSING
FROM 16MY
from £597.90
from £597.90
CAMERA, REVERSING Genuine Aston Martin - New (to order)
# 2
MPN: CD43-19H494-AA
BEZEL, CAMERA
Up To VIN F03108
from £1.01
from £1.01
BEZEL, CAMERA Genuine Aston Martin - New (to order)
# 2
MPN: DD43-19H494-AA
BEZEL, REVERSING CAMERA
FROM VIN F03109
from £2.65
from £2.65
BEZEL, REVERSING CAMERA Genuine Aston Martin - New (to order)
# 3
MPN: CD43-19H421-AA
BRACKET, CAMERA
Up To VIN F03108
from £2.07
from £2.07
BRACKET, CAMERA Genuine Aston Martin - New (to order)
# 3
MPN: DD43-19H421-AB
BRACKET, REVERSING CAMERA
FROM VIN F03109
from £1.83
from £1.83
BRACKET, REVERSING CAMERA Genuine Aston Martin - New (to order)
# 4
MPN: W506943-S424
SCREW, M4 X 12MM
SCREW, M4 X 12MM Genuine Aston Martin - New (to order)
# 4
MPN: DD43-4210208809-AA
SCREW, M4 X 16MM, PAN HEAD
FROM VIN F03109
from £0.50
from £0.50
SCREW, M4 X 16MM, PAN HEAD Genuine Aston Martin - New (to order)
