aston martin rapide (2016) parking aid sensors parts diagram

131301-D1 - Parking Aid Sensors

Aston Martin Rapide (2016) Parking Aid Sensors Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                    #
                    Part number
                    Description
                    Key
                    Price
                    # 1
                    MPN: 9G43-37-11061
                    MODULE, PARKING AID
                    from £149.01
                    from £149.01
                    This part replaces part number 6G43-37-10354 which we have in stock
                    MODULE, PARKING AID Genuine Aston Martin - New (to order)
                    # 2
                    MPN: 703164
                    NUT, WASHER HEAD, M6
                    from £0.47
                    from £0.47
                    M6 LOCKNUT FLANGE NYL Genuine Aston Martin - New (to order)
                    # 3
                    MPN: 1R12-37-10342
                    SPEAKER, PARKING AID WITH DUAL LO
                    from £5.00
                    from £5.00
                    SPEAKER-RR PARK SNSR Genuine Aston Martin - New (to order)
                    SPEAKER-RR PARK SNSR Genuine Aston Martin - Used In stock
                    # 4
                    MPN: 702295
                    SCREW, M5X16
                    from £0.47
                    from £0.47
                    NUT M5 HEX FLANGE Genuine Aston Martin - New (to order)
                    # 5
                    MPN: 703178
                    SCREW, M4X8 THREAD FORM
                    from £0.47
                    from £0.47
                    M4 X 8MM SCREW THRD Genuine Aston Martin - New (to order)
                    # 5
                    MPN: 705464
                    SCREW, 4.2X16, LARGE WASHER HEAD
                    Rapide S
                    from £0.47
                    from £0.47
                    SCREW 4.2 X 16 ST Genuine Aston Martin - New (to order)
                    # 6
                    MPN: AH42-15K859-AB
                    SENSOR, PARKING AID, FRONT & REAR-INNER
                    from £34.48
                    from £34.48
                    PARKING AID SENSOR Genuine Aston Martin - New (to order)
                    # 7
                    MPN: 9G92-15B864-AA
                    DECOUPLING RING, PARKING SENSOR
                    from £9.27
                    from £9.27
                    DECOUPLING RING Genuine Aston Martin - New (to order)
                    # 8
                    MPN: 9G92-15K859-AB
                    SENSOR, PARKING AID, FRONT & REAR-OUTER
                    from £64.02
                    from £64.02
                    PARKING AID SENSOR Genuine Aston Martin - New (to order)
                    FRONT PDC SENSOR Genuine Ferrari Part - New (to order)
                    # 9
                    MPN: 8D33-090400-AA
                    HEATSHIELD, PDC SENSOR, INBOARD REAR SENSORS
                    from £2.73
                    from £2.73
                    HEATSHIELD, PDC SENSOR, INBOARD REAR SENSORS Genuine Aston Martin - New (to order)
                    # 10
                    MPN: 8D33-37-10004
                    BRACKET, PARK AID SENSOR, INNER
                    from £2.22
                    from £2.22
                    This part replaces part number 6M2T-15K872-AA
                    BRKT-PRK AID SNS INNER Genuine Aston Martin - New (to order)
