aston martin rapide (2019) brake actuator assembly parts diagram

060600 - Brake Actuator Assembly

Aston Martin Rapide (2019) Brake Actuator Assembly Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
    #
    Part number
    Description
    Key
    Price
    # 1
    MPN: 4G43-2450-DI
    PEDAL BOX ASSEMBLY, AUTO, RHD, SILVER
    from £438.52
    from £438.52
    AUTO RHD BRK & BRACKET Genuine Aston Martin - New (to order)
    # 1
    MPN: 4G43-2450-BI
    PEDAL BOX ASSEMBLY, AUTO, LHD, SILVER
    from £437.42
    from £437.42
    AUTO LHD BRK & BRACKET Genuine Aston Martin - New (to order)
    # 1
    MPN: 4G43-2450-HB
    PEDAL BOX ASSEMBLY, AUTO, RHD, BLACK
    Rapide S Option
    from £375.16
    from £375.16
    AUTO RHD BRK BLACK Genuine Aston Martin - New (to order)
    # 1
    MPN: 4G43-2450-FB
    PEDAL BOX ASSEMBLY, AUTO, LHD, BLACK
    Rapide S Option
    from £398.76
    from £398.76
    AUTO LHD BRK BLACK Genuine Aston Martin - New (to order)
    # 2
    MPN: 9G43-2D042-BA
    PAD KIT, AUTO BRAKE PEDAL, SILVER
    from £108.91
    from £108.91
    KIT PAD BRAKE PDL(A) Genuine Aston Martin - New (to order)
    # 2
    MPN: CD33-2D042-DA
    PAD KIT, AUTO BRAKE PEDAL, BLACK
    Rapide S Option
    from £125.92
    from £125.92
    KIT PAD BRK BLACK Genuine Aston Martin - New (to order)
    # 3
    MPN: 703584
    SCREW, FLG HD, M8 X 40
    from £0.50
    from £0.50
    SCREW M8X40 FLANGE HD 8 Genuine Aston Martin - New (to order)
