aston martin v12 vantage (2011) dynamic weatherstrips, roadster parts diagram

010702-B2 - Dynamic Weatherstrips, Roadster

Aston Martin V12 Vantage (2011) Dynamic Weatherstrips, Roadster Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                              #
                                              Part number
                                              Description
                                              Key
                                              Price
                                              # 1
                                              MPN: 6G33-L20708-AC
                                              SEAL, DOOR PRIMARY
                                              from £500.92
                                              from £500.92
                                              SEAL, DOOR PRIMARY Genuine Aston Martin - New (to order)
                                              # 2
                                              MPN: 6G33-L25325-AB
                                              MARGIN SEAL LOWER FRONT, LH
                                              from £100.87
                                              from £100.87
                                              MARGIN SEAL LOWER FRONT, LH Genuine Aston Martin - New (to order)
                                              # 3
                                              MPN: 6G33-L25324-AB
                                              MARGIN SEAL LOWER FRONT, RH
                                              from £100.87
                                              from £100.87
                                              MARGIN SEAL LOWER FRONT, RH Genuine Aston Martin - New (to order)
                                              # 4
                                              MPN: 6G33-C20571-AD
                                              SEAL, DOOR WAIST INNER, LH
                                              from £60.60
                                              from £60.60
                                              WEATHERSTRIP, DOOR, INNER, LH Genuine Aston Martin - New (to order)
                                              WEATHERSTRIP, DOOR, INNER, LH Genuine Aston Martin - Used In stock
                                              # 5
                                              MPN: 6G33-C20570-AD
                                              SEAL, DOOR WAIST INNER, RH
                                              from £60.60
                                              from £60.60
                                              WEATHERSTRIP, DOOR, INNER, RH Genuine Aston Martin - New (to order)
                                              WEATHERSTRIP, DOOR, INNER, RH Genuine Aston Martin - Used In stock
                                              # 6
                                              MPN: 6G33-23314-AD
                                              INSULATOR, DOOR WINDOW GLASS
                                              from £13.48
                                              from £13.48
                                              INSULATOR, DOOR WINDOW GLASS Genuine Aston Martin - New (to order)
                                              # 7
                                              MPN: 6G33-C20557-AB
                                              SEAL, MARGIN, FRONT DOOR, LH
                                              Supersession
                                              Supersession
                                              Genuine Aston Martin (no longer available to order)
                                              # 8
                                              MPN: 6G33-C20556-AB
                                              SEAL, MARGIN, FRONT DOOR, RH
                                              SEAL, MARGIN, FRONT DOOR, RH Genuine Aston Martin - New (to order)
                                              # 9
                                              MPN: 6G33-C21511-AD
                                              WEATHERSTRIP, FRONT DOOR GLASS CHANNEL, LH
                                              from £204.67
                                              from £204.67
                                              WEATHERSTRIP, FRONT DOOR GLASS CHANNEL, LH Genuine Aston Martin - New (to order)
                                              # 10
                                              MPN: 6G33-C21510-AD
                                              WEATHERSTRIP, FRONT DOOR GLASS CHANNEL, RH
                                              from £204.66
                                              from £204.66
                                              WEATHERSTRIP, FRONT DOOR GLASS CHANNEL, RH Genuine Aston Martin - New (to order)
                                              # 11
                                              MPN: 6G33-C47775-AA
                                              FOAM PAD, DIVISION BAR, DOOR OUTER WAIST
                                              from £0.47
                                              from £0.47
                                              FOAM PAD Genuine Aston Martin - New (to order)
                                              # 12
                                              MPN: 6G33-C20921-BC
                                              MOULDING, FRONT DOOR TRIM, LH
                                              from £187.95
                                              from £187.95
                                              Genuine Aston Martin (no longer available to order)
                                              MOULDING, FRONT DOOR TRIM, LH Genuine Aston Martin - Used In stock
                                              # 13
                                              MPN: 6G33-C20920-BC
                                              MOULDING, FRONT DOOR TRIM, RH
                                              from £187.43
                                              from £187.43
                                              Genuine Aston Martin (no longer available to order)
                                              MOULDING, FRONT DOOR TRIM, RH Genuine Aston Martin - Used In stock
                                              # 14
                                              MPN: 6G33-C02565-BA
                                              RETAINER, WEATHERSTRIP, FRONT BODY PILLAR, LH
                                              Supersession
                                              Supersession
                                              Genuine Aston Martin (no longer available to order)
                                              # 15
                                              MPN: 6G33-C02564-BB
                                              RETAINER, WEATHERSTRIP, FRONT BODY PILLAR, RH
                                              from £23.75
                                              from £23.75
                                              WEATHERSTRIP, RETAINER, PILLAR, RH Genuine Aston Martin - New (to order)
                                              # 16
                                              MPN: 6G33-FA0115-AB-PK
                                              SCREW, M6 X 20, SKT HEAD
                                              Pack of 20
                                              from £12.31
                                              from £12.31
                                              This part replaces part number 6G33-FA0115-AB
                                              SCREW-M6X20 PACK 20 Genuine Aston Martin - New (to order)
                                              # 17
                                              MPN: 6G33-51756-AA-PK
                                              SCREW, M5 X 13, PAN HEAD
                                              Pack of 10
                                              from £2.68
                                              from £2.68
                                              SCREW-M5X13 PN HD(10 Genuine Aston Martin - New In stock
                                              # 18
                                              MPN: 4G43-16K816-AC
                                              WEATHERSTRIP EXTRUSION, HOOD, REAR
                                              from £12.34
                                              from £12.34
                                              WTHRSTP EXT HOOD REAR Genuine Aston Martin - New (to order)
                                              WTHRSTP EXT HOOD REAR Genuine Aston Martin - Used In stock
                                              # 19
                                              MPN: 6G33-16A014-AE
                                              WEATHERSTRIP, HOOD TO FENDER
                                              from £72.26
                                              from £72.26
                                              This part replaces part number 6G33-16A014-AB
                                              WEATHERSTRIP, HOOD TO FENDER Genuine Aston Martin - New (to order)
                                              # 20
                                              MPN: 6G33-L51452-AF
                                              WEATHERSTRIP, TONNEAU
                                              from £1,791.23
                                              from £1,791.23
                                              WEATHERSTRIP, TONNEAU Genuine Aston Martin - New (to order)
                                              # 21
                                              MPN: 702295
                                              NUT, M5, HEX FLANGE HEAD
                                              from £0.47
                                              from £0.47
                                              NUT M5 HEX FLANGE Genuine Aston Martin - New (to order)
                                              # 22
                                              MPN: 4G43-L43720-AE
                                              WEATHERSTRIP, TRUNK
                                              from £278.64
                                              from £278.64
                                              W/STRIP EXT TRNK LID Genuine Aston Martin - New (to order)
                                              # 23
                                              MPN: 6G33-L02564-AA
                                              RETENTION PLATE
                                              from £1.84
                                              from £1.84
                                              RETENTION PLATE Genuine Aston Martin - New (to order)
                                              # 24
                                              MPN: 6G33-L02564-BA
                                              FIR TREE, 4MM
                                              from £0.51
                                              from £0.51
                                              FIR TREE FIX Genuine Aston Martin - New (to order)
