aston martin v12 vantage (2011) heat shields parts diagram

020600 - Heat Shields

Aston Martin V12 Vantage (2011) Heat Shields Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                      #
                      Part number
                      Description
                      Key
                      Price
                      # 1
                      MPN: 6G33-5290-AF
                      HEATSHIELD, EXHAUST MUFFLER, REAR
                      from £496.83
                      from £496.83
                      HEATSHIELD, EXHAUST MUFFLER, REAR Genuine Aston Martin - New (to order)
                      # 2
                      MPN: 703145
                      BOLT/WASHER M6 X 30 HEX FLG
                      from £0.47
                      from £0.47
                      M6 X 30 BOLT Genuine Aston Martin - New (to order)
                      # 3
                      MPN: 6G33-9A032-AD
                      HEATSHIELD, FUEL TANK
                      HEATSHIELD, FUEL TANK Genuine Aston Martin - New (to order)
                      # 4
                      MPN: 702811
                      RIVET
                      from £0.47
                      from £0.47
                      BLIND RIVET 6.5 Genuine Aston Martin - New (to order)
                      # 5
                      MPN: 697286-PK
                      WASHER
                      from £7.22
                      from £7.22
                      WASHER Genuine Aston Martin - New (to order)
                      # 6
                      MPN: AD23-4A380-AB
                      HEATSHIELD, TUNNEL
                      from £328.36
                      from £328.36
                      HEATSHIELD, TUNNEL Genuine Aston Martin - New (to order)
                      # 7
                      MPN: 697452
                      WASHER
                      from £4.39
                      from £4.39
                      WASHER M8 LARGE OD Genuine Aston Martin - New (to order)
                      # 8
                      MPN: 703120
                      SCREW, M8 X 25 HEX FLG HD
                      from £3.45
                      from £3.45
                      SCREW M8X25 HEX FLNG Genuine Aston Martin - New (to order)
                      INTERMEDIATE HEAT SHIELD BOLTS Genuine Ferrari Part - New (to order)
                      # 9
                      MPN: 4G43-017A16-BG
                      HEATSHIELD, FRONT BULK/HD, RHD
                      RHD illustrated
                      from £41.70
                      from £41.70
                      SHLD ASSEMBLY D/PNL HT Genuine Aston Martin - New (to order)
                      SHLD ASSEMBLY D/PNL HT Genuine Aston Martin - Used In stock
                      # 9
                      MPN: 4G43-017A16-AG
                      HEATSHIELD, FRONT BULK/HD, LHD
                      from £83.90
                      from £83.90
                      SHLD ASSEMBLY D/PNL HT Genuine Aston Martin - New (to order)
                      # 10
                      MPN: 703612
                      NUT & WASHER, M6
                      from £0.47
                      from £0.47
                      NUT & WASHER-M6 HEX Genuine Aston Martin - New (to order)
                      # 11
                      MPN: 703151
                      SCREW & WASHER, M6 X 16
                      from £0.47
                      from £0.47
                      SCREW M6X16 HEX HD Genuine Aston Martin - New (to order)
                      LOWER MESH BOLTS Genuine Ferrari Part - New (to order)
