aston martin v12 vantage (2011) gear lever assembly, manual parts diagram

070600-R1 - Gear Lever Assembly, Manual

Aston Martin V12 Vantage (2011) Gear Lever Assembly, Manual Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                  #
                  Part number
                  Description
                  Key
                  Price
                  # 1
                  MPN: 6G33-7Z390-CC
                  GEARSHIFT, CONTROL AND CABLE ASSY, MANUAL
                  from £237.29
                  from £237.29
                  GEARSHIFT, CONTROL AND CABLE ASSEMBLY, MANUAL Genuine Aston Martin - New (to order)
                  GEARSHIFT, CONTROL AND CABLE ASSEMBLY, MANUAL Genuine Aston Martin - Damaged In stock
                  locking pin where gearstick joins broke
                  # 1
                  MPN: 6G33-7E395-AD
                  CABLE ASSY, TRANS, G/SHIFT, MAN, (LONG)
                  from £222.44
                  from £222.44
                  CABLE ASSEMBLY, TRANS, G/SHIFT, MAN, (LONG) Genuine Aston Martin - New (to order)
                  # 1
                  MPN: 6G33-7E395-BD
                  CABLE ASSY, TRANS, G/SHIFT, MAN, (SHORT)
                  from £188.08
                  from £188.08
                  CABLE ASSEMBLY, TRANS, G/SHIFT, MAN, (SHORT) Genuine Aston Martin - New (to order)
                  # 2
                  MPN: 699877
                  NUT, M6
                  Supersession
                  Supersession
                  Genuine Aston Martin (no longer available to order)
                  # 3
                  MPN: 8D33-7K327-AB
                  GEAR KNOB, MANUAL
                  from £1,186.61
                  from £1,186.61
                  KNOB ASSEMBLY, GEAR SHIFT LEVER Genuine Aston Martin - New (to order)
                  # 4
                  MPN: 4G43-7F377-DA
                  BRACKET, TRANSMISSION CABLE RETAINER
                  BRACKET, TRANS CONTROL CABLE Genuine Aston Martin - New (to order)
                  # 5
                  MPN: 703193
                  BOLT, M8X55
                  from £0.47
                  from £0.47
                  BOLT M8X55 HEX FLANGE 8 Genuine Aston Martin - New (to order)
                  # 6
                  MPN: 703187
                  BOLT, M8X25
                  from £0.47
                  from £0.47
                  SCREW M8 X 25 HEX Genuine Aston Martin - New (to order)
                  # 7
                  MPN: 703194
                  BOLT, M8X45
                  from £0.94
                  from £0.94
                  BOLT M8X45 HEX FLNG Genuine Aston Martin - New (to order)
                  # 8
                  MPN: 4G43-7K391-AA
                  CLIP, TRANSMISSION CONT TO HANDSET
                  from £20.61
                  from £20.61
                  CLP-TRANS CONTR CA Genuine Aston Martin - New (to order)
