aston martin v12 vantage (2011) mp3 media parts diagram

150108-D2 - MP3 Media

Aston Martin V12 Vantage (2011) MP3 Media Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
          #
          Part number
          Description
          Key
          Price
          # 1
          MPN: 4G43-37-10950
          MODULE AUU
          from £442.74
          from £442.74
          AUU MODULE Genuine Aston Martin - New (to order)
          # 2
          MPN: 703164
          NUT M6 HEX FLG
          from £0.47
          from £0.47
          M6 LOCKNUT FLANGE NYL Genuine Aston Martin - New (to order)
          # 3
          MPN: 8G43-19C166-AA
          UIP ASSY
          UIP ASSEMBLY Genuine Aston Martin - New (to order)
          # 3
          MPN: 8G43-19C166-AB
          UIP ASSY
          - Fron (V) S00215
          from £54.84
          from £54.84
          AUU UIP Genuine Aston Martin - New (to order)
          # 4
          MPN: 4G43-37-10923
          CONNECTOR, AUX INPUT
          from £4.47
          from £4.47
          AUX INPUT SOCKET-3.5 Genuine Aston Martin - New (to order)
          # 5
          MPN: 8G43-14D454-BA
          CABLE, UIP TO IPOD
          CABLE, UIP TO IPOD Genuine Aston Martin - New (to order)
          # 5
          MPN: 8G43-14D454-BB
          CABLE, UIP TO IPOD
          -Fron (V) S00262
          from £170.59
          from £170.59
          CABLE, UIP TO IPOD Genuine Aston Martin - New (to order)
          # 6
          MPN: 8G43-14D454-CA
          CABLE, UIP TO AUU
          from £122.48
          from £122.48
          USB HARNESS CABLE Genuine Aston Martin - New (to order)
