aston martin v12 vantage (2011) headlights parts diagram

170101-D1 - Headlights

Aston Martin V12 Vantage (2011) Headlights Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
      #
      Part number
      Description
      Key
      Price
      # 1
      MPN: 6G33-13W029-AD
      HEADLAMP ASSEMBLY, RH, RHD
      from £1,732.94
      from £1,732.94
      HEADLAMP ASSEMBLY, RH, RHD Genuine Aston Martin - New (to order)
      # 1
      MPN: 6G33-13W029-BD
      HEADLAMP ASSEMBLY, RH, LHD
      from £1,732.94
      from £1,732.94
      HEADLAMP ASSEMBLY, RH, LHD Genuine Aston Martin - New (to order)
      # 1
      MPN: 6G33-13W029-CD
      HEADLAMP ASSEMBLY, RH, FED
      from £2,610.89
      from £2,610.89
      HEADLAMP ASSEMBLY, RH, FED Genuine Aston Martin - New (to order)
      # 1
      MPN: 6G33-13W029-DE
      HEADLAMP ASSEMBLY, HID, RH, RHD
      Wash and leveling
      from £2,192.06
      from £2,192.06
      HEADLAMP ASSEMBLY, HID, RH, RHD Genuine Aston Martin - New (to order)
      # 1
      MPN: 6G33-13W029-EE
      HEADLAMP ASSEMBLY, HID, RH, LHD
      Wash and leveling
      from £2,192.06
      from £2,192.06
      HEADLAMP ASSEMBLY, HID, RH, LHD Genuine Aston Martin - New (to order)
      # 1
      MPN: 6G33-13W029-FE
      HEADLAMP ASSEMBLY, HID, RH, FED
      Wash and leveling
      from £2,192.06
      from £2,192.06
      HEADLAMP ASSEMBLY, HID, RH, FED Genuine Aston Martin - New (to order)
      # 1
      MPN: BG33-13W029-AC
      HEADLAMP ASSEMBLY, RH, RHD
      -11MY
      from £1,524.98
      from £1,524.98
      HEADLAMP ASSEMBLY, RH, RHD SILVER BEZEL Genuine Aston Martin - New (to order)
      # 1
      MPN: BG33-13W029-BE
      HEADLAMP ASSEMBLY, RH, LHD
      -11MY
      HEADLAMP ASSEMBLY, RH, LHD Genuine Aston Martin - New (to order)
      # 1
      MPN: BG33-13W029-CC
      HEADLAMP ASSEMBLY, RH, FED
      -11MY
      HEADLAMP ASSEMBLY, RH, FED SILVER BEZEL Genuine Aston Martin - New (to order)
      # 2
      MPN: 6G33-13W030-AD
      HEADLAMP ASSEMBLY, LH, RHD
      from £1,732.94
      from £1,732.94
      HEADLAMP ASSEMBLY, LH, RHD Genuine Aston Martin - New (to order)
      # 2
      MPN: 6G33-13W030-BD
      HEADLAMP ASSEMBLY, LH, LHD
      from £1,732.94
      from £1,732.94
      HEADLAMP ASSEMBLY, LH, LHD Genuine Aston Martin - New (to order)
      # 2
      MPN: 6G33-13W030-CC
      HEADLAMP ASSEMBLY, LH, FED
      from £1,587.96
      from £1,587.96
      HEADLAMP ASSEMBLY, LH, FED Genuine Aston Martin - New (to order)
      # 2
      MPN: 6G33-13W030-DE
      HEADLAMP ASSEMBLY, HID, LH, RHD
      Wash and leveling
      from £2,192.06
      from £2,192.06
      HEADLAMP ASSEMBLY, HID, LH, RHD Genuine Aston Martin - New (to order)
      # 2
      MPN: 6G33-13W030-EE
      HEADLAMP ASSEMBLY, HID, LH, LHD
      Wash and leveling
      from £2,192.06
      from £2,192.06
      HEADLAMP ASSEMBLY, HID, LH, LHD Genuine Aston Martin - New (to order)
      # 2
      MPN: 6G33-13W030-FE
      HEADLAMP ASSEMBLY, HID, LH, FED
      Wash and leveling
      from £2,192.06
      from £2,192.06
      HEADLAMP ASSEMBLY, HID, LH, FED Genuine Aston Martin - New (to order)
      # 2
      MPN: BG33-13W030-AC
      HEADLAMP ASSEMBLY, LH, RHD
      -11MY
      HEADLAMP ASSEMBLY, LH, RHD SILVER BEZEL Genuine Aston Martin - New (to order)
      # 2
      MPN: BG33-13W030-BE
      HEADLAMP ASSEMBLY, LH, LHD
      -11MY
      HEADLAMP ASSEMBLY, LH, LHD SILVER BEZEL Genuine Aston Martin - New (to order)
      # 2
      MPN: BG33-13W030-CC
      HEADLAMP ASSEMBLY, LH, FED
      -11MY
      from £1,483.45
      from £1,483.45
      HEADLAMP ASSEMBLY, LH, FED SILVER BEZEL Genuine Aston Martin - New (to order)
      # 3
      MPN: 4G43-13C169-AA
      MODULE, BALLAST
      DENSO
      from £90.87
      from £90.87
      Genuine Aston Martin (no longer available to order)
      MODULE, BALLAST Genuine Aston Martin - Used In stock
      # 3
      MPN: 4G43-13C169-AB
      MODULE, BALLAST
      De Amertek
      from £197.63
      from £197.63
      This part replaces part number 4G43-13C169-AA which we have in stock
      MODULE, BALLAST Genuine Aston Martin - New (to order)
      # 4
      MPN: 6G33-13C025-AB
      JET WASH COVER,NOZZLE & PUMP, LH
      from £121.62
      from £121.62
      JET WASH COVER,NOZZLE & PUMP, LH Genuine Aston Martin - New (to order)
      JET WASH COVER,NOZZLE & PUMP, LH Genuine Aston Martin - Used In stock
      # 5
      MPN: 6G33-13C024-AB
      JET WASH COVER,NOZZLE & PUMP, RH
      from £243.24
      from £243.24
      JET WASH COVER,NOZZLE & PUMP, RH Genuine Aston Martin - New (to order)
      # 6
      MPN: 6G33-13C025-BA
      JET WASH MOULDING COVER, NON HID, LH
      including spring
      JET WASH MOULDING COVER, NON HID, LH Genuine Aston Martin - New (to order)
      # 6
      MPN: 6G33-13C024-BA
      JET WASH MOULDING COVER, NON HID, RH
      including spring
      JET WASH MOULDING COVER, NON HID, RH Genuine Aston Martin - New (to order)
      # 7
      MPN: 4U5A-13N021-AA
      BULB, HALOGEN, H11
      Dip Beam
      from £32.26
      from £32.26
      BULB, HALOGEN, H11 Genuine Aston Martin - New (to order)
      # 8
      MPN: 4G43-99703-AA
      BULB, MAIN BEAM, 65W H9
      Main Beam
      from £72.52
      from £72.52
      BULB 65W TYPE H9 Genuine Aston Martin - New (to order)
      # 9
      MPN: 4G43-37-10226
      BULB, DIP, HID
      Dip Beam (HID)
      from £111.81
      from £111.81
      BULB-H/LAMP HID Genuine Aston Martin - New (to order)
      # 10
      MPN: 4G43-13465-AA
      BULB, BLUE- W5W
      Side Lights
      BULB, BLUE- W5W Genuine Aston Martin - New (to order)
      # 11
      MPN: 4G43-13465-BA
      BULB, AMBER, PY27/7W
      INDICATOR
      from £7.27
      from £7.27
      BULB, AMBER, PY27/7W Genuine Aston Martin - New (to order)
