7.6A - BONNET

Aston Martin V8 Coupe (1999) Bonnet Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                                      #
                                                                      Part number
                                                                      Description
                                                                      Key
                                                                      Price
                                                                      # 1
                                                                      MPN: 64-71072
                                                                      BONNET ASSEMBLY
                                                                      from £7,128.33
                                                                      from £7,128.33
                                                                      ASSEMBLY BONNET IN WHITE Genuine Aston Martin - New (to order)
                                                                      # 4
                                                                      MPN: 64-51551
                                                                      CLAMPING PLATE ASSEMBLY, STRIKER BRACKET
                                                                      from £7.99
                                                                      from £7.99
                                                                      ASSEMBLY CLAMPING PLATE Genuine Aston Martin - New (to order)
                                                                      # 5
                                                                      MPN: 64-72474
                                                                      GAS STAY MOUNTING REINFORCEMEMNT ASSEMBLY
                                                                      GAS STAY MOUNTING REINFORCEMEMNT ASSEMBLY Genuine Aston Martin - New (to order)
                                                                      # 6
                                                                      MPN: 64-72476
                                                                      HINGE REINFORCEMEMNT PLATE ASSEMBLY
                                                                      ASSEMBLY RNF PLT HNG Genuine Aston Martin - New (to order)
                                                                      # 7
                                                                      MPN: 110897
                                                                      RIVET, 1/8 X 3/8 SOLID ALUMINIUM
                                                                      from £0.47
                                                                      from £0.47
                                                                      RIVET 1/8 X 3/8 COUNTERSUNK Genuine Aston Martin - New (to order)
                                                                      Genuine Ferrari Part (no longer available to order)
                                                                      # 8
                                                                      MPN: 64-53017
                                                                      BONNET LAMP SUPPORT PLATE ASSEMBLY
                                                                      from £4.22
                                                                      from £4.22
                                                                      ASSEMBLY SPT PLT BNT LAMP Genuine Aston Martin - New (to order)
                                                                      # 9
                                                                      MPN: 64-73929
                                                                      BONNET SAFETY CATCH RETAINING PLATE ASSEMBLY
                                                                      BONNET SAFETY CATCH RETAINING PLATE ASSEMBLY Genuine Aston Martin - New (to order)
                                                                      # 10
                                                                      MPN: 64-72486
                                                                      Bonnet hinge mounting bracket assembly
                                                                      Bonnet hinge mounting bracket assembly Genuine Aston Martin - New (to order)
                                                                      # -
                                                                      -
                                                                      LOCTITE 341, 2X300ML
                                                                      # 11
                                                                      MPN: 64-72478
                                                                      BONNET HINGE ASSEMBLY, RH
                                                                      from £82.66
                                                                      from £82.66
                                                                      ASSEMBLY HINGE BONNET RH Genuine Aston Martin - New (to order)
                                                                      # 11
                                                                      MPN: 64-72479
                                                                      BONNET HINGE ASSEMBLY, LH
                                                                      from £41.58
                                                                      from £41.58
                                                                      ASSEMBLY HINGE BONNET LH Genuine Aston Martin - New (to order)
                                                                      # 12
                                                                      MPN: 696464
                                                                      BOLT, SKT SHLDR, M10X25
                                                                      Bonnet pivot
                                                                      from £8.91
                                                                      from £8.91
                                                                      BOLT M10 X 25 SOCKET Genuine Aston Martin - New (to order)
                                                                      # 13
                                                                      MPN: 696463
                                                                      WASHER, CRINKLE, M12 COPPER SELF FINISH
                                                                      Bonnet pivot
                                                                      from £0.74
                                                                      from £0.74
                                                                      WASHER M12 CRINKLE Genuine Aston Martin - New (to order)
                                                                      # -
                                                                      -
                                                                      COPA SLIP, 8OZ TUBE
                                                                      Bonnet pivot
                                                                      # 14
                                                                      MPN: 696729
                                                                      SCREW, M8X12
                                                                      Bonnet hinge to bracket
                                                                      from £3.51
                                                                      from £3.51
                                                                      SCREW M8 X 12 HEX Genuine Aston Martin - New (to order)
                                                                      # 15
                                                                      MPN: 696729
                                                                      SCREW, M8X12
                                                                      Hinge bracket to bonnet
                                                                      from £3.51
                                                                      from £3.51
                                                                      SCREW M8 X 12 HEX Genuine Aston Martin - New (to order)
                                                                      # -
                                                                      -
                                                                      LOCTITE 242E SEALANT
                                                                      # 16
                                                                      MPN: 64-72494
                                                                      GAS STAY, BONNET
                                                                      from £116.05
                                                                      from £116.05
                                                                      GAS STAY-BONNET Genuine Aston Martin - New (to order)
                                                                      # 17
                                                                      MPN: 64-72330
                                                                      BRACKET, GAS STAY, BONNET
                                                                      from £14.49
                                                                      from £14.49
                                                                      BRACKET GAS STRUT-BNNT Genuine Aston Martin - New (to order)
                                                                      # 18
                                                                      MPN: 695515
                                                                      NUT, NYLOC, M8
                                                                      Gas stay to bonnet/chassis
                                                                      from £0.50
                                                                      from £0.50
                                                                      NUT M8 HEX FLANGE SLK Genuine Aston Martin - New (to order)
                                                                      # 19
                                                                      MPN: 695563
                                                                      SCREW, FLG, M6X16
                                                                      Gas stay to bracket to bonnet
                                                                      SCREW, M6 X 16, HEATER UNIT TO FACIA Genuine Aston Martin - New (to order)
                                                                      # 20
                                                                      MPN: 64-51552
                                                                      STRIKER BRACKET, RH
                                                                      STRIKER BRACKET, RH Genuine Aston Martin - New (to order)
                                                                      # 20
                                                                      MPN: 64-51553
                                                                      STRIKER BRACKET, LH
                                                                      STRIKER BRACKET, LH Genuine Aston Martin - New (to order)
                                                                      # 21
                                                                      MPN: 695563
                                                                      SCREW, FLG, M6X16
                                                                      Striker bracket to bonnet
                                                                      SCREW, M6 X 16, HEATER UNIT TO FACIA Genuine Aston Martin - New (to order)
                                                                      # 22
                                                                      MPN: 64-25926
                                                                      STRIKER, BONNET
                                                                      from £10.94
                                                                      from £10.94
                                                                      STRIKER BONNET Genuine Aston Martin - New (to order)
                                                                      # 23
                                                                      MPN: 694040
                                                                      SCREW, M6X16 CSK POZI HD
                                                                      Striker to bracket
                                                                      SCREW, M6 x 16 Genuine Aston Martin - New (to order)
                                                                      # 24
                                                                      MPN: 692056
                                                                      WASHER, PLAIN, M6
                                                                      Striker to bracket
                                                                      from £0.47
                                                                      from £0.47
                                                                      WASHER, PLAIN, M6 Genuine Aston Martin - New (to order)
                                                                      # 25
                                                                      MPN: 692151
                                                                      NUT, NYLOC, M6
                                                                      Striker to bracket
                                                                      from £0.57
                                                                      from £0.57
                                                                      NUT M6 HEX SLK Genuine Aston Martin - New (to order)
                                                                      # 26
                                                                      MPN: 64-73934
                                                                      HOOK, BONNET SAFETY CATCH
                                                                      BONNET SAFETY CATCH Genuine Aston Martin - New (to order)
                                                                      # 27
                                                                      MPN: 64-73935
                                                                      PIVOT PIN, BONNET SAFETY CATCH
                                                                      from £3.43
                                                                      from £3.43
                                                                      PIVOT PIN SAFETY Genuine Aston Martin - New (to order)
                                                                      # 28
                                                                      MPN: 64-73936
                                                                      SPRING, BONNET SAFETY CATCH
                                                                      SPRING, BONNET SAFETY CATCH Genuine Aston Martin - New (to order)
                                                                      # 29
                                                                      MPN: 64-73937
                                                                      BEARING SPACER, BONNET SAFETY CATCH
                                                                      from £0.47
                                                                      from £0.47
                                                                      BEARING SPACER Genuine Aston Martin - New (to order)
                                                                      # 30
                                                                      MPN: 64-73938
                                                                      CLIP, BONNET SAFETY CATCH
                                                                      from £0.49
                                                                      from £0.49
                                                                      CLIP Genuine Aston Martin - New (to order)
                                                                      # 31
                                                                      MPN: 64-73930
                                                                      BRACKET, BONNET SAFETY CATCH
                                                                      from £10.09
                                                                      from £10.09
                                                                      BRACKET BONN SAFETY Genuine Aston Martin - New (to order)
                                                                      # 32
                                                                      MPN: 691453
                                                                      SCREW, M6X10
                                                                      BRACKET, BONNET SAFETY CATCH
                                                                      from £1.59
                                                                      from £1.59
                                                                      SCREW M6 X 10 HEX HD Genuine Aston Martin - New (to order)
                                                                      # 33
                                                                      MPN: 692056
                                                                      WASHER, PLAIN, M6
                                                                      BRACKET, BONNET SAFETY CATCH
                                                                      from £0.47
                                                                      from £0.47
                                                                      WASHER, PLAIN, M6 Genuine Aston Martin - New (to order)
                                                                      # -
                                                                      -
                                                                      SCREW, BUTTON FLG, M6X12
                                                                      Blank opp hand safety catch holes
                                                                      # 34
                                                                      MPN: 64-74046
                                                                      RETAINING PLATE ASSEMBLY, RH
                                                                      from £6.94
                                                                      from £6.94
                                                                      ASSEMBLY RETN PLATE RH Genuine Aston Martin - New (to order)
                                                                      # 34
                                                                      MPN: 64-74047
                                                                      RETAINING PLATE ASSEMBLY, LH
                                                                      from £6.94
                                                                      from £6.94
                                                                      ASSEMBLY RETN PLATE L/H Genuine Aston Martin - New (to order)
                                                                      # 35
                                                                      MPN: 64-73933
                                                                      BONNET LATCH
                                                                      from £92.43
                                                                      from £92.43
                                                                      BONNET LATCH (MOD) Genuine Aston Martin - New (to order)
                                                                      # 36
                                                                      MPN: 64-73946
                                                                      CATCH PLATE
                                                                      LHD
                                                                      CATCH PLATE Genuine Aston Martin - New (to order)
                                                                      # 37
                                                                      MPN: 691453
                                                                      SCREW, M6X10
                                                                      LHD
                                                                      from £1.59
                                                                      from £1.59
                                                                      SCREW M6 X 10 HEX HD Genuine Aston Martin - New (to order)
                                                                      # 38
                                                                      MPN: 692066
                                                                      WASHER, SHAKEPROOF, M6
                                                                      LHD
                                                                      from £0.47
                                                                      from £0.47
                                                                      WASHER, SPR, M6 Genuine Aston Martin - New (to order)
                                                                      # 39
                                                                      MPN: 692056
                                                                      WASHER, PLAIN, M6
                                                                      LHD
                                                                      from £0.47
                                                                      from £0.47
                                                                      WASHER, PLAIN, M6 Genuine Aston Martin - New (to order)
                                                                      # 40
                                                                      MPN: 692241
                                                                      BOLT, M6X35
                                                                      from £0.47
                                                                      from £0.47
                                                                      BOLT M6 X 35 HEX Genuine Aston Martin - New (to order)
                                                                      # 41
                                                                      MPN: 64-73926
                                                                      SPACER PLATE, BONNET RELEASE
                                                                      from £1.82
                                                                      from £1.82
                                                                      SPACER PLT BONN REL Genuine Aston Martin - New (to order)
                                                                      # 42
                                                                      MPN: 692005
                                                                      SCREW, M5X16
                                                                      from £0.47
                                                                      from £0.47
                                                                      SCREW M5 X 16 HEX HD Genuine Aston Martin - New (to order)
                                                                      # 43
                                                                      MPN: 692055
                                                                      WASHER, PLAIN, M5
                                                                      from £0.47
                                                                      from £0.47
                                                                      WASHER M5 PLAIN MED Genuine Aston Martin - New (to order)
                                                                      # 44
                                                                      MPN: 692800
                                                                      NUT, NYLOC, M5
                                                                      from £0.47
                                                                      from £0.47
                                                                      NUT M5 HEX SLK Genuine Aston Martin - New (to order)
                                                                      # 45
                                                                      MPN: 64-73924
                                                                      BRACKET, CABLE, RH
                                                                      from £14.27
                                                                      from £14.27
                                                                      BRACKET CABLE RH Genuine Aston Martin - New (to order)
                                                                      # 45
                                                                      MPN: 64-73923
                                                                      BRACKET, CABLE, LH
                                                                      from £14.27
                                                                      from £14.27
                                                                      BRACKET CABLE LH Genuine Aston Martin - New (to order)
                                                                      # 46
                                                                      MPN: 64-52962
                                                                      LEVER, BONNET RELEASE
                                                                      from £82.66
                                                                      from £82.66
                                                                      LEVER-BONNET RELEASE Genuine Aston Martin - New (to order)
                                                                      # 47
                                                                      MPN: 64-52963
                                                                      SELF ADHESIVE LABEL
                                                                      from £15.77
                                                                      from £15.77
                                                                      LABEL-SELF ADHESIVE Genuine Aston Martin - New (to order)
                                                                      # 48
                                                                      MPN: 64-54051
                                                                      MOUNTING BRACKET, BONNET RELEASE
                                                                      from £63.46
                                                                      from £63.46
                                                                      ASSEMBLY M/BRKT BONNT REL Genuine Aston Martin - New (to order)
                                                                      # 49
                                                                      MPN: 692262
                                                                      SCREW, M6X12
                                                                      Release lever to mounting bracket
                                                                      from £0.47
                                                                      from £0.47
                                                                      SCREW M6 X 12 HEX HD Genuine Aston Martin - New (to order)
                                                                      # 50
                                                                      MPN: 692090
                                                                      SCREW, M5X12
                                                                      Mounting bracket attach
                                                                      from £0.47
                                                                      from £0.47
                                                                      SCREW M5 X 12 HEX HD Genuine Aston Martin - New (to order)
                                                                      # 51
                                                                      MPN: 692065
                                                                      WASHER, SHAKEPROOF, M5
                                                                      Mounting bracket attach
                                                                      from £0.47
                                                                      from £0.47
                                                                      WASHER M5 S/PROOF Genuine Aston Martin - New (to order)
                                                                      # 52
                                                                      MPN: 692055
                                                                      WASHER, PLAIN, M5
                                                                      Mounting bracket attach
                                                                      from £0.47
                                                                      from £0.47
                                                                      WASHER M5 PLAIN MED Genuine Aston Martin - New (to order)
                                                                      # 53
                                                                      MPN: 692243
                                                                      SCREW, M5X16
                                                                      Mounting bracket attach
                                                                      from £0.47
                                                                      from £0.47
                                                                      SCREW M5 X 16 PAN Genuine Aston Martin - New (to order)
                                                                      # 54
                                                                      MPN: 692065
                                                                      WASHER, SHAKEPROOF, M5
                                                                      Mounting bracket attach
                                                                      from £0.47
                                                                      from £0.47
                                                                      WASHER M5 S/PROOF Genuine Aston Martin - New (to order)
                                                                      # 55
                                                                      MPN: 692055
                                                                      WASHER, PLAIN, M5
                                                                      Mounting bracket attach
                                                                      from £0.47
                                                                      from £0.47
                                                                      WASHER M5 PLAIN MED Genuine Aston Martin - New (to order)
                                                                      # 56
                                                                      MPN: 64-52621
                                                                      CABLE, BONNET RELEASE, LONG
                                                                      from £167.20
                                                                      from £167.20
                                                                      CBL.BONNT.REL.(LONG) Genuine Aston Martin - New (to order)
                                                                      # 57
                                                                      MPN: 64-52622
                                                                      CABLE, BONNET RELEASE, SHORT
                                                                      from £159.33
                                                                      from £159.33
                                                                      CBL.BONNT.REL(SHORT) Genuine Aston Martin - New (to order)
                                                                      # 58
                                                                      MPN: 692378
                                                                      GROMMET, 3/8 BORE
                                                                      BONNET CABLE
                                                                      from £0.47
                                                                      from £0.47
                                                                      GROMMET 3/8 BORE Genuine Aston Martin - New (to order)
                                                                      # 59
                                                                      MPN: 696507
                                                                      P CLIP, BLACK NYLON
                                                                      LHD
                                                                      from £0.47
                                                                      from £0.47
                                                                      P CLIP BLK NYLON 7.9 Genuine Aston Martin - New (to order)
                                                                      # 60
                                                                      MPN: 692525
                                                                      P CLIP, 1/4 NYLON
                                                                      LHD, Bonnet release cable attach
                                                                      from £0.47
                                                                      from £0.47
                                                                      P-CLIP 1/4 NYLON Genuine Aston Martin - New (to order)
                                                                      # 61
                                                                      MPN: 691020
                                                                      SCREW, NO.8X1/2
                                                                      LHD, Bonnet release cable attach
                                                                      from £0.47
                                                                      from £0.47
                                                                      SCREW NO8 X 1/2 PK Genuine Aston Martin - New (to order)
                                                                      # 62
                                                                      MPN: 693374
                                                                      CABLE TIE, 98MM X 22MM
                                                                      Bonnet release cable attach
                                                                      from £0.47
                                                                      from £0.47
                                                                      CBL-TIE 98MMX22MM Genuine Aston Martin - New (to order)
