aston martin v8 coupe (2000) interior lamps parts diagram

6.2C - Interior Lamps

Aston Martin V8 Coupe (2000) Interior Lamps Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                    #
                    Part number
                    Description
                    Key
                    Price
                    # 1
                    MPN: 069-037-0151
                    BONNET LAMP
                    from £149.69
                    from £149.69
                    LAMP-BONNET &REVERSE Genuine Aston Martin - New (to order)
                    # 2
                    MPN: 37-72495
                    GASKET, BONNET LAMP
                    from £6.36
                    from £6.36
                    GASKET-BONNET LAMP Genuine Aston Martin - New (to order)
                    # 3
                    MPN: 696470
                    SCREW, M4X12 PAN, PLASTIC, NYLON
                    Bonnet lamp attach
                    from £0.47
                    from £0.47
                    SCREW M4 X 12 PAN Genuine Aston Martin - New (to order)
                    # 4
                    MPN: 691917
                    GROMMET, 3/8 PVC
                    Bonnet lamp harness
                    from £0.47
                    from £0.47
                    GROMMET 3/8 PVC Genuine Aston Martin - New (to order)
                    # 5
                    MPN: 37-73454
                    INTERIOR LAMP, FRONT
                    from £47.42
                    from £47.42
                    INT LAMP FRONT MODIF'D Genuine Aston Martin - New (to order)
                    # 6
                    MPN: 37-62218
                    LENS, FOOTWELL LAMP
                    from £17.80
                    from £17.80
                    LENS Genuine Aston Martin - New (to order)
                    # 7
                    MPN: 37-50378
                    EYEBALL LAMP
                    from £67.87
                    from £67.87
                    EYEBALL LAMP Genuine Aston Martin - New (to order)
                    # 8
                    MPN: 37-52860
                    BULB HOLDER
                    from £6.25
                    from £6.25
                    BULB HOLDER Genuine Aston Martin - New (to order)
                    # -
                    -
                    TERMINAL, EARTHING
                    # -
                    -
                    SCREW, NO.6 X 3/8
                    Earth terminal to header rail
                    # 9
                    MPN: 37-10809
                    BOOT LAMP
                    from £27.84
                    from £27.84
                    INTERIOR LAMP Genuine Aston Martin - New (to order)
                    # 10
                    MPN: 37-72064
                    DOOR EDGE LAMP
                    from £27.43
                    from £27.43
                    DOOR EDGE LAMP Genuine Aston Martin - New (to order)
                    # 11
                    MPN: 37-72065
                    DOOR PUDDLE LAMP
                    from £5.03
                    from £5.03
                    DOOR PUDDLE LAMP Genuine Aston Martin - New (to order)
                    # -
                    -
                    HIGH MOUNTED STOP LAMP ASSEMBLY
                    Australia, New Zealand and Japan
                    # 12
                    MPN: 37-54668
                    BODY AND LENS, HIGH MOUNTED STOP LAMP
                    Australia, New Zealand and Japan
                    from £351.19
                    from £351.19
                    BODY & LENS Genuine Aston Martin - New (to order)
