aston martin v8 coupe (2000) body panels parts diagram

7.3A - Body Panels

Aston Martin V8 Coupe (2000) Body Panels Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Key
Price
# -
MPN: 62-55921
FRONT END ASSEMBLY, COMPLETE
ASSEMBLY FRONT END COMPLETE Genuine Aston Martin - New (to order)
# 1
MPN: 62-74177
NOSE PANEL ASSEMBLY
from £3,292.85
from £3,292.85
ASSEMBLY NOSE PANEL Genuine Aston Martin - New (to order)
# -
-
SPREADER PLATE ASSEMBLY, FRONT END NOSE PANEL
# -
-
SCREW, FLG, M6X12
Nose panel to chassis/spreader
# -
-
NUT, LUG, M6
Nose panel to chassis/spreader
# -
-
EVODE MULTI-SEAL
Nose panel to chassis/spreader
# 2
MPN: 64-55931
Bonnet skin panel
Bonnet skin panel Genuine Aston Martin - New (to order)
# 3
MPN: 62-55922
FRONT WING ASSEMBLY, RH
from £3,999.31
from £3,999.31
ASSEMBLY FRONT WING RH Genuine Aston Martin - New (to order)
# 4
MPN: 62-55923
FRONT WING ASSEMBLY, LH
from £3,999.31
from £3,999.31
ASSEMBLY FRONT WING LH Genuine Aston Martin - New (to order)
# -
-
DRAIN TUBE, FRONT WING
# -
-
Fixing angle, front wing retaining
# 5
MPN: 62-50196
A' post, RH
from £47.31
from £47.31
`A' POST RH-FINISHED Genuine Aston Martin - New (to order)
# 6
MPN: 62-50197
A' post, LH
from £47.31
from £47.31
`A' POST LH-FINISHED Genuine Aston Martin - New (to order)
# 7
MPN: 62-53548
FINISHER, CANTRAIL, FRONT, RH
Made from 62-53548R
FINISHER, CANTRAIL, FRONT, RH Genuine Aston Martin - New (to order)
# 8
MPN: 62-53549
FINISHER, CANTRAIL, FRONT, LH
Made from 62-53548R
FINISHER, CANTRAIL, FRONT, LH Genuine Aston Martin - New (to order)
# -
-
PACKING STRIP, CANT RAIL
# 9
MPN: 65-60470
DOOR SKIN ASSEMBLY, RH
Up to (V)79044
from £1,316.75
from £1,316.75
ASSEMBLY DOOR SKIN - RH Genuine Aston Martin - New (to order)
# 9
MPN: 65-74494
DOOR SKIN ASSEMBLY, RH
From (V)79045 excl 79074 up to (V)79079
from £1,545.74
from £1,545.74
ASSEMBLY DOOR SKIN RH Genuine Aston Martin - New (to order)
# 9
MPN: 65-65200
DOOR SKIN PANEL, RH
From (V)79080 + 79074
from £953.41
from £953.41
DOOR SKIN PANEL RH Genuine Aston Martin - New (to order)
# 10
MPN: 65-60471
DOOR SKIN ASSEMBLY, LH
Up to (V)79044
from £1,316.75
from £1,316.75
ASSEMBLY DOOR SKIN-LH Genuine Aston Martin - New (to order)
# 10
MPN: 65-74495
DOOR SKIN ASSEMBLY, LH
From (V)79045 excl 79074 up to (V)79079
ASSEMBLY DOOR SKIN LH Genuine Aston Martin - New (to order)
# 10
MPN: 65-65201
DOOR SKIN PANEL, LH
From (V)79080 + 79074
from £953.41
from £953.41
DOOR SKIN PANEL LH Genuine Aston Martin - New (to order)
# 11
MPN: 62-72359
B' post, RH
Made from 62-50198R
B' post, RH Genuine Aston Martin - New (to order)
# 12
MPN: 62-72360
B' post, LH
Made from 62-50198R
B' post, LH Genuine Aston Martin - New (to order)
# 13
MPN: 62-53550
FINISHER, CANTRAIL, REAR, RH
Made from 62-53550R
FINISHER, CANTRAIL, REAR, RH Genuine Aston Martin - New (to order)
# 14
MPN: 62-53551
FINISHER, CANTRAIL, REAR, LH
Made from 62-53550R
FINISHER, CANTRAIL, REAR, LH Genuine Aston Martin - New (to order)
# 15
MPN: 62-50200
C' post, RH
C' post, RH Genuine Aston Martin - New (to order)
# 15
MPN: 62-50201
C' post, LH
C' post, LH Genuine Aston Martin - New (to order)
# 16
MPN: 62-55926
REAR END ASSEMBLY, COMPLETE
ASSEMBLY REAR END COMPLETE Genuine Aston Martin - New (to order)
# 17
MPN: 62-55924
REAR WING ASSEMBLY, RH
from £1,814.74
from £1,814.74
ASSEMBLY REAR WING RH Genuine Aston Martin - New (to order)
# 18
MPN: 62-55925
REAR WING ASSEMBLY, LH
from £1,814.74
from £1,814.74
ASSEMBLY REAR WING LH Genuine Aston Martin - New (to order)
# 19
MPN: 62-71069
REAR PANEL
from £705.09
from £705.09
REAR PANEL Genuine Aston Martin - New (to order)
# 20
MPN: 62-72361
SADDLE STRIP
from £395.55
from £395.55
SADDLE STRIP-(REWKD) Genuine Aston Martin - New (to order)
# 21
MPN: 62-50190
ROOF PANEL
ROOF SKIN (REWORKED) Genuine Aston Martin - New (to order)
# 21
MPN: 62-52950
ROOF PANEL, C/W A AND C POSTS
from £1,923.55
from £1,923.55
ASSEMBLY ROOF PANEL Genuine Aston Martin - New (to order)
# 22
MPN: 68-50202
FUEL FLAP, RH
FUEL FLAP RH Genuine Aston Martin - New (to order)
# 23
MPN: 68-50203
FUEL FLAP, LH
FUEL FLAP LH Genuine Aston Martin - New (to order)
# 24
MPN: 67-71073
BOOT LID OUTER SKIN PANEL
ASSEMBLY BOOT LID OUTER Genuine Aston Martin - New (to order)
# -
-
RIVET, 1/8 X 3/8 CSK, SOLID ALUMINIUM
# -
-
POP RIVET, 1/8 X 5/16
# -
-
POP RIVET, 3.2X8.5 CLOSED END
# -
-
SCREW, NO 4 X 1/2
# -
-
MASKING TAPE (RED) 1 1/2
# -
-
DURALAC JOINT COMPOUND
# -
-
SEALANT, TEROSTAT
