aston martin v8 vantage (2009) body dash and cowl, coupe parts diagram

010102-20 - body dash and cowl, coupe

Aston Martin V8 Vantage (2009) Body Dash and Cowl, Coupe Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
    #
    Part number
    Description
    Key
    Price
    # 1
    MPN: EG33-C03014-BB
    FRAME ASSEMBLY, WINDSHIELD, RHD
    Up to 16MY. Structural. Cat A Only
    FRAME ASSEMBLY, WINDSHIELD, RHD Genuine Aston Martin - New (to order)
    # 1
    MPN: HG33-C03014-BB
    FRAME ASSEMBLY, WINDSHIELD, RHD
    From 17MY. Structural. Cat A Only
    FRAME ASSEMBLY, WINDSHIELD, RHD Genuine Aston Martin - New (to order)
    # 1
    MPN: EG33-C03014-AB
    FRAME ASSEMBLY, WINDSHIELD, LHD
    Up to 16MY. Structural. Cat A Only
    from £2,329.83
    from £2,329.83
    This part replaces part number 4G43-C03014-AR
    FRAME ASSEMBLY, WINDSHIELD, LHD Genuine Aston Martin - New (to order)
    # 1
    MPN: HG33-C03014-AB
    FRAME ASSEMBLY, WINDSHIELD, LHD
    From 17MY. Structural. Cat A Only
    FRAME ASSEMBLY, WINDSHIELD, LHD Genuine Aston Martin - New (to order)
    # 2
    MPN: GOAG33-F02527-AA
    REINFORCEMENT, FRONT BODY PILLAR, LH
    Up To 16MY, Structural. Cat A only
    from £53.74
    from £53.74
    REINFORCEMENT, FRONT BODY PILLAR, LH Genuine Aston Martin - New (to order)
    # 2
    MPN: GOAG33-F02526-AA
    REINFORCEMENT, FRONT BODY PILLAR, RH
    Up To 16MY, Structural. Cat A only
    REINFORCEMENT FRONT BODY PILLAR, RH Genuine Aston Martin - New (to order)
    # 2
    MPN: GOGG33-F02526-AA
    REINFORCEMENT, FRONT BODY PILLAR
    From 16MY, Structural. Cat A only
    from £188.92
    from £188.92
    REINFORCEMENT, FRONT BODY PILLAR Genuine Aston Martin - New (to order)
    # 3
    MPN: AG33-10414-AA
    MEMBER, FRONT CROSS AT DASH
    Structural. Cat A Only
    from £52.97
    from £52.97
    MEMBER, FRONT CROSS AT DASH Genuine Aston Martin - New (to order)
    # 4
    MPN: AG33-9N790-BA
    SPACER ASSY, ACCELERATOR PEDAL
    RHD Only, Structural. Cat A Only
    SPACER ASSEMBLY, ACCELERATOR PEDAL Genuine Aston Martin - New (to order)
    # 5
    MPN: GOGG33-02526-AB
    REINFORCEMENT, A PILLAR, UPPER
    From 16MY, Structural. Cat A only
    from £42.10
    from £42.10
    REINFORCEMENT, A PILLAR, UPPER Genuine Aston Martin - New (to order)
    # 6
    MPN: GOFD33-025D07-AC
    REINFORCEMENT, A PILLAR, LOWER, LH
    From 16MY, Structural. Cat A only
    from £100.76
    from £100.76
    A PLR REINFORCEMENT CAST LOWER Genuine Aston Martin - New (to order)
    # 6
    MPN: GOFD33-025D06-AC
    REINFORCEMENT, A PILLAR, LOWER, RH
    From 16MY, Structural. Cat A only
    from £100.76
    from £100.76
    A PLR REINFORCEMENT CAST LOWER Genuine Aston Martin - New (to order)
    # 7
    MPN: 6G33-68676-AC
    RIVET, 6.5X14
    from £0.72
    from £0.72
    STRUCT RIVET 6.5X14 Genuine Aston Martin - New (to order)
