aston martin v8 vantage (2009) front bumper, gt8 parts diagram

011901-25 - Front Bumper, GT8

Aston Martin V8 Vantage (2009) Front Bumper, GT8 Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
            #
            Part number
            Description
            Key
            Price
            # 1
            MPN: HG3Y-17D957-AA
            BUMPER COVER ASSEMBLY, FRONT
            from £12,525.33
            from £12,525.33
            BUMPER COVER ASSEMBLY, FRONT Genuine Aston Martin - New (to order)
            # 2
            MPN: HG3Y-17B968-AA
            VALANCE, LOWER
            Black, Painted
            from £13,967.76
            from £13,967.76
            VALANCE, LOWER Genuine Aston Martin - New (to order)
            # 2
            MPN: HG3Y-17B968-BA
            VALANCE, LOWER
            Gloss Clearcoat
            from £13,560.93
            from £13,560.93
            VALANCE, LOWER Genuine Aston Martin - New (to order)
            # 2
            MPN: HG3Y-17B968-KA
            VALANCE, LOWER
            Natural Carbon
            VALANCE, LOWER Genuine Aston Martin - New (to order)
            # 2
            MPN: HG3Y-17B968-MA
            VALANCE, LOWER
            Satin Clearcoat
            VALANCE, LOWER Genuine Aston Martin - New (to order)
            # 3
            MPN: HG3Y-17626-AA
            SPLITTER, RH
            Gloss Clearcoat
            from £4,847.89
            from £4,847.89
            SPLITTER, RH Genuine Aston Martin - New (to order)
            # 3
            MPN: HG3Y-17626-JA
            SPLITTER, RH
            Natural Carbon
            SPLITTER, RH Genuine Aston Martin - New (to order)
            # 3
            MPN: HG3Y-17626-LA
            SPLITTER, RH
            Satin Clearcoat
            SPLITTER, RH Genuine Aston Martin - New (to order)
            # 3
            MPN: HG3Y-17627-AA
            SPLITTER, LH
            Gloss Clearcoat
            from £4,944.86
            from £4,944.86
            SPLITTER, LH Genuine Aston Martin - New (to order)
            # 3
            MPN: HG3Y-17627-JA
            SPLITTER, LH
            Natural Carbon
            SPLITTER, LH Genuine Aston Martin - New (to order)
            # 3
            MPN: HG3Y-17627-LA
            SPLITTER, LH
            Satin Clearcoat
            SPLITTER, LH Genuine Aston Martin - New (to order)
            # 4
            MPN: HG3Y-8156-AA
            MESH, LOWER GRILLE
            from £495.82
            from £495.82
            MESH, LOWER GRILLE Genuine Aston Martin - New (to order)
            # 5
            MPN: HG3Y-F7080-AA
            BLANKING COVER
            RH
            from £150.32
            from £150.32
            BLANKING COVER Genuine Aston Martin - New (to order)
            # 5
            MPN: HG3Y-F7081-AA
            BLANKING COVER
            LH
            from £150.32
            from £150.32
            BLANKING COVER Genuine Aston Martin - New (to order)
            # 6
            MPN: HG3Y-10624-AA
            TAPE, LOWER VALANCE
            RH
            from £36.14
            from £36.14
            TAPE, LOWER VALANCE Genuine Aston Martin - New (to order)
            # 6
            MPN: HG3Y-10625-AA
            TAPE, LOWER VALANCE
            LH
            from £36.14
            from £36.14
            TAPE, LOWER VALANCE Genuine Aston Martin - New (to order)
            # 7
            MPN: 7G43-10609E-AA-PK
            NUT, U TYPE, M6
            Pack of 10
            from £5.08
            from £5.08
            CLIP SPG M6 PK OF 10 Genuine Aston Martin - New In stock
            FRONT UNDERTRAY CLIP Genuine Ferrari Part - New (to order)
            # 8
            MPN: 702514
            SCREW, M6X14, PAN HEAD
            from £0.56
            from £0.56
            SCREW M6 X 14 HD INT Genuine Aston Martin - New In stock
            FRONT UNDERTRAY BOLT Genuine Ferrari Part - New (to order)
            # 9
            MPN: 702839-PK
            SCREW AND WASHER, M6X 20
            Pack of 10
            from £3.22
            from £3.22
            SCREW&WSHR M6X20(10) Genuine Aston Martin - New (to order)
            # 10
            MPN: 703169
            NUT, M6
            from £0.71
            from £0.71
            This part replaces part number 703168
            NUT M6 HEX FLANGE Genuine Aston Martin - New (to order)
            # 11
            MPN: 702520-PK
            CLIP, BUMPER TO GRILLE
            Pack of 20
            from £2.42
            from £2.42
            CLIP 8.5X16X1.7 (20) Genuine Aston Martin - New (to order)
            FRONT BUMPER CLIP (SMALL) Genuine Ferrari Part - New (to order)
            # 12
            MPN: 4G43-46662-AA-PK
            WASHER, SPACING 2MM
            Pack of 10
            from £2.54
            from £2.54
            WASHER, SPACING 2MM Genuine Aston Martin - New (to order)
            # 13
            MPN: 703143
            SCREW, BUTTON TORX
            from £1.11
            from £1.11
            SCRW & WSHR-M6 X 12 Genuine Aston Martin - New (to order)
