aston martin v8 vantage (2009) front seat belts parts diagram

012001 - Front Seat Belts

Aston Martin V8 Vantage (2009) Front Seat Belts Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
            #
            Part number
            Description
            Key
            Price
            # 1
            MPN: 6G33-611B10-BE
            SEATBELT ANCHOR PLATE, UPPER RH, COUPE
            from £506.25
            from £506.25
            Genuine Aston Martin (no longer available to order)
            SEATBELT ANCHOR PLATE, UPPER RH, COUPE Genuine Aston Martin - Used In stock
            # 1
            MPN: 6G33-611B11-BE
            SEATBELT ANCHOR PLATE, UPPER LH, COUPE
            from £506.25
            from £506.25
            Genuine Aston Martin (no longer available to order)
            SEATBELT ANCHOR PLATE, UPPER LH, COUPE Genuine Aston Martin - Used In stock
            # 1
            MPN: 6G33-L611B10-BD
            SEATBELT ANCHOR PLATE, UPPER RH, ROADSTER
            SEATBELT ANCHOR PLATE, UPPER RH, ROADSTER Genuine Aston Martin - New (to order)
            # 1
            MPN: 6G33-L611B11-BD
            SEATBELT ANCHOR PLATE, UPPER LH, ROADSTER
            SEATBELT ANCHOR PLATE, UPPER LH, ROADSTER Genuine Aston Martin - New (to order)
            # 2
            MPN: 6G33-5784-AA
            PIN, RESTRAINING, FRONT SEATBELT
            from £10.21
            from £10.21
            PIN, RESTRAINING, FRONT SEATBELT Genuine Aston Martin - New (to order)
            # 3
            MPN: 703201
            SCREW, M8 X 30, 8 EACH SIDE
            from £0.47
            from £0.47
            SCREW M8X30 HEX FLNG Genuine Aston Martin - New (to order)
            # 4
            MPN: 6G33-611B68-ABW
            SEATBELT ASSY, RH, LHD
            Warm Charcoal
            from £663.29
            from £663.29
            SEATBELT ASSEMBLY, RH, LHD Genuine Aston Martin - New In stock
            # 4
            MPN: 6G33-611B68-BBW
            SEATBELT ASSY, RH, LHD
            Flint
            from £663.29
            from £663.29
            SEATBELT ASSEMBLY, RH, LHD Genuine Aston Martin - New (to order)
            # 4
            MPN: 6G33-611B71-ABW
            SEATBELT ASSY, RH, RHD
            Warm Charcoal
            from £663.29
            from £663.29
            SEATBELT ASSEMBLY, RH, RHD Genuine Aston Martin - New (to order)
            # 4
            MPN: 6G33-611B71-BBW
            SEATBELT ASSY, RH, RHD
            Flint
            from £609.95
            from £609.95
            SEATBELT ASSEMBLY, RH, RHD Genuine Aston Martin - New (to order)
            # 4
            MPN: 6G33-611B70-ACW
            SEATBELT ASSY, LH, LHD
            Warm Charcoal
            from £663.29
            from £663.29
            SEATBELT ASSEMBLY, LH, LHD Genuine Aston Martin - New (to order)
            # 4
            MPN: 6G33-611B70-BCW
            SEATBELT ASSY, LH, LHD
            Flint
            from £663.29
            from £663.29
            SEATBELT ASSEMBLY, LH, LHD Genuine Aston Martin - New (to order)
            # 4
            MPN: 6G33-611B69-ACW
            SEATBELT ASSY, LH, RHD
            Warm Charcoal
            from £331.65
            from £331.65
            SEATBELT ASSEMBLY, PASSENGER SIDE, RHD Genuine Aston Martin - New (to order)
            SEATBELT ASSEMBLY, PASSENGER SIDE, RHD Genuine Aston Martin - Used In stock
            # 4
            MPN: 6G33-611B69-BCW
            SEATBELT ASSY, LH, RHD
            Flint
            from £665.21
            from £665.21
            SEATBELT ASSEMBLY, PASSENGER SIDE, RHD Genuine Aston Martin - New (to order)
            # 5
            MPN: 6G33-60258-AA
            REINF, FRONT SEAT BELT, RH
            from £8.52
            from £8.52
            REINFORCEMENT , FRONT SEAT BELT, RH Genuine Aston Martin - New (to order)
            REINFORCEMENT , FRONT SEAT BELT, RH Genuine Aston Martin - Used In stock
            # 5
            MPN: 6G33-60259-AA
            REINF, FRONT SEAT BELT, LH
            from £7.74
            from £7.74
            REINFORCEMENT , FRONT SEAT BELT, LH Genuine Aston Martin - New (to order)
            REINFORCEMENT , FRONT SEAT BELT, LH Genuine Aston Martin - Used In stock
            # 6
            MPN: 6G33-610D36-AA
            PLATE, FRONT SEATBELT ANCHOR
            from £2.95
            from £2.95
            PLATE, FRONT SEATBELT ANCHOR Genuine Aston Martin - New (to order)
