aston martin v8 vantage (2009) actuation sensors parts diagram

012005-B1 - Actuation Sensors

Aston Martin V8 Vantage (2009) Actuation Sensors Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
        #
        Part number
        Description
        Key
        Price
        # 1
        MPN: 6G43-37-10240
        SENSOR ASSY, SIDE IMPACT, DOOR, ARS
        from £22.35
        from £22.35
        ARS SD IMP SENSOR Genuine Aston Martin - New (to order)
        ARS SD IMP SENSOR Genuine Aston Martin - Used In stock
        # 1
        MPN: 4G43-37-10260
        SENSOR ASSY, FRONT IMPACT, SIDE
        08MY
        from £69.29
        from £69.29
        SENSOR-OCC RESTRAINT Genuine Aston Martin - New (to order)
        SENSOR-OCC RESTRAINT Genuine Aston Martin - Used In stock
        # 2
        MPN: 4G43-37-10261
        SENSOR ASSY, FRONT IMPACT, UPPER FRONT
        08MY
        from £274.45
        from £274.45
        SENSOR ASSEMBLY, FRONT IMPACT, UPPER FRONT Genuine Aston Martin - New (to order)
        SENSOR ASSEMBLY, FRONT IMPACT, UPPER FRONT Genuine Aston Martin - Used In stock
        # 2
        MPN: 4G43-37-10932
        SENSOR ASSY, FRONT IMPACT
        09MY
        from £50.72
        from £50.72
        This part replaces part number 6G33-10853-AF which we have in stock
        SENSOR-ORS UPPER FRONT Genuine Aston Martin - New (to order)
        # 3
        MPN: 4G43-37-10260
        SENSOR ASSY, SIDE IMPACT, B PILLAR
        Upto Vin B10201 -08MY
        from £69.29
        from £69.29
        SENSOR-OCC RESTRAINT Genuine Aston Martin - New (to order)
        SENSOR-OCC RESTRAINT Genuine Aston Martin - Used In stock
        # 3
        MPN: 4G43-37-10931
        SENSOR ASSY, SIDE IMPACT, B PILLAR
        From Vin B10202 - 08MY
        from £32.98
        from £32.98
        SENSOR-OCC RESTRAINT Genuine Aston Martin - New (to order)
        # 4
        MPN: 6G43-37-10242
        MODULE, CONTROL ASSY, OCCUPANT RESTRAINT
        Coupe, To 09MY, P15
        from £180.14
        from £180.14
        MODULE, CONTROL ASSEMBLY, OCCUPANT RESTRAINT Genuine Aston Martin - New (to order)
        MODULE, CONTROL ASSEMBLY, OCCUPANT RESTRAINT Genuine Aston Martin - Used In stock
        # 4
        MPN: AD33-37-10112
        MODULE, CONTROL ASSY, OCCUPANT RESTRAINT
        Coupe, From 09MY, To 14MY, P14
        from £303.28
        from £303.28
        RCM P14 TYPE Genuine Aston Martin - New (to order)
        # 4
        MPN: DD33-14C246-AA
        MODULE, CONTROL ASSY, OCCUPANT RESTRAINT
        Coupe, From 14MY, P14
        from £568.97
        from £568.97
        HW MNTR AIR BAG RCM Genuine Aston Martin - New (to order)
        # 4
        MPN: 6G43-37-10242
        MODULE, CONTROL ASSY, OCCUPANT RESTRAINT
        Roadster, To 08MY, P15
        from £180.14
        from £180.14
        MODULE, CONTROL ASSEMBLY, OCCUPANT RESTRAINT Genuine Aston Martin - New (to order)
        MODULE, CONTROL ASSEMBLY, OCCUPANT RESTRAINT Genuine Aston Martin - Used In stock
        # 4
        MPN: 4G43-37-10930
        MODULE, CONTROL ASSY, OCCUPANT RESTRAINT
        Roadster, From 08MY To 14MY, P15
        from £387.41
        from £387.41
        MODULE, CONTROL ASSEMBLY, OCCUPANT RESTRAINT Genuine Aston Martin - New (to order)
        # 4
        MPN: CG43-37-11330
        MODULE, CONTROL ASSY, OCCUPANT RESTRAINT
        Roadster, From 14MY, P15
        from £483.83
        from £483.83
        MODULE-RESTRAINTS Genuine Aston Martin - New (to order)
        # 5
        MPN: 702522
        NUT, M5, 2 EACH SIDE
        from £0.47
        from £0.47
        M5 HEX FLANGE NUT Genuine Aston Martin - New (to order)
        # 6
        MPN: 702839-PK
        SCREW AND WASHER M6X20
        Pack of 10
        from £3.22
        from £3.22
        SCREW&WSHR M6X20(10) Genuine Aston Martin - New (to order)
        # 7
        MPN: 703199
        BOLT, M6X30 HEX FLG
        from £0.47
        from £0.47
        BOLT M6X30 HEX FLANGE Genuine Aston Martin - New (to order)
        # 8
        MPN: 702840
        NUT AND WASHER M6
        from £0.47
        from £0.47
        NUT/WASHER ASSEMBLY M6 Genuine Aston Martin - New (to order)
        # 9
        MPN: 700986-PK
        NUT, M4
        Pack of 20
        Supersession
        Supersession
        Genuine Aston Martin (no longer available to order)
