aston martin v8 vantage (2009) parking brake, rhd parts diagram

060500-C3 - Parking Brake, RHD

Aston Martin V8 Vantage (2009) Parking Brake, RHD Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                  #
                                  Part number
                                  Description
                                  Key
                                  Price
                                  # 1
                                  MPN: 4G43-8492-BB
                                  HANDBRAKE LEVER ASSEMBLY, RHD
                                  from £83.66
                                  from £83.66
                                  HANDBRAKE LEVER ASSEMBLY RHD Genuine Aston Martin - New (to order)
                                  HANDBRAKE LEVER ASSEMBLY RHD Genuine Aston Martin - Used In stock
                                  # 2
                                  MPN: 37-84687
                                  SWITCH, HANDBRAKE
                                  from £211.30
                                  from £211.30
                                  SWITCH, HANDBRAKE Genuine Aston Martin - New (to order)
                                  # 3
                                  MPN: 4G43-2A686-BB
                                  BRACKET ASSEMBLY, RHD
                                  from £259.90
                                  from £259.90
                                  BRACKET ASSEMBLY P/BRK LVR Genuine Aston Martin - New (to order)
                                  BRACKET ASSEMBLY P/BRK LVR Genuine Aston Martin - Used In stock
                                  # 4
                                  MPN: 6G33-2853-AC
                                  CABLE & CONDUIT ASSEMBLY
                                  from £111.03
                                  from £111.03
                                  CABLE & CONDUIT ASSEMBLY Genuine Aston Martin - New (to order)
                                  CABLE & CONDUIT ASSEMBLY Genuine Aston Martin - Used In stock
                                  # 5
                                  MPN: 6G33-439136-AA
                                  TRUNNION, H/BRAKE CABLE TO LEVER
                                  from £1.35
                                  from £1.35
                                  TRUNNION, HANDBRAKE CABLE Genuine Aston Martin - New (to order)
                                  # 6
                                  MPN: 7G43-2K605-AA
                                  PIVOT PIN, H/BRAKE CABLE TO LEVER
                                  from £1.21
                                  from £1.21
                                  PIVOT PIN, H/BRAKE CABLE TO LEVER Genuine Aston Martin - New (to order)
                                  # 7
                                  MPN: 6G33-100063-AA-PK
                                  PUSH ON FIX- 6MM SHAFT
                                  from £7.71
                                  from £7.71
                                  PUSH ON FIX, H/BRAKE CABLE TO LEVER Genuine Aston Martin - New (to order)
                                  # 8
                                  MPN: 7G43-2C464-BB
                                  KIT, HANDBRAKE CALIPER REPL, RH
                                  PAINTED
                                  from £237.72
                                  from £237.72
                                  KIT, HANDBRAKE CALIPER REPL, RH Genuine Aston Martin - New (to order)
                                  # 8
                                  MPN: 7G43-2C464-BC
                                  KIT, HANDBRAKE CALIPER REPL, RH
                                  Anodised
                                  from £209.02
                                  from £209.02
                                  KIT, HANDBRAKE CALIPER REPL, RH Genuine Aston Martin - New (to order)
                                  # 8
                                  MPN: 7G43-2C465-BB
                                  KIT, HANDBRAKE CALIPER REPL, LH
                                  PAINTED
                                  from £118.86
                                  from £118.86
                                  KIT, HANDBRAKE CALIPER REPL, LH Genuine Aston Martin - New (to order)
                                  KIT, HANDBRAKE CALIPER REPL, LH Genuine Aston Martin - Used In stock
                                  Painted purple
                                  # 8
                                  MPN: 7G43-2C465-BC
                                  KIT, HANDBRAKE CALIPER REPL, LH
                                  Anodised
                                  from £209.02
                                  from £209.02
                                  KIT, HANDBRAKE CALIPER REPL, LH Genuine Aston Martin - New (to order)
                                  # 9
                                  MPN: 4G43-2C564-CA
                                  BOLT, FLG, M10X87
                                  Caliper to Hub
                                  from £1.83
                                  from £1.83
                                  BOLT-M10X87 HEX FLNG Genuine Aston Martin - New (to order)
                                  # 10
                                  MPN: 4G43-2C562-BA
                                  PAD SET, (PER AXLE)
                                  Supersession
                                  Supersession
                                  Genuine Aston Martin (no longer available to order)
                                  # 11
                                  MPN: 4G43-2B296-BA
                                  PIN, PAD RETAINING, 1 PER CALIPER
                                  from £38.44
                                  from £38.44
                                  PIN, PAD RETAINING, 1 PER CALIPER Genuine Aston Martin - New (to order)
                                  # 12
                                  MPN: 4G43-224259-BA
                                  SPRING, ANTI RATTLE
                                  from £41.18
                                  from £41.18
                                  SPRING, ANTI-RATTLE Genuine Aston Martin - New (to order)
                                  # 13
                                  MPN: 694891
                                  P-CLIP
                                  from £2.37
                                  from £2.37
                                  P-CLIP Genuine Aston Martin - New (to order)
                                  # 14
                                  MPN: 702282
                                  CLIP, 16-18.5X6.5X1-6
                                  from £0.77
                                  from £0.77
                                  CLIP 16-18 5X6 5X1-6 Genuine Aston Martin - New (to order)
                                  # 15
                                  MPN: 703121
                                  SCREW, M8 HEX FLG HD
                                  from £0.47
                                  from £0.47
                                  SCREW M8X20 HEX FLANGE Genuine Aston Martin - New (to order)
                                  # 16
                                  MPN: 4G43-2A686-BB
                                  BRACKET ASSEMBLY RHD
                                  from £259.90
                                  from £259.90
                                  BRACKET ASSEMBLY P/BRK LVR Genuine Aston Martin - New (to order)
                                  BRACKET ASSEMBLY P/BRK LVR Genuine Aston Martin - Used In stock
                                  # 17
                                  MPN: 37-84687
                                  SWITCH, HANDBRAKE
                                  from £211.30
                                  from £211.30
                                  SWITCH, HANDBRAKE Genuine Aston Martin - New (to order)
                                  # -
                                  -
                                  GROMMET, BLANKING
                                  # -
                                  -
                                  PLUG, BLANKING, M8
                                  # -
                                  -
                                  BOOT, SLIDING PIN
                                  # -
                                  -
                                  NUT, FLG, M6, P CLIP ATTCH
                                  # -
                                  -
                                  SCREW, FLG, M6X20
