aston martin v8 vantage (2009) air con lines, hfo1234yf gas, lhd parts diagram

120305-20 - Air Con Lines, HFO1234yf Gas, LHD

Aston Martin V8 Vantage (2009) Air Con Lines, HFO1234yf Gas, LHD Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                                                  #
                                                                                  Part number
                                                                                  Description
                                                                                  Key
                                                                                  Price
                                                                                  # 1
                                                                                  MPN: HG33-19A705-BA
                                                                                  TUBE, ASSY, AIRCON EVAP OUTLET, LH
                                                                                  from £121.09
                                                                                  from £121.09
                                                                                  TUBE, ASSEMBLY, AIRCON EVAPORATOR OUTLET, LH Genuine Aston Martin - New (to order)
                                                                                  # 1a
                                                                                  MPN: HD23-32117-AA
                                                                                  EPDM O RING, 13.40X2.40
                                                                                  from £3.49
                                                                                  from £3.49
                                                                                  EPDM O RING, 13.40X2.40 Genuine Aston Martin - New (to order)
                                                                                  # 1b
                                                                                  MPN: HD23-49745-AA
                                                                                  EPDM O RING, 12.93X1.86
                                                                                  from £5.03
                                                                                  from £5.03
                                                                                  O RING, 12.93X1.86 Genuine Aston Martin - New (to order)
                                                                                  # 4
                                                                                  MPN: 703199
                                                                                  BOLT, M6X30
                                                                                  from £0.47
                                                                                  from £0.47
                                                                                  BOLT M6X30 HEX FLANGE Genuine Aston Martin - New (to order)
                                                                                  # 5
                                                                                  MPN: 702291
                                                                                  CLIP, A/C PIPE TO WIPER LINKAGE
                                                                                  from £0.94
                                                                                  from £0.94
                                                                                  CLIP 11-18X6.5X7 Genuine Aston Martin - New (to order)
                                                                                  # 6
                                                                                  MPN: 699699
                                                                                  CLIP, 16X15
                                                                                  from £1.34
                                                                                  from £1.34
                                                                                  P CLIP - 16 Genuine Aston Martin - New (to order)
                                                                                  # 7
                                                                                  MPN: 700606
                                                                                  SCREW, M6X12
                                                                                  from £0.47
                                                                                  from £0.47
                                                                                  SCREW M6X12 FLANGE Genuine Aston Martin - New (to order)
                                                                                  # 8
                                                                                  MPN: HG33-19A705-AA
                                                                                  TUBE ASSY, EVAP OUTLET, LH
                                                                                  from £84.20
                                                                                  from £84.20
                                                                                  TUBE ASSEMBLY, EVAPORATOR TO PUMP, LOWER Genuine Aston Martin - New (to order)
                                                                                  # 8a
                                                                                  MPN: HD23-32117-AA
                                                                                  EPDM O RING, 13.40X2.40
                                                                                  from £3.49
                                                                                  from £3.49
                                                                                  EPDM O RING, 13.40X2.40 Genuine Aston Martin - New (to order)
                                                                                  # 10
                                                                                  MPN: 703203
                                                                                  SCREW, M6X20
                                                                                  from £0.47
                                                                                  from £0.47
                                                                                  SCREW M6X20 HEX FLNG Genuine Aston Martin - New (to order)
                                                                                  LOWER RADIATOR SUPPORT BOLT Genuine Ferrari Part - New (to order)
                                                                                  # 11
                                                                                  MPN: 703025
                                                                                  SCREW, M6X25
                                                                                  from £0.47
                                                                                  from £0.47
                                                                                  SCREW M6X1.0X25 HEX Genuine Aston Martin - New (to order)
                                                                                  # 12
                                                                                  MPN: HG33-19972-AA
                                                                                  TUBE ASSY, COMPR TO CONDENSER
                                                                                  from £336.78
                                                                                  from £336.78
                                                                                  This part replaces part number 6G33-19972-AH which we have in stock
                                                                                  TUBE ASSEMBLY, COMPRESSOR TO CONDENSER Genuine Aston Martin - New (to order)
                                                                                  # 12a
                                                                                  MPN: HD23-99542-AA
                                                                                  EPDM O RING, 13.75X2.5
                                                                                  from £4.15
                                                                                  from £4.15
                                                                                  EPDM O RING, 13.75X2.5 Genuine Aston Martin - New (to order)
                                                                                  # 12b
                                                                                  MPN: HD23-87072-AA
                                                                                  EPDM O RING, 9.19X2.62
                                                                                  from £4.15
                                                                                  from £4.15
                                                                                  EPDM O-RING Genuine Aston Martin - New (to order)
                                                                                  # 14
                                                                                  MPN: 699634
                                                                                  CLIP, 13MM
                                                                                  from £1.29
                                                                                  from £1.29
                                                                                  P-CLIP 13X15XM6 Genuine Aston Martin - New (to order)
                                                                                  # 15
                                                                                  MPN: HG33-19D719-AA
                                                                                  TUBE ASSY, A/C DEHY INLET
                                                                                  from £92.33
                                                                                  from £92.33
                                                                                  This part replaces part number 6G33-19D719-AB which we have in stock
                                                                                  TUBE ASSEMBLY, CONDENSER TO RECEIVER/DRIER Genuine Aston Martin - New (to order)
                                                                                  # 15a
                                                                                  MPN: HD23-87056-AA
                                                                                  EPDM O RING, 6.5X2.62
                                                                                  from £4.15
                                                                                  from £4.15
                                                                                  O RINGS, RECEIVER / DRIER Genuine Aston Martin - New (to order)
                                                                                  # 15b
                                                                                  MPN: HD23-87024-AA
                                                                                  EPDM O RING, 6.7X1.80
                                                                                  from £4.15
                                                                                  from £4.15
                                                                                  EPDM O-RING Genuine Aston Martin - New (to order)
                                                                                  # 17
                                                                                  MPN: 703201
                                                                                  SCREW, M8X30
                                                                                  from £0.47
                                                                                  from £0.47
                                                                                  SCREW M8X30 HEX FLNG Genuine Aston Martin - New (to order)
                                                                                  # 18
                                                                                  MPN: 701180
                                                                                  CLIP
                                                                                  from £0.82
                                                                                  from £0.82
                                                                                  CLIP 14.0X4.0 PUSHIN Genuine Aston Martin - New (to order)
                                                                                  # 21
                                                                                  MPN: HG33-19835-BA
                                                                                  TUBE, DEHY TO EVAP, LHD
                                                                                  from £197.81
                                                                                  from £197.81
                                                                                  TUBE, RECEIVER/DRYER TO EVAPORATOR Genuine Aston Martin - New (to order)
                                                                                  # 22
                                                                                  MPN: 702944
                                                                                  NUT, M6
                                                                                  from £0.58
                                                                                  from £0.58
                                                                                  NUT M6 HEX FLNG MTL8 Genuine Aston Martin - New (to order)
                                                                                  LOWER MESH NUTS Genuine Ferrari Part - New (to order)
                                                                                  # 23
                                                                                  MPN: 6G33-6C778-BA
                                                                                  ISOLATOR, OIL MOUNTING BUFFER
                                                                                  from £13.46
                                                                                  from £13.46
                                                                                  ISOLATOR - BUFFER Genuine Aston Martin - New (to order)
                                                                                  # 24
                                                                                  MPN: 1R12-89-10192
                                                                                  A/C SWITCH, HIGH PRESSURE
                                                                                  from £165.55
                                                                                  from £165.55
                                                                                  A/C SWITCH-HIGH PRES Genuine Aston Martin - New (to order)
                                                                                  A/C SWITCH-HIGH PRES Genuine Aston Martin - Used In stock
                                                                                  # 24a
                                                                                  MPN: HD23-100501-AA
                                                                                  EPDM O RING, 10.82X1.78
                                                                                  from £3.01
                                                                                  from £3.01
                                                                                  EPDM O RING, 10.82X1.78 Genuine Aston Martin - New (to order)
                                                                                  # 25
                                                                                  MPN: AG43-89-11295
                                                                                  SWITCH ASSEMBLY, A/C PRESSURE CUT-OFF
                                                                                  from £272.88
                                                                                  from £272.88
                                                                                  This part replaces part number 6F93-19D594-AA which we have in stock - and 1 more. Click to view details
                                                                                  SWITCH ASSEMBLY, PRESSURE CUT-OFF Genuine Aston Martin - New (to order)
                                                                                  SWITCH ASSEMBLY, PRESSURE CUT-OFF Genuine Aston Martin - Used In stock
                                                                                  # 25a
                                                                                  MPN: HD23-100403-AA
                                                                                  EPDM O RING, 7.65X1.79
                                                                                  from £5.03
                                                                                  from £5.03
                                                                                  EPDM O RING, 7.65X1.79 Genuine Aston Martin - New (to order)
                                                                                  # 26
                                                                                  MPN: HD23-18D487-AB
                                                                                  TUBE ASSEMBLY, A/C IHX LHD
                                                                                  from £170.23
                                                                                  from £170.23
                                                                                  TUB ASSEMBLY A/C IHX OLET Genuine Aston Martin - New (to order)
                                                                                  # 27
                                                                                  MPN: HD23-19N649-AA
                                                                                  TUBE ASSEMBLY, A/C IHX INLET LHD
                                                                                  from £140.36
                                                                                  from £140.36
                                                                                  TUBE ASSEMBLY, A/C IHX INLET LHD Genuine Aston Martin - New (to order)
                                                                                  # 27a
                                                                                  MPN: HD23-87071-AA
                                                                                  EPDM O RING, 10.8X2.40
                                                                                  from £4.15
                                                                                  from £4.15
                                                                                  EPDM O-RING Genuine Aston Martin - New (to order)
                                                                                  # 27b
                                                                                  MPN: HD23-87072-AA
                                                                                  EPDM O RING, 9.19X2.62
                                                                                  from £4.15
                                                                                  from £4.15
                                                                                  EPDM O-RING Genuine Aston Martin - New (to order)
                                                                                  # 28
                                                                                  MPN: 703163
                                                                                  NUT, M6 FLG LOCKING
                                                                                  from £0.47
                                                                                  from £0.47
                                                                                  NUT M6 FLANGE LOCKING Genuine Aston Martin - New (to order)
                                                                                  # 29
                                                                                  MPN: HG33-19D602-AA
                                                                                  TUBE ASSEMBLY, A/C EVAP OUTLET LHD (SUCTION)
                                                                                  from £137.10
                                                                                  from £137.10
                                                                                  TUBE ASSEMBLY, A/C EVAPORATOR OUTLET LHD (SUCTION) Genuine Aston Martin - New (to order)
                                                                                  # 29a
                                                                                  MPN: HD23-32117-AA
                                                                                  EPDM O RING, 13.40X2.40
                                                                                  from £3.49
                                                                                  from £3.49
                                                                                  EPDM O RING, 13.40X2.40 Genuine Aston Martin - New (to order)
                                                                                  # 29b
                                                                                  MPN: HD23-19394-AA
                                                                                  EPDM O RING, 16.25X2.50
                                                                                  from £5.14
                                                                                  from £5.14
                                                                                  EPDM O-RING Genuine Aston Martin - New (to order)
                                                                                  # 30
                                                                                  MPN: HG33-19D603-AA
                                                                                  TUBE ASSEMBLY, A/C EVAP INLET LHD (LIQUID)
                                                                                  from £139.84
                                                                                  from £139.84
                                                                                  TUBE ASSEMBLY, A/C EVAPORATOR INLET LHD (LIQUID) Genuine Aston Martin - New (to order)
                                                                                  # 30a
                                                                                  MPN: HD23-87024-AA
                                                                                  EPDM O RING, 6.70X1.80
                                                                                  from £4.15
                                                                                  from £4.15
                                                                                  EPDM O-RING Genuine Aston Martin - New (to order)
                                                                                  # 30b
                                                                                  MPN: HD23-87072-AA
                                                                                  EPDM O RING, 9.19X2.62
                                                                                  from £4.15
                                                                                  from £4.15
                                                                                  EPDM O-RING Genuine Aston Martin - New (to order)
                                                                                  # 31
                                                                                  MPN: 703265
                                                                                  SCREW, M6X16 HEX HD
                                                                                  from £0.47
                                                                                  from £0.47
                                                                                  SCREW M6X16 HEX HD Genuine Aston Martin - New (to order)
