aston martin v8 vantage (2009) tyre pressure module parts diagram

191001-D3 - Tyre Pressure Module

Aston Martin V8 Vantage (2009) Tyre Pressure Module Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
            #
            Part number
            Description
            Key
            Price
            # 1
            MPN: 4R12-370807-AC
            MODULE, TYRE PRESSURE MONITOR
            07MY
            from £250.10
            from £250.10
            MODULE, TYRE PRESSURE MONITORING ECU Genuine Aston Martin - New (to order)
            MODULE, TYRE PRESSURE MONITORING ECU Genuine Aston Martin - Used In stock
            # 1
            MPN: 8G43-370807-BA
            MODULE, TYRE PRESSURE MONITOR
            08MY From (V) D07649
            Supersession
            Supersession
            Genuine Aston Martin (no longer available to order)
            # 1
            MPN: AD43-370807-AA
            MODULE, TYRE PRESSURE MONITOR
            11MY
            MODULE, TYRE PRESSURE MONITOR Genuine Aston Martin - New (to order)
            # 2
            MPN: 6G33-10E887-GA
            BRACKET, TYRE PRESS MONITOR, LHD/ RHD
            early vehicles
            BRACKET, TYRE PRESS MONITOR, LHD/ RHD Genuine Aston Martin - New (to order)
            # 2
            MPN: 7G43-370807-AA
            BRACKET, TYRE PRESS MONITOR, LHD/ RHD
            08MY
            BRACKET ASSEMBLY TPM Genuine Aston Martin - New (to order)
            # 3
            MPN: 701196
            SCREW, M6 X 16, BRACKET TO BODY
            SCREW / WASHER M6X16 Genuine Aston Martin - New (to order)
            # 3
            MPN: 4G43-201022-AA
            SCREW, NO6 X 1/2" MODULE TO BRCKT
            SCREW, NO6 X 1/2 INCH MODULE TO BRCKT Genuine Aston Martin - New (to order)
            # 4
            MPN: 700018
            WASHER M4 SPRF, MOD TO BRCKT
            from £0.47
            from £0.47
            WASHER, SPRF, M4 Genuine Aston Martin - New (to order)
            # -
            -
            SCREW, NO6 X 1/2" MODULE TO BRCKT
            # 5
            MPN: 4G43-46030-AA
            SCREW, THUMBSCREW, 6 UNC
            from £1.21
            from £1.21
            THUMB SCREW Genuine Aston Martin - New (to order)
            # 6
            MPN: 8G43-14A163-BA
            CLIP, HARNESS
            from £0.67
            from £0.67
            CLIP, HARNESS Genuine Aston Martin - New (to order)
