2.4 - VACUUM SYSTEM
Aston Martin V8 Virage (2000) Vacuum System Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 1
MPN: 08-52975
Mounting bracket assembly, carbon canister
from £26.99
from £26.99
# -
-
SCREW, M6 X 25
Clamp ring fixing
# -
-
NUT, NYLOC, M6
Clamp ring fixing
# -
-
WASHER, PLAIN, M6
Clamp ring fixing
# 2
MPN: 693962
SCREW, M6 X 25
Bracket to mounting
from £1.29
from £1.29
# 3
MPN: 692056
WASHER, PLAIN, M6
Bracket to mounting
from £0.47
from £0.47
# 4
MPN: 692580
WASHER, SPRING, M6
Bracket to mounting
from £0.47
from £0.47
# 5
MPN: 097-034-0116
CARBON CANISTER
from £93.56
from £93.56
# 6
MPN: 34-15188
DRAIN CAP
from £2.05
from £2.05
# 7
MPN: 692643
VACUUM HOSE, 11/32 ID
Bottom cap
from £36.54
from £36.54
# 8
MPN: 692236
TUBING, NYLAFLEX, 55MM LONG
from £12.58
from £12.58
# 9
MPN: 097-034-0118
Adaptor, carbon canister to tank line
from £12.99
from £12.99
# 10
MPN: 692235
BREATHER TUBE, TANK LINE
3000mm long
from £6.23
from £6.23
# -
-
GROMMET, 3/8
# 11
MPN: 692525
P' CLIP, 1/4 NYLON, TANK LINE
from £0.47
from £0.47
# 12
MPN: 694791
CLIP, SELF ADHESIVE, TANK LINE
from £1.31
from £1.31
# 13
MPN: 694836
GROMMET, 1/4 ID
Bulkhead holes
from £0.47
from £0.47
# 14
MPN: 692307
HOSE
from £26.01
from £26.01
# 15
MPN: 08-55366
Nipple, 3/8 BSP, Plenum base to purge line
# 15
MPN: 08-55718
Nipple, 1/4 BSP, Plenum base to purge line
From January 1992
from £20.58
from £20.58
# 16
MPN: 692671
O' CLIP
from £1.15
from £1.15
# 17
MPN: 692546
TUBE, NYLON, 1/8 DIA X 1600MM
Reducer to 'Y'
from £8.13
from £8.13
# 18
MPN: 08-54411
ABSOLUTE PRESSURE SENSOR
# 19
MPN: 08-26637
MOUNTING BRACKET ASSY, ABSOLUTE PRESSURE SENSOR
from £50.53
from £50.53
# 20
MPN: 692088
SCREW, M6 X 16, A.P.S BRACKET TO BULKHEAD
Up to Feb 1993
from £0.47
from £0.47
# 20
MPN: 692267
SCREW, M6 X 30, A.P.S BRACKET TO BULKHEAD
From Feb 1993
from £0.67
from £0.67
# -
-
SPACER, A.P.S BRACKET TO BULKHEAD
From Feb 1993
# 21
MPN: 692046
WASHER, SPRING, M6, A.P.S BRACKET TO BULKHEAD
from £0.47
from £0.47
# 22
MPN: 692762
WASHER, PLAIN, M6, A.P.S BRACKET TO BULKHEAD
from £0.47
from £0.47
# 23
MPN: 692088
SCREW, M6 X 16, A.P.S TO MOUNTING BRACKET
from £0.47
from £0.47
# 24
MPN: 692046
WASHER, SPRING, M6, A.P.S TO MOUNTING BRACKET
from £0.47
from £0.47
# 25
MPN: 692762
WASHER, PLAIN, M6, A.P.S TO MOUNTING BRACKET
from £0.47
from £0.47
# 26
MPN: 692546
TUBE, POLYVON, 1/8 DIA.
A.P.S. to 'Y' connection
from £8.13
from £8.13
# 27
MPN: 08-21068
Y' connection
# 28
MPN: 692546
TUBE, POLYVON, 1/8 DIA.
Y' connection to plenum
from £8.13
from £8.13
# 29
MPN: 691504
TUBE, WHITE POLYVON
Fuel pressure regulator to plenum
# 30
MPN: 89-26545
VACUUM VALVE, AIR INJECTION
Unleaded fuel engine
from £13.62
from £13.62
# 31
MPN: 07-53228
MOUNTING BRACKET, VACUUM VALVE
Unleaded fuel engine
from £56.47
from £56.47
# 32
MPN: 692546
TUBE, POLYVON, 1/8 DIA, VAC VALVE TO CARBON CAN 'Y'
Unleaded fuel engine
from £8.13
from £8.13
# 33
MPN: 692546
TUBE, POLYVON, 1/8 DIA, VACUUM VALVE TO PLENUM
Unleaded fuel engine
from £8.13
from £8.13
# 34
MPN: 08-21067
TEE PIECE, 4-4-4, PLENUM TO VACUUM VALVE
Unleaded fuel engine
from £2.55
from £2.55
# -
-
TUBE, POLYVON, 1/8 DIA, 'Y' TO 'Y'
Unleaded fuel engine
# 35
MPN: 692181
TEE PIECE, NYLON, 10-10-10
from £4.89
from £4.89
# 36
MPN: 692643
VACUUM HOSE, 11/32 ID X 7.1/2 LONG
Engine to valve
from £36.54
from £36.54
# 37
MPN: 692643
VACUUM HOSE, 11/32 ID X 6.1/2 LONG
Valve to tee piece
from £36.54
from £36.54
# 38
MPN: 692643
VACUUM HOSE, 11/32 ID X 38 LONG RHD
Vacuum tank to tee piece
from £36.54
from £36.54
# 39
MPN: 692643
VACUUM HOSE, 11/32 ID X 9 LONG RHD
Tee piece to tee piece
from £36.54
from £36.54
# 40
MPN: 692643
VACUUM HOSE, 11/32 ID X 10 LONG RHD
Servo to tee piece
from £36.54
from £36.54
# 40
MPN: 692643
VACUUM HOSE, 11/32 ID X 16 LONG LHD
Servo to tee piece
from £36.54
from £36.54
# 41
MPN: 692645
HOSE CLIP, 'OETIKER' TYPE
from £1.26
from £1.26
# 42
MPN: 692634
HOSE CLIP, 12 - 22 MM
RHD - 5 used on LHD
from £1.23
from £1.23
# 43
MPN: 33-16743
NON-RETURN VALVE, ENGINE TO VACUUM PIPE
from £85.60
from £85.60
# 44
MPN: 692446
TEE PIECE, NYLON, 10-6-10
from £8.41
from £8.41
# 45
MPN: 692644
VACUUM HOSE, 7/32 ID X 7 LONG, TEE TO VALVE
from £27.80
from £27.80
# 46
MPN: 692644
VACUUM HOSE, 7/32 ID X 3 LONG, VALVE TO REDUCER
from £27.80
from £27.80
# 47
MPN: 692732
STRAIGHT REDUCER, 6MM - 4MM
from £4.39
from £4.39
# 48
MPN: 694657
NON-RETURN VALVE
from £76.92
from £76.92
# 49
MPN: 693168
HOSE CLIP, 'OETIKER' TYPE
from £0.92
from £0.92
# 50
MPN: 692546
TUBE, POLYVON, 1/8 DIA X 3 LONG, TANK TO REDUCER
RHD
from £8.13
from £8.13
# 50
MPN: 692546
TUBE, POLYVON, 1/8 DIA X 32 LONG, TANK TO REDUCER
LHD
from £8.13
from £8.13
# 51
MPN: 069-033-0168
BANJO
from £54.17
from £54.17
# 52
MPN: 022-033-0202
Washer, copper
from £1.90
from £1.90
# 53
MPN: 08-26434
BANJO BOLT ASSEMBLY
from £47.21
from £47.21
# 54
MPN: 08-26227
ASSEMBLY, CHOKE UNION TO A.P.S.
from £60.28
from £60.28
# 55
MPN: 08-21079
CHOKE UNION ASSEMBLY
from £44.52
from £44.52
# 56
MPN: 095-033-0161
Washer, copper
# 57
MPN: 693060
VACUUM RESERVOIR TANK
from £115.94
from £115.94
# 58
MPN: 692262
SCREW, M6 X 12, VACUUM TANK TO WHEELARCH
from £0.47
from £0.47
# 59
MPN: 692056
WASHER, PLAIN, M6, VACUUM TANK TO WHEELARCH
from £0.47
from £0.47
# -
-
Rivnut, M6, vacuum tank to wheelarch
# 60
MPN: 692546
TUBE, POLYVON, 1/8 X 90, VACUUM RESVR TO A/C UNIT
from £8.13
from £8.13
# -
-
P' CLIP, NYLON, 3/16, TUBE SUPPORT
# -
-
SCREW, NO 6 X 1/2, TUBE SUPPORT
# -
-
PIPE, VACUUM TANK TO SERVO LHD
Virage. Volante up to app (V) 60192
# -
-
PIPE, VACUUM TANK TO SERVO LHD
Volante from approx (V) 60193
# -
-
P' CLIP, NYLON, 3/8 PIPE SUPPORT
# -
-
SCREW, NO 6 X 1/2 PIPE SUPPORT
# -
-
VACUUM HOSE, 11/32 ID X 30 LONG LHD
Vacuum tank to bulkhead pipe
# -
-
VACUUM HOSE, 11/32 ID X 13 LONG LHD
Vacuum pipe to tee piece
# -
-
GROMMET
Automatic cars
# -
-
SLEEVING, 12 MM, VACUUM PIPE PROTECTION
Automatic cars
# -
-
ELBOW
Automatic cars
# -
-
TEE PIECE, 6-6-6
Automatic cars
# 61
MPN: 08-64407
RESTRICTOR, INSIDE HOSE, ITEM 14, AT CARBON CAN END
Volante from (V) 60120 & 60106
from £28.12
from £28.12
-part-diagram-2.5a.webp "ASTON MARTIN V8 VIRAGE (2000) ELECTRONIC FUEL INJECTION, TO VIN 60224 PARTS DIAGRAM")
-part-diagram-2.5b.webp "ASTON MARTIN V8 VIRAGE (2000) ELECTRONIC FUEL INJECTION, VOLANTE, VIN 69225 ON PARTS DIAGRAM")
-part-diagram-2.6.webp "ASTON MARTIN V8 VIRAGE (2000) FUEL SYSTEM PARTS DIAGRAM")
-part-diagram-2.7a.webp "ASTON MARTIN V8 VIRAGE (2000) EXHAUST SYSTEM, EARLY CARS PARTS DIAGRAM")
-part-diagram-2.7b.webp "ASTON MARTIN V8 VIRAGE (2000) EXHAUST SYSTEM, VOLANTE, 1993 TO VIN 60224 PARTS DIAGRAM")
-part-diagram-2.7c.webp "ASTON MARTIN V8 VIRAGE (2000) EXHAUST SYSTEM, VOLANTE, VIN 69225 ON PARTS DIAGRAM")
-part-diagram-3.10.webp "ASTON MARTIN V8 VIRAGE (2000) HYPOID UNIT PARTS DIAGRAM")
-part-diagram-3.11.webp "ASTON MARTIN V8 VIRAGE (2000) HYPOID MOUNTING PARTS DIAGRAM")
-part-diagram-3.12.webp "ASTON MARTIN V8 VIRAGE (2000) DRIVESHAFT & HUB ASSEMBLY PARTS DIAGRAM")
-part-diagram-3.1a.webp "ASTON MARTIN V8 VIRAGE (2000) TORQUE CONVERTER, TO APPROX VIN 60042 PARTS DIAGRAM")
-part-diagram-3.1b.webp "ASTON MARTIN V8 VIRAGE (2000) AUTOMATIC PARTS DIAGRAM")
-part-diagram-3.2a.webp "ASTON MARTIN V8 VIRAGE (2000) AUTOMATIC TRANSMISSION, GEARBOX COOLING, TO APPROX VIN 60042 PARTS DIAGRAM")
-part-diagram-3.2b.webp "ASTON MARTIN V8 VIRAGE (2000) AUTOMATIC TRANSMISSION, GEARBOX COOLING, APPROX VIN 60043 TO APPROX VIN 60192 PARTS DIAGRAM")
-part-diagram-3.2c.webp "ASTON MARTIN V8 VIRAGE (2000) AUTOMATIC TRANSMISSION, GEARBOX COOLING, FROM APPROX VIN 60193 PARTS DIAGRAM")
-part-diagram-3.3a.webp "ASTON MARTIN V8 VIRAGE (2000) 3 SPEED SELECTOR ASSEMBLY, TO APPROX VIN 60042 PARTS DIAGRAM")
-part-diagram-3.3b1.webp "ASTON MARTIN V8 VIRAGE (2000) 4 SPEED SELECTOR ASSEMBLY, VOLANTE, APPROX VIN 60043 ON PARTS DIAGRAM")
-part-diagram-3.3b2.webp "ASTON MARTIN V8 VIRAGE (2000) 4 SPEED SELECTOR, GEAROX LINKAGE, VOLANTE, APPROX VIN 60043 ON PARTS DIAGRAM")
-part-diagram-3.4a.webp "ASTON MARTIN V8 VIRAGE (2000) 3 SPEED GEARCASE & GEARTRAIN PARTS DIAGRAM")
-part-diagram-3.4b.webp "ASTON MARTIN V8 VIRAGE (2000) 4 SPEED GEARCASE & GEARTRAIN PARTS DIAGRAM")
-part-diagram-3.5a.webp "ASTON MARTIN V8 VIRAGE (2000) 3 SPEED VALVE BODY, SUMP & PROPSHAFT PARTS DIAGRAM")
-part-diagram-3.5b.webp "ASTON MARTIN V8 VIRAGE (2000) 4 SPEED VALVE BODY, SUMP & PROPSHAFT PARTS DIAGRAM")
-part-diagram-3.6.webp "ASTON MARTIN V8 VIRAGE (2000) CLUTCH & FLYWHEEL PARTS DIAGRAM")
-part-diagram-3.7.webp "ASTON MARTIN V8 VIRAGE (2000) CLUTCH HYDRAULICS PARTS DIAGRAM")
-part-diagram-3.8.webp "ASTON MARTIN V8 VIRAGE (2000) MANUAL GEARBOX, CASING & SELECTOR PARTS DIAGRAM")
-part-diagram-3.9.webp "ASTON MARTIN V8 VIRAGE (2000) MANUAL GEARBOX, GEARTRAIN & PROPSHAFT PARTS DIAGRAM")
-part-diagram-4.1.webp "ASTON MARTIN V8 VIRAGE (2000) REAR SUSPENSION PARTS DIAGRAM")
-part-diagram-4.2.webp "ASTON MARTIN V8 VIRAGE (2000) FRONT SUSPENSION PARTS DIAGRAM")
-part-diagram-4.3a.webp "ASTON MARTIN V8 VIRAGE (2000) STEERING COLUMN PARTS DIAGRAM")
-part-diagram-4.3a.1.webp "ASTON MARTIN V8 VIRAGE (2000) STEERING COLUMN, 1993 ON PARTS DIAGRAM")
-part-diagram-4.4.webp "ASTON MARTIN V8 VIRAGE (2000) POWER STEERING PARTS DIAGRAM")
-part-diagram-5.1a.webp "ASTON MARTIN V8 VIRAGE (2000) FRONT BRAKES PARTS DIAGRAM")
-part-diagram-5.1b.webp "ASTON MARTIN V8 VIRAGE (2000) FRONT BRAKES, VOLANTE ONLY PARTS DIAGRAM")
-part-diagram-5.2.webp "ASTON MARTIN V8 VIRAGE (2000) REAR BRAKES PARTS DIAGRAM")
-part-diagram-5.3.webp "ASTON MARTIN V8 VIRAGE (2000) HANDBRAKE PARTS DIAGRAM")
-part-diagram-5.4.webp "ASTON MARTIN V8 VIRAGE (2000) PEDAL GEAR PARTS DIAGRAM")
-part-diagram-5.5a.webp "ASTON MARTIN V8 VIRAGE (2000) WHEELS & TYRES PARTS DIAGRAM")
-part-diagram-5.5b.webp "ASTON MARTIN V8 VIRAGE (2000) WHEELS & TYRES, VOLANTE ONLY PARTS DIAGRAM")
-part-diagram-6.1a.webp "ASTON MARTIN V8 VIRAGE (2000) INSTRUMENTS & CONTROLS PARTS DIAGRAM")
-part-diagram-6.1b.webp "ASTON MARTIN V8 VIRAGE (2000) INSTRUMENTS & CONTROLS PARTS DIAGRAM")
-part-diagram-6.2.webp "ASTON MARTIN V8 VIRAGE (2000) LAMPS & BULBS PARTS DIAGRAM")
-part-diagram-6.3a.webp "ASTON MARTIN V8 VIRAGE (2000) COMPONENTS & WIRING PARTS DIAGRAM")
-part-diagram-6.3b.webp "ASTON MARTIN V8 VIRAGE (2000) COMPONENTS & WIRING PARTS DIAGRAM")
-part-diagram-6.3c.webp "ASTON MARTIN V8 VIRAGE (2000) COMPONENTS & WIRING PARTS DIAGRAM")
-part-diagram-6.3d.webp "ASTON MARTIN V8 VIRAGE (2000) COMPONENTS & WIRING PARTS DIAGRAM")
-part-diagram-6.3e.webp "ASTON MARTIN V8 VIRAGE (2000) COMPONENTS & WIRING PARTS DIAGRAM")
-part-diagram-6.3f.webp "ASTON MARTIN V8 VIRAGE (2000) COMPONENTS & WIRING PARTS DIAGRAM")
-part-diagram-6.4a.webp "ASTON MARTIN V8 VIRAGE (2000) WINDSCREEN WIPERS PARTS DIAGRAM")
-part-diagram-6.4b.webp "ASTON MARTIN V8 VIRAGE (2000) WINDSCREEN & HEADLAMP WASHERS PARTS DIAGRAM")
-part-diagram-7.1.webp "ASTON MARTIN V8 VIRAGE (2000) CHASSIS FRAME PARTS DIAGRAM")
-part-diagram-7.10a.webp "ASTON MARTIN V8 VIRAGE (2000) SEAT BELTS, EUROPE, SALOON & VOLANTE PARTS DIAGRAM")
-part-diagram-7.10b.webp "ASTON MARTIN V8 VIRAGE (2000) SEAT BELTS, USA, SALOON PARTS DIAGRAM")
-part-diagram-7.2a.webp "ASTON MARTIN V8 VIRAGE (2000) CHASSIS SUPERSTRUCTURE, FRONT PARTS DIAGRAM")
-part-diagram-7.2b.webp "ASTON MARTIN V8 VIRAGE (2000) CHASSIS SUPERTRUCTURE, REAR PARTS DIAGRAM")
-part-diagram-7.3a.webp "ASTON MARTIN V8 VIRAGE (2000) BODY PANELS, SALOON PARTS DIAGRAM")
-part-diagram-7.3b.webp "ASTON MARTIN V8 VIRAGE (2000) BODY PANELS, VOLANTE PARTS DIAGRAM")
-part-diagram-7.3c.webp "ASTON MARTIN V8 VIRAGE (2000) BODY PANELS, SALOON PARTS DIAGRAM")
-part-diagram-7.4a.webp "ASTON MARTIN V8 VIRAGE (2000) DOORS, SALOON PARTS DIAGRAM")
-part-diagram-7.4b.webp "ASTON MARTIN V8 VIRAGE (2000) DOORS, VOLANTE PARTS DIAGRAM")
-part-diagram-7.4c.webp "ASTON MARTIN V8 VIRAGE (2000) DOOR LOCKING PARTS DIAGRAM")
-part-diagram-7.4d.webp "ASTON MARTIN V8 VIRAGE (2000) WEATHER SEALS, VOLANTE PARTS DIAGRAM")
-part-diagram-7.5.webp "ASTON MARTIN V8 VIRAGE (2000) BODY, FRONT PARTS DIAGRAM")
-part-diagram-7.6.webp "ASTON MARTIN V8 VIRAGE (2000) BODY, BONNET PARTS DIAGRAM")
-part-diagram-7.7a.webp "ASTON MARTIN V8 VIRAGE (2000) BODY, REAR PARTS DIAGRAM")
-part-diagram-7.7b1.webp "ASTON MARTIN V8 VIRAGE (2000) FUEL FILLER FLAPS PARTS DIAGRAM")
-part-diagram-7.7b2.webp "ASTON MARTIN V8 VIRAGE (2000) FUEL FILLER FLAPS PARTS DIAGRAM")
-part-diagram-7.7b3.webp "ASTON MARTIN V8 VIRAGE (2000) FUEL FILLER FLAPS, VOLANTE PARTS DIAGRAM")
-part-diagram-7.8a.webp "ASTON MARTIN V8 VIRAGE (2000) INTERIOR FITTINGS, FASCIA & CENTRE CONSOLE PARTS DIAGRAM")
-part-diagram-7.8a1.webp "ASTON MARTIN V8 VIRAGE (2000) INTERIOR FITTINGS, SALOON PARTS DIAGRAM")
-part-diagram-7.8a2.webp "ASTON MARTIN V8 VIRAGE (2000) DASH HOUSING, VOLANTE PARTS DIAGRAM")
-part-diagram-7.8a3.webp "ASTON MARTIN V8 VIRAGE (2000) CENTRE CONSOLE, VOLANTE PARTS DIAGRAM")
-part-diagram-7.8a4.webp "ASTON MARTIN V8 VIRAGE (2000) HEADER RAIL, VOLANTE PARTS DIAGRAM")
-part-diagram-7.8a5.webp "ASTON MARTIN V8 VIRAGE (2000) REAR TRIM, VOLANTE PARTS DIAGRAM")
-part-diagram-7.8b1.webp "ASTON MARTIN V8 VIRAGE (2000) INTERIOR FITTINGS, SEAT FITTINGS & EUROPEAN SEATS PARTS DIAGRAM")
-part-diagram-7.8b2.webp "ASTON MARTIN V8 VIRAGE (2000) INTERIOR FITTINGS, USA SEAT BELTS PARTS DIAGRAM")
-part-diagram-7.8c.webp "ASTON MARTIN V8 VIRAGE (2000) INTERIOR FITTINGS PARTS DIAGRAM")
-part-diagram-7.9a.webp "ASTON MARTIN V8 VIRAGE (2000) HOOD FRAME ASSEMBLY PARTS DIAGRAM")
-part-diagram-7.9b.webp "ASTON MARTIN V8 VIRAGE (2000) HOOD HYDRAULIC SYSTEM PARTS DIAGRAM")
-part-diagram-7.9c1.webp "ASTON MARTIN V8 VIRAGE (2000) HOOD ASSEMBLY PARTS DIAGRAM")
-part-diagram-7.9c2.webp "ASTON MARTIN V8 VIRAGE (2000) HOOD ASSEMBLY PARTS DIAGRAM")
-part-diagram-7.9d.webp "ASTON MARTIN V8 VIRAGE (2000) HOOD ASSEMBLY PARTS DIAGRAM")
-part-diagram-7.9e.webp "ASTON MARTIN V8 VIRAGE (2000) DROPPING REAR QUARTER LIGHT PARTS DIAGRAM")
-part-diagram-8.1.webp "ASTON MARTIN V8 VIRAGE (2000) ENGINE COMPARTMENT INSTALLATION PARTS DIAGRAM")
-part-diagram-8.2a.webp "ASTON MARTIN V8 VIRAGE (2000) INTERIOR INSTALLATION PARTS DIAGRAM")
-part-diagram-8.2b.webp "ASTON MARTIN V8 VIRAGE (2000) SENSORS, SWITCHES, SOLENOIDS, MOTORS ETC PARTS DIAGRAM")
-part-diagram-9.1.webp "ASTON MARTIN V8 VIRAGE (2000) OPTIONAL EQUIPMENT PARTS DIAGRAM")
-part-diagram-9.2.webp "ASTON MARTIN V8 VIRAGE (2000) TOOLS & SUNDRIES PARTS DIAGRAM")
-part-diagram-9.3.webp "ASTON MARTIN V8 VIRAGE (2000) GASKET SETS PARTS DIAGRAM")
-part-diagram-1.1.webp "ASTON MARTIN V8 VIRAGE (2000) CYLINDER BLOCK PARTS DIAGRAM")
-part-diagram-1.2.webp "ASTON MARTIN V8 VIRAGE (2000) CRANKSHAFT, PISTONS & RODS PARTS DIAGRAM")
-part-diagram-1.3a.webp "ASTON MARTIN V8 VIRAGE (2000) CYLINDER HEAD, TO VIN 60224 PARTS DIAGRAM")
-part-diagram-1.3b.webp "ASTON MARTIN V8 VIRAGE (2000) CYLINDER HEAD, VOLATE FROM VIN 69225 PARTS DIAGRAM")
-part-diagram-1.4a.webp "ASTON MARTIN V8 VIRAGE (2000) TIMING CASE, WATER PUMP & SPROCKETS PARTS DIAGRAM")
-part-diagram-1.4b.webp "ASTON MARTIN V8 VIRAGE (2000) BELTS & CHAINS PARTS DIAGRAM")
-part-diagram-1.5.webp "ASTON MARTIN V8 VIRAGE (2000) OIL PUMP & SUMP PARTS DIAGRAM")
-part-diagram-1.6a.webp "ASTON MARTIN V8 VIRAGE (2000) OIL COOLING SYSTEM, TO APPROX VIN 60192 PARTS DIAGRAM")
-part-diagram-1.6b.webp "ASTON MARTIN V8 VIRAGE (2000) OIL COOLING SYSTEM, VOLANTE, APPROX VIN 60193 ON PARTS DIAGRAM")
-part-diagram-1.7a1.webp "ASTON MARTIN V8 VIRAGE (2000) WATER COOLING SYSTEM, TO APPROX VIN 60192 PARTS DIAGRAM")
-part-diagram-1.7a2.webp "ASTON MARTIN V8 VIRAGE (2000) WATER COOLING SYSTEM, VOLANTE, APPROX VIN 60193 ON PARTS DIAGRAM")
-part-diagram-1.7b1.webp "ASTON MARTIN V8 VIRAGE (2000) RADIATOR FAN COWL, TO APPROX VIN 60192 PARTS DIAGRAM")
-part-diagram-1.7b2.webp "ASTON MARTIN V8 VIRAGE (2000) RADIATOR FAN COWL, VOLANTE, APPROX VIN 60193 ON PARTS DIAGRAM")
-part-diagram-1.8.webp "ASTON MARTIN V8 VIRAGE (2000) ENGINE MOUNTINGS PARTS DIAGRAM")
-part-diagram-1.9a.webp "ASTON MARTIN V8 VIRAGE (2000) IGNITION COIL, DISTRIBUTOR & STARTER MOTOR PARTS DIAGRAM")
-part-diagram-1.9b.webp "ASTON MARTIN V8 VIRAGE (2000) GENERATOR PARTS DIAGRAM")
-part-diagram-2.1a.webp "ASTON MARTIN V8 VIRAGE (2000) THROTTLE LINKAGE & CONTROLS, TO VIN 60224 PARTS DIAGRAM")
-part-diagram-2.1b.webp "ASTON MARTIN V8 VIRAGE (2000) THROTTLE LINKAGE & CONTROLS, VOLANTE, VIN 69225 ON PARTS DIAGRAM")
-part-diagram-2.2a.webp "ASTON MARTIN V8 VIRAGE (2000) INLET MANIFOLDS & PLENUM PARTS DIAGRAM")
-part-diagram-2.2b1.webp "ASTON MARTIN V8 VIRAGE (2000) AIR FILTERS, TO VIN 60224 PARTS DIAGRAM")
-part-diagram-2.2b2.webp "ASTON MARTIN V8 VIRAGE (2000) AIR FILTERS, VOLANTE, VIN 69224 ON PARTS DIAGRAM")
-part-diagram-2.3.webp "ASTON MARTIN V8 VIRAGE (2000) SECONDARY AIR INJECTION SYSTEM PARTS DIAGRAM")
