aston martin v8 virage (2000) interior fittings parts diagram

7.8C - Interior Fittings

Aston Martin V8 Virage (2000) Interior Fittings Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Key
Price
# -
MPN: 83-54709
COVER, HIGH-MOUNTED STOP LAMP
USA cars
from £351.98
from £351.98
ASSEMBLY COVER S/LMP-UN-MOD Genuine Aston Martin - New (to order)
# -
MPN: 83-54712
PLINTH, HIGH-MOUNTED STOP LAMP
USA cars
from £285.91
from £285.91
ASSEMBLY PLINTH-H.L.S.LP Genuine Aston Martin - New (to order)
# -
MPN: 691780
SEAL STRIP
USA cars
from £3.11
from £3.11
SEAL STRIP Genuine Aston Martin - New (to order)
# -
MPN: 692011
SCREW, NO.10 X 3/4
Lamp to plinth - USA cars
from £0.47
from £0.47
SCREW NO10 X 3/4 FLANGE Genuine Aston Martin - New (to order)
# -
MPN: 691460
NUT, SPIRE, NO.8
Lamp to plinth - USA cars
NUT, SPIRE, NO.8 Genuine Aston Martin - New (to order)
# -
MPN: 695149
SCREW, M5 X 60
Plinth to rear parcel shelf - USA cars
from £0.79
from £0.79
SCREW M5 X 60 PAN HD Genuine Aston Martin - New (to order)
# -
MPN: 692055
WASHER, PLAIN, M5
Plinth to rear parcel shelf - USA cars
from £0.47
from £0.47
WASHER M5 PLAIN MED Genuine Aston Martin - New (to order)
# -
MPN: 690386
WASHER, PLAIN, 1/4
Plinth to rear parcel shelf - USA cars
from £0.47
from £0.47
WASHER 1/4 X 3/4 ZPL Genuine Aston Martin - New (to order)
# -
MPN: 692800
NUT, M5
Plinth to rear parcel shelf - USA cars
from £0.47
from £0.47
NUT M5 HEX SLK Genuine Aston Martin - New (to order)
# -
MPN: 83-53264
INTERIOR CARPET SET
RHD, Advise carpet colour required when ordering
from £1,872.03
from £1,872.03
ASSEMBLY CPT SET COMP Genuine Aston Martin - New (to order)
# -
MPN: 83-53265
INTERIOR CARPET SET
LHD, Advise carpet colour required when ordering
INTERIOR CARPET SET Genuine Aston Martin - New (to order)
