aston martin v8 volante (2000) trunk lid parts diagram

7.6B - TRUNK LID

Aston Martin V8 Volante (2000) Trunk Lid Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Key
Price
# -
MPN: 67-65183
BOOT LID ASSEMBLY
from £5,869.93
from £5,869.93
ASSEMBLY BOOT LID IN WHT Genuine Aston Martin - New (to order)
# 1
MPN: 67-65196
BOOT LID OUTER SKIN PANEL
from £2,939.52
from £2,939.52
ASSEMBLY BOOT LID OUTER Genuine Aston Martin - New (to order)
# 2
MPN: 67-65198
PANEL, BOOT LID INNER ASSEMBLY
Made from 67-66654
from £1,997.75
from £1,997.75
PANEL BOOT LID INN ASSEMBLY Genuine Aston Martin - New (to order)
# -
-
LOCTITE 341, 2X300ML
Boot inner to boot outer
# 3
MPN: 67-60676
HINGE PLATE ASSY
from £30.04
from £30.04
ASSEMBLY HINGE PLATE Genuine Aston Martin - New (to order)
# 4
MPN: 67-606664
HINGE BRACKET ASSY
HINGE BRACKET ASSEMBLY Genuine Aston Martin - New (to order)
# 5
MPN: 695515
NUT, FLG, NYLOC, M8, HINGE BRACKET TO DRAIN CHANNEL
from £0.47
from £0.47
NUT M8 HEX FLANGE SLK Genuine Aston Martin - New (to order)
# 6
MPN: 692057
WASHER, PLAIN, M8, HINGE PLATE TO BOOT LID INNER
from £0.47
from £0.47
WASHER M8 PLAIN Genuine Aston Martin - New (to order)
# 7
MPN: 692135
NUT, NYLOC, M8, HINGE PLATE TO BOOT LID INNER
from £0.94
from £0.94
NUT M8 HEX SLK Genuine Aston Martin - New (to order)
# 8
MPN: 696538
CAP, PROTECTION, HINGE PLATE TO BOOT LID INNER
from £0.47
from £0.47
CAP PROTECTION M8 Genuine Aston Martin - New (to order)
# 9
MPN: 695199
SCREW, SHOULDER, M5, BOOT HINGE PIVOT
from £1.46
from £1.46
SCREW M5 -.6 X 30 Genuine Aston Martin - New (to order)
# 10
MPN: 692055
WASHER, PLAIN, M5, BOOT HINGE PIVOT
from £0.47
from £0.47
WASHER M5 PLAIN MED Genuine Aston Martin - New (to order)
# 11
MPN: 692800
NUT, NYLOC, M5, BOOT HINGE PIVOT
from £0.47
from £0.47
NUT M5 HEX SLK Genuine Aston Martin - New (to order)
# 12
MPN: 67-52444
STRIKER, TRUNK LID LOCK
from £22.00
from £22.00
STRIKER-TRUNK LID LK Genuine Aston Martin - New (to order)
# 13
MPN: 692077
NUT, M8, STRIKER TRUNK LID
Nut, plain, M8 Genuine Aston Martin - New (to order)
# 14
MPN: 692047
WASHER, SPRING, M8, STRIKER TRUNK LID
from £0.47
from £0.47
WASHER M8 SPRING Genuine Aston Martin - New (to order)
# 15
MPN: 692057
WASHER, PLAIN, M8, STRIKER TRUNK LID
from £0.47
from £0.47
WASHER M8 PLAIN Genuine Aston Martin - New (to order)
# 16
MPN: 67-66090
GAS STRUT ASSEMBLY, BOOT
from £161.78
from £161.78
ASSEMBLY GAS STRUT-BOOT Genuine Aston Martin - New (to order)
# 17
MPN: 67-72324
OVERSLAM RUBBER
from £3.25
from £3.25
OVERSLAM RUBBER Genuine Aston Martin - New (to order)
# 18
MPN: 80-66488
Bracket, trunk latch actuator mounting
from £5.98
from £5.98
BRACKET TRUNK LATCH Genuine Aston Martin - New (to order)
# 19
MPN: 697543
SCREW, 1/4 UNF X 3/8
from £0.47
from £0.47
SCREW 1/4 UNF X 3/8 Genuine Aston Martin - New (to order)
# 20
MPN: 697546
WASHER, LOCK
from £0.47
from £0.47
WASHER-LOCK Genuine Aston Martin - New (to order)
# 21
MPN: 697485
WASHER, PLAIN, M6
from £0.47
from £0.47
WASHER M6 PLAIN FM C Genuine Aston Martin - New (to order)
# 22
MPN: 67-82587
TRUNK LATCH
from £184.05
from £184.05
TRUNK LATCH W/MSWTCH Genuine Aston Martin - New (to order)
# 23
MPN: 692672
SCREW, FLG, M6X16
from £6.16
from £6.16
SCREW M6 X16 HEX FLANGE Genuine Aston Martin - New (to order)
# 24
MPN: 83-66365
PLATE, CENTRE BOOT PANEL RETAINER
PLATE, CENTRE BOOT PANEL RETAINER Genuine Aston Martin - New (to order)
# 25
MPN: 37-82584
ACTUATOR, TRUNK LATCH
from £227.36
from £227.36
ACTUATOR-TRUNK LATCH Genuine Aston Martin - New (to order)
# 26
MPN: 697542
SCREW
from £0.47
from £0.47
SCREW Genuine Aston Martin - New (to order)
# 27
MPN: 67-82586
LINK, ACTUATOR TRUNK LOCK
from £10.46
from £10.46
LINK ACTUATOR T/LOCK Genuine Aston Martin - New (to order)
# 28
MPN: 697544
WASHER, PLAIN, 4BA
from £0.47
from £0.47
WASHER 4BA PLAIN C Genuine Aston Martin - New (to order)
# 29
MPN: 697290
CLIP, STARLOCK, M3
from £0.47
from £0.47
PUSH ON FIXER-M3 Genuine Aston Martin - New (to order)
# 30
MPN: 80-66140
PLATE, BOOT RELEASE CABLE ABUTMENT
from £6.28
from £6.28
PLATE-BOOT RELEASE Genuine Aston Martin - New (to order)
# 31
MPN: 80-66141
PIVOT ASSY, BOOT RELEASE CABLE
from £9.93
from £9.93
ASSY-PIVOT RELEASE Genuine Aston Martin - New (to order)
# 32
MPN: 80-72266
CABLE, BOOT RELEASE
from £18.84
from £18.84
CABLE BOOT RELEASE Genuine Aston Martin - New (to order)
# 33
MPN: 80-56425
PLATE ASSY, CABLE RETAINER
from £8.48
from £8.48
ASSEMBLY PLT CABLE RET'R Genuine Aston Martin - New (to order)
# 34
MPN: 692228
SCREW, M4X10
from £0.47
from £0.47
SCREW M4 X 10 HEX HD Genuine Aston Martin - New (to order)
# 35
MPN: 698403
GROMMET
from £0.56
from £0.56
DIAPHRAGM GROMMET Genuine Aston Martin - New (to order)
# 36
MPN: 83-72232
LEVER, REMOTE BOOT RELEASE
from £19.68
from £19.68
LEVER BOOT RELEASE Genuine Aston Martin - New (to order)
# 37
MPN: 692215
SCREW, M5X20, BOOT LEVER SWITCH
from £0.47
from £0.47
SCREW M5 X 20 HEX HD Genuine Aston Martin - New (to order)
# 38
MPN: 67-66522
SPACER, BOOT HINGE
from £2.22
from £2.22
SPACER - BOOT HINGE Genuine Aston Martin - New (to order)
# 39
MPN: 80-66645
ADAPTOR PLATE, BOOT GAS STAY
ADAPTOR PLATE Genuine Aston Martin - New (to order)
# 40
MPN: 692089
SCREW, M8X16
from £0.47
from £0.47
SCREW M8 X 16 HEX HD Genuine Aston Martin - New (to order)
# 41
MPN: 692077
NUT, M8
Nut, plain, M8 Genuine Aston Martin - New (to order)
# 42
MPN: 80-66646
ANGLE REINF, PIVOT BRACKET BOOT GAS STAY
from £2.56
from £2.56
ANGLE REINFORCEMENT - PIVOT Genuine Aston Martin - New (to order)
# 43
MPN: 83-66647
GAITER, ADAPTOR PLATE
Made from 697962
GAITER, ADAPTOR PLATE Genuine Aston Martin - New (to order)
# 44
MPN: 691910
P CLIP, BOOT CABLE
from £0.47
from £0.47
P-CLIP PLASTIC 5MM Genuine Aston Martin - New (to order)
# 45
MPN: 627-000-0604
SCREW, NO.6 X 1/2
P clip attach
from £0.47
from £0.47
SCREW NO6 X 1/2 Genuine Aston Martin - New (to order)
