aston martin vanquish (2015) front header trim, coupe 14.5my parts diagram

01-0504-B1A - Front Header Trim, Coupe 14.5MY

Aston Martin Vanquish (2015) Front Header Trim, Coupe 14.5MY Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                #
                Part number
                Description
                Key
                Price
                # 1
                MPN: DD33-03409-ADW
                HEADER TRIM, RHD
                Includes Items 2 and 3
                from £242.29
                from £242.29
                HEADER TRIM, RHD Genuine Aston Martin - New (to order)
                # 1
                MPN: DD33-03408-ACW
                HEADER TRIM, LHD
                Includes Items 2 and 3
                from £198.10
                from £198.10
                HEADER TRIM, LHD Genuine Aston Martin - New (to order)
                # 2
                MPN: 701448
                SPRING NUT, U TYPE, 4.2X2.1
                from £0.47
                from £0.47
                NUT 4.2 2.1-3.1 U TY Genuine Aston Martin - New (to order)
                SPLITTER NUTS Genuine Ferrari Part - New (to order)
                # 3
                MPN: AG43-19G379-BB
                BEZEL, MICROPHONE
                Up to 17MY
                from £37.80
                from £37.80
                BEZEL, MICROPHONE Genuine Aston Martin - New (to order)
                # 3
                MPN: HG33-19G379-AA
                BEZEL, MICROPHONE
                FROM 17MY
                from £56.30
                from £56.30
                BEZEL, MICROPHONE Genuine Aston Martin - New (to order)
                # 4
                MPN: 701157-PK
                SCREW AND WASHER, 4.2X16
                Pack of 10
                from £1.59
                from £1.59
                SCREW&WSHR 4.2X16(10 Genuine Aston Martin - New (to order)
                # 5
                MPN: CD33-519A58-ACW
                CONSOLE ASSEMBLY, ROOF HEADER
                Includes Items 6 and 7
                from £299.07
                from £299.07
                CONSOLE ASSEMBLY, ROOF HEADER Genuine Aston Martin - New (to order)
                # 6
                MPN: ED33-13E714-AA
                BEZEL, LAMP ASSEMBLY, AMBIENT
                from £0.94
                from £0.94
                BEZEL, LAMP ASSEMBLY, AMBIENT Genuine Aston Martin - New (to order)
                # 7
                MPN: AD33-19G379-AA
                BEZEL, MICROPHONE
                from £3.00
                from £3.00
                RETAINER, MICROPHONE BEZEL Genuine Aston Martin - New (to order)
                # 8
                MPN: 701653
                SPRING NUT, U TYPE, 4.2X0.7
                from £0.47
                from £0.47
                SPRING NUT 4.2X0.7-2 Genuine Aston Martin - New (to order)
                # 9
                MPN: 704620
                WASHER, INTERNAL STAR, M6
                WASHER-M6 INT S/PRF Genuine Aston Martin - New (to order)
                # 10
                MPN: 702944
                NUT, HEX FLANGED, M6
                from £0.58
                from £0.58
                NUT M6 HEX FLNG MTL8 Genuine Aston Martin - New (to order)
                LOWER MESH NUTS Genuine Ferrari Part - New (to order)
                # 11
                MPN: 702994
                NUT, THIN, M6
                from £0.47
                from £0.47
                NUT M6 HEX THIN Genuine Aston Martin - New In stock
