aston martin vanquish (2015) door top roll parts diagram

01-0505-02 - Door Top Roll

Aston Martin Vanquish (2015) Door Top Roll Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
        #
        Part number
        Description
        Key
        Price
        # 1
        MPN: CD33-23928-ACW
        PANEL ASSY, DOOR TOP ROLL, RH
        Coupe
        from £500.94
        from £500.94
        PANEL ASSEMBLY, DOOR TOP ROLL, RH Genuine Aston Martin - New (to order)
        # 1
        MPN: CD33-23929-ACW
        PANEL ASSY, DOOR TOP ROLL, LH
        Coupe
        from £435.76
        from £435.76
        PANEL ASSEMBLY, DOOR TOP ROLL, LH Genuine Aston Martin - New (to order)
        # 2
        MPN: CD33-23747-AAW
        INSERT, WINGS LOGO
        Coupe
        from £143.01
        from £143.01
        INSERT, WINGS LOGO Genuine Aston Martin - New (to order)
        # 3
        MPN: ED33-23928-ABW
        PANEL ASSY, DOOR TOP ROLL, RH
        Volante, for curtain airbag
        from £1,554.37
        from £1,554.37
        PANEL ASSEMBLY, DOOR TOP ROLL, RH Genuine Aston Martin - New (to order)
        # 3
        MPN: ED33-23929-ABW
        PANEL ASSY, DOOR TOP ROLL, LH
        Volante, for curtain airbag
        from £1,554.37
        from £1,554.37
        PANEL ASSEMBLY, DOOR TOP ROLL, LH Genuine Aston Martin - New (to order)
        # 4
        MPN: AD43-23747-AAW
        INSERT, AIRBAG
        Volante
        from £124.28
        from £124.28
        SRS INSERT ASSEMBLY Genuine Aston Martin - New (to order)
        # 5
        MPN: CD33-20838-AA
        RETAINER, DOOR TRIM UPPER
        Coupe
        RETAINER, DOOR TRIM UPPER Genuine Aston Martin - New (to order)
        # 5
        MPN: ED33-20838-AB
        RETAINER, DOOR TRIM UPPER
        Volante
        from £19.46
        from £19.46
        RETAINER, DOOR TRIM UPPER Genuine Aston Martin - New (to order)
        # 6
        MPN: AG43-20838-BA
        RETAINER, DOOR TRIM UPPER
        Coupe
        from £9.27
        from £9.27
        RETAINER, DOOR TRIM UPPER Genuine Aston Martin - New (to order)
        # 7
        MPN: CD33-20838-BB
        RETAINER, DOOR TRIM UPPER, RH
        Coupe
        from £23.80
        from £23.80
        RETAINER, DOOR TRIM UPPER, RH Genuine Aston Martin - New (to order)
        # 7
        MPN: CD33-20839-BB
        RETAINER, DOOR TRIM UPPER, LH
        Coupe
        RETAINER, DOOR TRIM UPPER, LH Genuine Aston Martin - New (to order)
        # 8
        MPN: 702514
        SCREW, M6 X 14, PAN HD
        from £0.56
        from £0.56
        SCREW M6 X 14 HD INT Genuine Aston Martin - New In stock
        FRONT UNDERTRAY BOLT Genuine Ferrari Part - New (to order)
        # 9
        MPN: 7G43-10609E-AA-PK
        CLIP, SPRING, U-TYPE, M6
        Pack of 10
        from £5.08
        from £5.08
        CLIP SPG M6 PK OF 10 Genuine Aston Martin - New In stock
        FRONT UNDERTRAY CLIP Genuine Ferrari Part - New (to order)
        # 10
        MPN: 701655
        RIVET, 4.8 X 6.3-12.7
        from £0.47
        from £0.47
        RIVET-4.8X6.3-12.7 Genuine Aston Martin - New (to order)
        # 11
        MPN: DD33-487032-AA
        CLIP, PUSH IN, 8.0 X 16 X 1.7
        from £0.60
        from £0.60
        CLIP, PUSH IN, 8.0 X 16 X 1.7 Genuine Aston Martin - New (to order)
        # 12
        MPN: W502670-S442
        SCREW, 4.2X13
        Coupe
        from £0.47
        from £0.47
        SCR4 - 8X16 Genuine Aston Martin - New (to order)
        # 13
        MPN: 703149
        SCREW, M6 X 16, PAN HD
        Volante
        from £0.47
        from £0.47
        SCREW M6X16 PAN Genuine Aston Martin - New (to order)
        # 14
        MPN: 6G33-100063-AA
        PUSH FIX M6
        Volante
        PUSH-ON FIX, H/BRAKE CABLE TO LEVER Genuine Aston Martin - New (to order)
        # 15
        MPN: W505722-S424
        SCREW, M5 X 12, COUNTERSUNK TORX
        Volante
        SCREW, M5 X 12, COUNTERSUNK TORX Genuine Aston Martin - New (to order)
        # 16
        MPN: 701573
        SCREW AND WASHER, M4 X 16, PAN HD
        Volante
        Supersession
        Supersession
        Genuine Aston Martin (no longer available to order)
