aston martin vanquish (2017) steering column assembly parts diagram

11-0401-02 - STEERING COLUMN ASSEMBLY

Aston Martin Vanquish (2017) Steering Column Assembly Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                      #
                      Part number
                      Description
                      Key
                      Price
                      # 1
                      MPN: AD43-3C529-AB
                      COLUMN ASSY, ELECTRIC STEERING
                      from £918.36
                      from £918.36
                      ELEC STEERING COLM ASSEMBLY Genuine Aston Martin - New (to order)
                      # 2
                      MPN: 4G43-3F818-AA
                      SENSOR, STEERING ANGLE
                      from £126.46
                      from £126.46
                      SNS ASSEMBLY - STNG ROT Genuine Aston Martin - New (to order)
                      SNS ASSEMBLY - STNG ROT Genuine Aston Martin - Used In stock
                      # 3
                      MPN: 4G43-ALR3219-BA
                      BRACKET, STEERING ANGLE SENSOR MOUNTING
                      from £2.46
                      from £2.46
                      BRACKET-MOUNTING Genuine Aston Martin - New (to order)
                      # 4
                      MPN: 4G43-3D677-BA
                      GAITER, STEERING COLUMN, RHD
                      from £18.17
                      from £18.17
                      SE ASY-STNG COL OPG Genuine Aston Martin - New (to order)
                      SE ASY-STNG COL OPG Genuine Aston Martin - Used In stock
                      # 4
                      MPN: 4G43-3D677-AA
                      GAITER, STEERING COLUMN, LHD
                      from £33.72
                      from £33.72
                      SE ASY-STNG COL OPG Genuine Aston Martin - New (to order)
                      # 5
                      MPN: 701354
                      SCREW & WASHER, M3.5 X 13, PAN
                      from £0.47
                      from £0.47
                      SCREW M3.5X13 PAN FLANGE Genuine Aston Martin - New (to order)
                      # 6
                      MPN: 4G43-3C662-AE
                      SHAFT ASSY, STEERING COLUMN INTERMEDIATE
                      from £214.72
                      from £214.72
                      This part replaces part number 4G43-3C662-AD
                      STEERING COLUMN INTERMEDIATE Genuine Aston Martin - New (to order)
                      # 7
                      MPN: 4G43-3C684-AB
                      BOLT, M8 X 30, HEX FLANGE HD
                      from £1.90
                      from £1.90
                      BOLT - STEERING COL CLAMP Genuine Aston Martin - New (to order)
                      # 8
                      MPN: 703138-PK
                      BOLT, M8 X 25, PATCH
                      Pack of 10
                      from £4.07
                      from £4.07
                      BOLT, M8 X 25, PATCH Genuine Aston Martin - New (to order)
                      # 9
                      MPN: 4G43-3N997-AC
                      COUPLING, POWER
                      from £36.54
                      from £36.54
                      CPL-STNG COL SHFT Genuine Aston Martin - New (to order)
                      CPL-STNG COL SHFT Genuine Aston Martin - Used In stock
                      # 10
                      MPN: 701355
                      SCREW, M10 X 21.8
                      from £0.72
                      from £0.72
                      SCREW M10X1.5X21.8 Genuine Aston Martin - New (to order)
                      # 11
                      MPN: 701353
                      SCREW, M8 X 30, PAN HD TORX DRIVE
                      from £0.73
                      from £0.73
                      SCREW M8X30 PAN HD Genuine Aston Martin - New (to order)
