-Set Holder Without Door Version- -Valid for TS-
ferrari 348 (1993) tb / ts tunnel - accessories parts diagram

125A - tunnel - accessories

Ferrari 348 (1993) TB / TS Tunnel - Accessories Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                          #
                                          Part number
                                          Description
                                          Price
                                          # 001
                                          MPN: 62147100
                                          RADIO CASING
                                          from £342.05
                                          from £342.05
                                          # 002
                                          MPN: 14202782
                                          BLOCK
                                          from £0.71
                                          from £0.71
                                          # 003
                                          MPN: 15688375
                                          SCREW
                                          (minimum order quantity = 30)
                                          from £0.54
                                          from £0.54
                                          This part replaces part number 15688306 which we have in stock
                                          # 004
                                          MPN: 14624487
                                          RUBBER PLUG
                                          from £2.32
                                          from £2.32
                                          # 005
                                          MPN: 62147900
                                          SPRING FOR DOOR
                                          from £60.52
                                          from £60.52
                                          # 006
                                          MPN: 621474..
                                          COVERED CAR RADIO OUTER SET HOLDER
                                          Not for USA from M.Y. 90
                                          Supersession
                                          Supersession
                                          # 006
                                          MPN: 621477..
                                          DOORTRIM
                                          Not for USA from M.Y. 90
                                          Supersession
                                          Supersession
                                          # 007
                                          MPN: 62147800
                                          PIN FOR DOOR
                                          from £2.62
                                          from £2.62
                                          # 008
                                          MPN: 62993700
                                          COVERED INNER GLOVE BOX PLATE
                                          from £24.84
                                          from £24.84
                                          # 009
                                          MPN: 146375
                                          CONSOLE PLATE
                                          from £203.12
                                          from £203.12
                                          # 010
                                          MPN: 147111
                                          TUNNEL PLATE
                                          valid for LHD
                                          from £275.42
                                          from £275.42
                                          # 010
                                          MPN: 147112
                                          TUNNEL PLATE
                                          Valid For RHD
                                          from £388.56
                                          from £388.56
                                          # 011
                                          MPN: 62146600
                                          ASHTRAY
                                          from £427.73
                                          from £427.73
                                          # 012
                                          -
                                          ASHTRAY PAN
                                          # 013
                                          MPN: 226942
                                          CIGAR LIGHTER
                                          not as spare part - use part number: 226942
                                          from £11.69
                                          from £11.69
                                          This part replaces part number 61107500
                                          # 014
                                          MPN: 62147500
                                          CAR RADIO GLOVE BOX INNER DOOR
                                          Not for USA from M.Y. 90
                                          from £64.59
                                          from £64.59
                                          # 015
                                          MPN: 226941
                                          CIGAR LIGHTER BODY
                                          not as spare part - use part number: 226941
                                          from £9.51
                                          from £9.51
                                          This part replaces part number 61107600 - and 5 more. Click to view details
                                          # 016
                                          MPN: 62146500
                                          PLATE FOR MONEY
                                          from £131.25
                                          from £131.25
                                          # 017
                                          MPN: 633221..
                                          LINING
                                          Supersession
                                          Supersession
                                          # 017
                                          MPN: 633396..
                                          GLOVE BOX BOTTOM COVER
                                          Supersession
                                          Supersession
                                          # 018
                                          MPN: 12577811
                                          NUT
                                          Supersession
                                          Supersession
                                          # 019
                                          MPN: 12638101
                                          WASHER
                                          from £0.71
                                          from £0.71
                                          # 020
                                          MPN: 633397..
                                          COVERED REAR INSERT
                                          Not for GD
                                          Supersession
                                          Supersession
                                          # 020
                                          MPN: 633398..
                                          LINING
                                          Not for GD
                                          Supersession
                                          Supersession
                                          # 020
                                          MPN: 633410..
                                          COVERED REAR INSERT
                                          Valid for GO
                                          Supersession
                                          Supersession
                                          # 020
                                          MPN: 633411..
                                          LINING
                                          Valid for GD
                                          Supersession
                                          Supersession
                                          # 021
                                          MPN: 15915807
                                          SCREW
                                          from £0.47
                                          from £0.47
                                          # 022
                                          MPN: 622260..
                                          COVERED CAR RADIO OUTER SET HOLDER
                                          Valid for USA from M.Y. 90
                                          Supersession
                                          Supersession
                                          # 022
                                          MPN: 622261..
                                          DOORTRIM
                                          Valid for USA from M.Y. 90
                                          Supersession
                                          Supersession
                                          # 023
                                          MPN: 62990000
                                          348 TS NAMEPLATE
                                          Valid for USA from M.Y. 90
                                          from £69.83
                                          from £69.83
                                          # 024
                                          MPN: 62220600
                                          CAR RADIO GLOVE BOX INNER DOOR
                                          Valid for USA from M.Y. 90
                                          # 025
                                          MPN: 15669706
                                          SCREW
                                          from £0.47
                                          from £0.47
                                          # 026
                                          MPN: 62993400
                                          CLIP
                                          from £1.14
                                          from £1.14
                                          # 027
                                          MPN: 16101711
                                          NUT
                                          from £0.53
                                          from £0.53
                                          This part replaces part number 16101715
                                          # 028
                                          MPN: 10615171
                                          WASHER
                                          from £0.47
                                          from £0.47
                                          This part replaces part number 10615174
                                          # 029
                                          MPN: 12612207
                                          WASHER
                                          from £0.71
                                          from £0.71
                                          # 030
                                          MPN: 15688375
                                          SCREW
                                          (minimum order quantity = 30)
                                          from £0.54
                                          from £0.54
                                          This part replaces part number 15688306 which we have in stock
                                          # 031
                                          MPN: 12638178
                                          WASHER
                                          from £0.47
                                          from £0.47
                                          This part replaces part number 10519578 which we have in stock - and 3 more. Click to view details
                                          # 032
                                          MPN: 60324506
                                          CLIP
                                          Valid for USA from M.Y. 90
                                          from £1.55
                                          from £1.55
                                          This part replaces part number 62773000
                                          # 033
                                          MPN: 14115980
                                          BLOCK
                                          from £0.69
                                          from £0.69
                                          This part replaces part number 14202380
