ferrari 599 sa aperta (europe) engine compartment lid parts diagram

0116 - ENGINE COMPARTMENT LID

Ferrari 599 SA Aperta (Europe) ENGINE COMPARTMENT LID Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                                              #
                                                              Part number
                                                              Description
                                                              Price
                                                              # 001
                                                              MPN: 68057711
                                                              front lid
                                                              from £2,074.84
                                                              from £2,074.84
                                                              This part replaces part number 68057700
                                                              # 002
                                                              MPN: 68577300
                                                              INTERNAL TRIM
                                                              from £739.59
                                                              from £739.59
                                                              # 003
                                                              MPN: 68057900
                                                              COMPLETE RH HINGE
                                                              from £240.28
                                                              from £240.28
                                                              # 003
                                                              MPN: 68058000
                                                              COMPLETE LH HINGE
                                                              from £240.28
                                                              from £240.28
                                                              # 004
                                                              MPN: 14059311
                                                              NUT
                                                              from £0.29
                                                              from £0.29
                                                              # 005
                                                              MPN: 12646701
                                                              WASHER
                                                              from £0.51
                                                              from £0.51
                                                              # 006
                                                              MPN: 68576800
                                                              GAS STRUT
                                                              from £48.85
                                                              from £48.85
                                                              # 007
                                                              MPN: 65939900
                                                              PIN
                                                              from £1.18
                                                              from £1.18
                                                              This part replaces part number 63402800 which we have in stock - and 1 more. Click to view details
                                                              # 008
                                                              MPN: 11617624
                                                              SCREW
                                                              from £1.95
                                                              from £1.95
                                                              # 009
                                                              MPN: 14496501
                                                              WASHER
                                                              from £0.84
                                                              from £0.84
                                                              # 010
                                                              MPN: 80205800
                                                              ENGINE COMPARTMENT LID LOCK
                                                              from £175.06
                                                              from £175.06
                                                              This part replaces part number 69969400
                                                              # 011
                                                              MPN: 80205900
                                                              ENGINE COMPARTMENT LID RELEASE CABLE
                                                              LHD Release Cable For Bonnet, May Have To Replace lock 80205800, if Old Version Fitted
                                                              from £92.45
                                                              from £92.45
                                                              This part replaces part number 69122000
                                                              # 011
                                                              MPN: 80206000
                                                              ENGINE COMPARTMENT LID RELEASE CABLE
                                                              -Applicable for GD-
                                                              from £46.17
                                                              from £46.17
                                                              # 012
                                                              MPN: 14569480
                                                              CLIP
                                                              from £0.53
                                                              from £0.53
                                                              This part replaces part number 81580800
                                                              # 013
                                                              MPN: 68577100
                                                              EMERGENCY CABLE
                                                              from £18.90
                                                              from £18.90
                                                              # 014
                                                              MPN: 14040711
                                                              NUT
                                                              from £0.53
                                                              from £0.53
                                                              This part replaces part number 14040715
                                                              # 015
                                                              MPN: 67161800
                                                              SPACER BLOCK
                                                              from £21.35
                                                              from £21.35
                                                              This part replaces part number 69773300
                                                              # 016
                                                              MPN: 67003800
                                                              ENGINE COMPARTMENT LID HANDLE
                                                              from £23.68
                                                              from £23.68
                                                              # 017
                                                              MPN: 14059111
                                                              NUT
                                                              from £0.47
                                                              from £0.47
                                                              # 018
                                                              MPN: 12639724
                                                              WASHER
                                                              from £0.47
                                                              from £0.47
                                                              This part replaces part number 12639725 - and 1 more. Click to view details
                                                              # 019
                                                              MPN: 67134700
                                                              LID LOCK STRIKER
                                                              from £22.51
                                                              from £22.51
                                                              # 020
                                                              MPN: 16296927
                                                              SCREW
                                                              from £0.47
                                                              from £0.47
                                                              # 021
                                                              MPN: 69362900
                                                              SHIM
                                                              from £1.84
                                                              from £1.84
                                                              # 022
                                                              MPN: 68786200
                                                              RH GRILLE
                                                              from £218.91
                                                              from £218.91
                                                              # 022
                                                              MPN: 68786300
                                                              LH GRILLE
                                                              from £218.91
                                                              from £218.91
                                                              # 023
                                                              MPN: 69855300
                                                              PRESS-FIT BUTTON
                                                              from £0.47
                                                              from £0.47
                                                              # 024
                                                              MPN: 69850300
                                                              RH AIR VENT SURROUND
                                                              from £64.12
                                                              from £64.12
                                                              # 024
                                                              MPN: 69850400
                                                              LH AIR VENT SURROUND
                                                              from £64.12
                                                              from £64.12
                                                              # 025
                                                              MPN: 14591687
                                                              FASTENER BUTTON
                                                              from £0.26
                                                              from £0.26
                                                              This part replaces part number 69767700 - and 1 more. Click to view details
                                                              # 026
                                                              MPN: 68048000
                                                              RH BRACKET
                                                              from £9.53
                                                              from £9.53
                                                              # 026
                                                              MPN: 68048100
                                                              LH BRACKET
                                                              from £17.33
                                                              from £17.33
                                                              # 027
                                                              MPN: 16287224
                                                              SCREW
                                                              from £0.47
                                                              from £0.47
                                                              This part replaces part number 16287221
                                                              # 028
                                                              MPN: 69867900
                                                              STRIKER RETAINER BRACKET
                                                              from £14.76
                                                              from £14.76
                                                              # 029
                                                              MPN: 10902387
                                                              SCREW
                                                              from £0.47
                                                              from £0.47
                                                              This part replaces part number 10902327 which we have in stock
                                                              # 030
                                                              MPN: 12601277
                                                              WASHER
                                                              from £0.71
                                                              from £0.71
                                                              # 031
                                                              MPN: 12644478
                                                              WASHER
                                                              from £0.47
                                                              from £0.47
