ferrari 599 sa aperta (usa) passenger compartment ecus parts diagram

0136 - PASSENGER COMPARTMENT ECUs

Ferrari 599 SA Aperta (USA) PASSENGER COMPARTMENT ECUs Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                  #
                  Part number
                  Description
                  Price
                  # 001
                  MPN: 242006
                  BODY COMPUTER NODE
                  from £1,421.15
                  from £1,421.15
                  This part replaces part number 212139
                  # 001
                  MPN: 262999
                  BODY COMPUTER NODE
                  -No longer supplied- -Replaced by 242006-
                  from £373.01
                  from £373.01
                  # 002
                  MPN: 206070
                  YAW SENSOR
                  -Applicable until depletion-
                  from £78.75
                  from £78.75
                  # 002
                  MPN: 317783
                  YAW SENSOR
                  -Applicable after depletion of 206070-
                  from £163.02
                  from £163.02
                  This part replaces part number 206070 which we have in stock
                  # 003
                  MPN: 204708
                  MAIN NODE ECU
                  from £378.37
                  from £378.37
                  # 005
                  MPN: 188788
                  POWER STEERING CONTROL ECU
                  from £152.16
                  from £152.16
                  # 006
                  MPN: 253903
                  WINDSCREEN WIPER ECU
                  from £152.46
                  from £152.46
                  This part replaces part number 212916
                  # 007
                  MPN: 245787
                  DASHBOARD NODE
                  from £146.34
                  from £146.34
                  This part replaces part number 190831 which we have in stock
                  # 008
                  MPN: 217806
                  BRACKET
                  from £8.39
                  from £8.39
                  # 009
                  MPN: 14059211
                  NUT
                  from £0.47
                  from £0.47
                  # 010
                  MPN: 278515
                  ANTI-LIFT MODULE
                  from £311.04
                  from £311.04
