![ferrari 812 superfast (europe) electronic management (suspension) parts diagram](/img/CxIAAETbRrE5H1AM3VKGHAMRlK8M0Sg0yHU-zqVvF7EWNB4ZfEjZjS0DAw%3D%3D/ferrari-812-superfast-(europe)-part-diagram-0136.webp)
0136 - ELECTRONIC MANAGEMENT (SUSPENSION)
Ferrari 812 Superfast (Europe) ELECTRONIC MANAGEMENT (SUSPENSION) Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table
- You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: 320527
COMPL. FRONT RH MOTION SENSOR
Supersession
Supersession
# 002
MPN: 320526
COMPL. FRONT LH MOTION SENSOR
Supersession
Supersession
# 003
MPN: 320528
POTENTIOMETER TIE-ROD
-L. 63.7 mm-
Supersession
Supersession
# 004
MPN: 311876
FRONT RH BRACKET
from £6.95
from £6.95
# 005
MPN: 311875
FRONT LH BRACKET
from £6.95
from £6.95
# 006
MPN: 259266
COMPL. REAR RH MOTION SENSOR
from £61.52
from £61.52
This part replaces part number 230954 - and 4 more. Click to view details
# 007
MPN: 259265
COMPL. REAR LH MOTION SENSOR
from £61.52
from £61.52
This part replaces part number 230953 - and 2 more. Click to view details
# 008
MPN: 229653
POTENTIOMETER TIE-ROD
-L. 115 mm-
from £21.11
from £21.11
# 009
MPN: 217456
SCREW
from £0.47
from £0.47
# 010
MPN: 231617
SCREW
-M6 X 18-
from £0.47
from £0.47
This part replaces part number 14433124 which we have in stock
# 011
MPN: 14040614
NUT
from £0.47
from £0.47
# 012
MPN: 326365
REAR RH BRACKET
from £40.73
from £40.73
# 013
MPN: 326364
REAR LH BRACKET
from £40.73
from £40.73
# 014
MPN: 263079
ACCELEROMETER
from £77.58
from £77.58
