ferrari 812 superfast (rhd) rear brake callipers parts diagram

0028 - REAR BRAKE CALLIPERS

Ferrari 812 Superfast (RHD) REAR BRAKE CALLIPERS Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                  #
                  Part number
                  Description
                  Price
                  # 001
                  MPN: 335699
                  REAR LH CALLIPER WITH PADS
                  -Standard-
                  from £2,715.87
                  from £2,715.87
                  # 001
                  MPN: 335701
                  REAR RH CALLIPER WITH PADS
                  -Standard-
                  from £2,715.87
                  from £2,715.87
                  # 001
                  MPN: 335704
                  REAR LH CALLIPER WITH PADS
                  -Black-
                  from £2,769.12
                  from £2,769.12
                  # 001
                  MPN: 335705
                  REAR LH CALLIPER WITH PADS
                  -Scuderia Red-
                  from £2,878.78
                  from £2,878.78
                  # 001
                  MPN: 335706
                  REAR LH CALLIPER WITH PADS
                  -Gold-
                  from £2,878.78
                  from £2,878.78
                  # 001
                  MPN: 335707
                  REAR LH CALLIPER WITH PADS
                  -Blue-
                  from £3,074.01
                  from £3,074.01
                  # 001
                  MPN: 335708
                  REAR LH CALLIPER WITH PADS
                  -Dark grey-
                  from £3,074.01
                  from £3,074.01
                  # 001
                  MPN: 335709
                  REAR LH CALLIPER WITH PADS
                  -Silver-
                  from £2,878.78
                  from £2,878.78
                  # 001
                  MPN: 335710
                  REAR LH CALLIPER WITH PADS
                  -Red-
                  from £2,815.91
                  from £2,815.91
                  # 001
                  MPN: 335711
                  REAR LH CALLIPER WITH PADS
                  -Yellow-
                  from £2,878.78
                  from £2,878.78
                  # 001
                  MPN: 335712
                  REAR RH CALLIPER WITH PADS
                  -Black-
                  from £2,769.12
                  from £2,769.12
                  # 001
                  MPN: 335713
                  REAR RH CALLIPER WITH PADS
                  -Scuderia Red-
                  from £2,878.78
                  from £2,878.78
                  # 001
                  MPN: 335714
                  REAR RH CALLIPER WITH PADS
                  -Gold-
                  from £2,878.78
                  from £2,878.78
                  # 001
                  MPN: 335715
                  REAR RH CALLIPER WITH PADS
                  -Blue-
                  from £3,074.01
                  from £3,074.01
                  # 001
                  MPN: 335716
                  REAR RH CALLIPER WITH PADS
                  -Dark grey-
                  from £3,074.01
                  from £3,074.01
                  # 001
                  MPN: 335717
                  REAR RH CALLIPER WITH PADS
                  -Silver-
                  from £2,878.78
                  from £2,878.78
                  # 001
                  MPN: 335718
                  REAR RH CALLIPER WITH PADS
                  -Red-
                  from £2,815.91
                  from £2,815.91
                  # 001
                  MPN: 335719
                  REAR RH CALLIPER WITH PADS
                  -Yellow-
                  from £995.00
                  from £995.00
                  # 002
                  MPN: 271711
                  RUBBER PIPE
                  from £18.16
                  from £18.16
                  This part replaces part number 116373 - and 4 more. Click to view details
                  # 003
                  MPN: 299560
                  COMPL. BRAKE PIPE FROM CALLIPER TO LH HOSE
                  from £9.10
                  from £9.10
                  # 003
                  MPN: 299562
                  COMPL. BRAKE PIPE FROM CALLIPER TO RH HOSE
                  from £10.32
                  from £10.32
                  # 004
                  MPN: 116374
                  CLIP
                  from £1.16
                  from £1.16
                  # 005
                  MPN: 70003667
                  SET OF EPB PADS
                  from £732.75
                  from £732.75
                  # 006
                  MPN: 70003759
                  REAR PAD SET WITH SPRING
                  from £1,048.83
                  from £1,048.83
                  # 007
                  MPN: 195167
                  SCREW
                  from £9.38
                  from £9.38
                  This part replaces part number 217654 - and 1 more. Click to view details
                  # 008
                  MPN: 10815787
                  RING CLAMP
                  from £0.54
                  from £0.54
                  # 009
                  MPN: 70003493
                  REAR DUST GAITER KIT
                  from £51.53
                  from £51.53
