0041 - Battery
Ferrari GTC4 Lusso (USA) BATTERY Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot in the parts diagram to locate the part in the table
- You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: 312187
Battery
-95 Ah-
Supersession
Supersession
This part replaces part number 256381
# 002
MPN: 334416
BATTERY MOUNTING
from £185.08
from £185.08
# 003
MPN: 16044321
SCREW
-M8 X 55-
from £0.26
from £0.26
# 003
MPN: 16287024
SCREW
-M8 X 16-
from £0.47
from £0.47
# 004
MPN: 329275
BATTERY RETAINER COMPLETE WITH NEGATIVE TERMINAL
from £50.63
from £50.63
# 005
MPN: 292882
TIE-ROD
from £4.90
from £4.90
# 006
MPN: 228265
NUT
from £0.47
from £0.47
# 007
MPN: 12643724
WASHER
from £0.47
from £0.47
This part replaces part number 109684 - and 4 more. Click to view details
# 008
MPN: 10795206
SPLIT PIN
from £0.47
from £0.47
# 009
MPN: 274661
BATTERY SENSOR
from £75.60
from £75.60
# 010
MPN: 273569
COMPL. BATTERY MASTER SWITCH
- CHASSIS GROUND CABLE -Applicable for GD-
from £25.03
from £25.03
# 010
MPN: 273942
COMPL. BATTERY MASTER SWITCH
- CHASSIS GROUND CABLE -Not for GD-
from £42.83
from £42.83
# 011
MPN: 329276
COMPL. BATTERY ECU
-Applicable until depletion-
Supersession
Supersession
# 011
MPN: 338949
COMPL. BATTERY ECU
-Applicable after depletion of 329276- -Applicable until depletion-
Supersession
Supersession
This part replaces part number 329276
# 011
MPN: 764669
COMPL. BATTERY ECU
-Applicable after depletion of 338949-
from £81.67
from £81.67
This part replaces part number 338949
# 012
MPN: 12646778
WASHER
from £0.53
from £0.53
This part replaces part number 156093
# 013
MPN: 278419
GROUND CABLE FROM SENSOR TO FALSE POLE
from £12.09
from £12.09
# 014
MPN: 251793
HEAT SHIELD
-No longer supplied- -Replaced by 769500-
from £98.67
from £98.67
# 014
MPN: 769500
HEAT SHIELD
from £155.91
from £155.91
