0070 - PEDAL BOARD
Ferrari Purosangue PEDAL BOARD Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: 773369
PEDAL BOARD MOUNT
from £141.56
from £141.56
# 002
MPN: 16287524
SCREW
from £0.86
from £0.86
This part replaces part number 16287521
# 003
MPN: 12601374
WASHER
from £0.54
from £0.54
This part replaces part number 10615474 - and 6 more. Click to view details
# 004
MPN: 912497
IPB UNIT
| Applies until depletion |
from £2,804.49
from £2,804.49
# 004
MPN: 992169
IPB UNIT
| Applicable after depletion of 912497 |
# 005
MPN: 831281
BRAKE PEDAL PIVOT PIN
from £50.01
from £50.01
# 006
MPN: 800483
COMPL. PEDAL BOARD
| Applicable for: GD |
from £641.77
from £641.77
# 006
MPN: 897894
COMPL. PEDAL BOARD
| Not applicable for: GD |
from £500.20
from £500.20
# 007
MPN: 842845
CLIP
from £2.24
from £2.24
# 008
MPN: 12578211
NUT
from £0.53
from £0.53
# 009
MPN: 896903
IPB-PEDAL BOARD FASTENER PIN KIT
from £73.60
from £73.60
# 010
MPN: 240987
DRILLED PLATE
from £83.05
from £83.05
# 011
MPN: 933730
SCREW
from £4.74
from £4.74
# 012
MPN: 12578111
NUT
from £0.53
from £0.53
# 013
MPN: 898168
RSV MANIFOLD KIT
from £167.69
from £167.69
# 014
MPN: 898169
IPB INSTALLATION KIT
from £20.90
from £20.90
