lamborghini lp700-4 coupe (2012) coolant pump parts diagram

121.01.00 - COOLANT PUMP

Lamborghini LP700-4 Coupe (2012) COOLANT PUMP Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                #
                Part number
                Description
                Key
                Price
                # 001
                MPN: 07M121011H
                COOLANT PUMP
                (EUROPE spec vehicles)
                Supersession
                Supersession
                Genuine Lamborghini (no longer available to order)
                # 001
                MPN: 07M121011K
                COOLANT PUMP
                from £2,506.45
                from £2,506.45
                This part replaces part number 07M121011H
                WATER PUMP POMPA ACQUA Genuine Lamborghini - New (to order)
                # 002
                MPN: 07M115120D
                INPUT SHAFT
                Supersession
                Supersession
                Genuine Lamborghini (no longer available to order)
                # 003
                MPN: 07M121071A
                COOLANT HOSE
                from £552.85
                from £552.85
                COOLANT HOSE Genuine Lamborghini - New (to order)
                COOLANT HOSE Genuine Lamborghini - Used In stock
                # 004
                MPN: 07M121139
                SEAL
                from £10.04
                from £10.04
                SEAL Genuine Lamborghini - New In stock
                # 005
                MPN: 07M103181
                SEAL
                from £16.51
                from £16.51
                SEAL Genuine Lamborghini - New In stock
                # 006
                MPN: N10518405
                SOCKET HEAD BOLT WITH MULTI- POINT INNER DRIVE, SELF-LOCK.
                M8X30
                from £1.90
                from £1.90
                TRIPLE SQUARE BOLTM8X30 Genuine Lamborghini - New In stock
                CYLINDER HEAD SCREW WITH TORX Genuine Porsche Part - New (to order)
                # 007
                MPN: N90180902
                O-RING
                50X2
                from £2.75
                from £2.75
                O-RING Genuine Lamborghini - New In stock
                O-RING Genuine Porsche Part - New In stock
                # 008
                MPN: 07M121437
                SEAL RING
                from £33.18
                from £33.18
                SEAL RING Genuine Lamborghini - New (to order)
                # 009
                MPN: 07M103143A
                DOWEL SLEEVE
                from £21.62
                from £21.62
                SLEEVE Genuine Lamborghini - New (to order)
                # 010
                MPN: N10689302
                SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD
                M8X25
                from £1.78
                from £1.78
                12-POINT SOCKET FLANGE BOLT Genuine Lamborghini - New In stock
                BOLT, WITH POLYGON SOCKET HD. Genuine Porsche Part - New (to order)
                # 011
                MPN: N91071701
                HEXAGON SOCKET FLAT HEAD BOLT
                M6X25
                from £0.95
                from £0.95
                SCREW Genuine Lamborghini - New In stock
                HEXAGON SOCKET FLAT Genuine Porsche Part - New (to order)
                # 012
                MPN: 470121069B
                COOLANT HOSE
                from £71.51
                from £71.51
                COOLANT HOSE Genuine Lamborghini - New (to order)
                COOLANT HOSE Genuine Lamborghini - Used In stock
                # 013
                MPN: N90928101
                O-RING
                42X3-N N909281
                from £7.62
                from £7.62
                O-RING Genuine Lamborghini - New (to order)
                # 014
                MPN: N91005902
                HEXAGON SOCKET HEAD BOLT
                M8X25
                from £1.80
                from £1.80
                12-POINT SOCKET Genuine Lamborghini - New In stock
                HEXAGONAL SOCKET HEAD Genuine Porsche Part - New (to order)
                # 015
                -
                COOLANT HOSE
                SEE ILLUSTRATION : 121.03
                # 016
                MPN: N90180902
                O-RING
                50X2
                from £2.75
                from £2.75
                O-RING Genuine Lamborghini - New In stock
                O-RING Genuine Porsche Part - New In stock
