lamborghini lp700-4 coupe (2012) electrics parts diagram

907.01.00 - electrics

Lamborghini LP700-4 Coupe (2012) ELECTRICS Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
              #
              Part number
              Description
              Key
              Price
              # 000
              MPN: 470971302
              1 SET ATTACHMENT PARTS FOR RETAINING BRACKET
              SERVICE FOR COLD JOINT (EUROPE spec vehicles)
              from £17.39
              from £17.39
              SET OF SECURING PARTS Genuine Lamborghini - New (to order)
              # 000
              MPN: 470998161
              REPAIR SET
              L73X-A.04. 16 FROM VIN GLA04224 UNTIL THE VIN GLA04889 (EUROPE spec vehicles)
              from £381.47
              from £381.47
              COLD JOINT KIT Genuine Lamborghini - New (to order)
              Genuine Lamborghini (no longer available to order)
              # 001
              MPN: 7PP907275F
              TYRE PRESSURE SENSOR
              433,92 MHZ - EU - SCANDINAVIA - SWEDEN - GB - SOUTH AFRICA - RUSSIA - ARABIA - DUBAI - BRASIL - SUD KOREA - AUSTRALIA - NEW ZEALAND - PHILIPPINE - USA - CANADA - MEXICO - TAIWAN-433MHZ
              from £56.22
              from £56.22
              TPMS SENSOR STANDARD Genuine Lamborghini - New In stock
              Genuine Porsche Part (no longer available to order)
              TPMS SENSOR STANDARD Genuine Lamborghini - Used In stock
              # 001
              MPN: 7PP907275G
              TYRE PRESSURE SENSOR
              315 MHZ - JAPAN - HONG KONG - SINGAPORE - CHINA-315MHZ (EUROPE spec vehicles)
              from £102.21
              from £102.21
              WHEEL ELECTRONICS US AND JAPAN Genuine Lamborghini - New (to order)
              Genuine Porsche Part (no longer available to order)
              # 002
              MPN: 8E0907277
              aerial
              433,92 MHZ - EU - SCANDINAVIA - SWEDEN - GB - SOUTH AFRICA - RUSSIA - ARABIA - DUBAI - BRASIL - SUD KOREA - AUSTRALIA - NEW ZEALAND - PHILIPPINE - USA - CANADA - MEXICO - TAIWAN-433 MHZ
              from £104.39
              from £104.39
              ANTENNA Genuine Lamborghini - New (to order)
              # 002
              MPN: 8E0907277A
              aerial
              315 MHZ - GIAPPONE - HONG KONG - SINGAPORE - CINA (EUROPE spec vehicles)
              from £103.56
              from £103.56
              ANTENNA Genuine Lamborghini - New (to order)
              # 003
              MPN: 7PP907283
              SENDER UNIT
              from £48.71
              from £48.71
              TRANSMITTING UNIT Genuine Lamborghini - New (to order)
              Genuine Porsche Part (no longer available to order)
              TRANSMITTING UNIT Genuine Lamborghini - Used In stock
              # 004
              MPN: 470907732A
              ARM
              from £656.35
              from £656.35
              HOLDER, ELECTRIC CON Genuine Lamborghini - New (to order)
              HOLDER, ELECTRIC CON Genuine Lamborghini - Used In stock
              # 005
              MPN: 8K0907410
              CONTROL UNIT FOR OPENING GARAGE DOOR
              (EUROPE, UK spec vehicles)
              from £441.35
              from £441.35
              CONTROL UNIT, Genuine Lamborghini - New In stock
              CONTROL UNIT FOR RADIO Genuine Porsche Part - New (to order)
              CONTROL UNIT, Genuine Lamborghini - Used In stock
              # 005
              MPN: 8K0907410C
              CONTROL UNIT FOR OPENING GARAGE DOOR
              (USA spec vehicles)
              from £498.94
              from £498.94
              CONTROL UNIT, Genuine Lamborghini - New In stock
              CONTROL UNIT FOR RADIO Genuine Porsche Part - New (to order)
              # 006
              MPN: 400807777
              BRACKET
              (EUROPE spec vehicles)
              from £12.24
              from £12.24
              BRACKET,GARAGE Genuine Lamborghini - New (to order)
              # 006
              MPN: 470807777
              BRACKET
              from £6.73
              from £6.73
              BRACKET,GARAGE Genuine Lamborghini - New (to order)
              BRACKET,GARAGE Genuine Lamborghini - Used In stock
              # 007
              MPN: 8K0906093E
              CONTROL UNIT FOR FUEL PUMP
              from £120.64
              from £120.64
              CONTROL UNIT, FUEL Genuine Lamborghini - New (to order)
              # 008
              -
              REPAIR KIT FOR SIGNAL HORN
              SEE ILLUSTRATION : 012.01
              # 009
              -
              ELECTRONIC SIREN
              SEE ILLUSTRATION : 012.01
              # 010
              -
              ARM
              SEE ILLUSTRATION : 012.01
              # 011
              MPN: 470971593A
              BRACKET
              LEFT
              from £16.45
              from £16.45
              BRACKET Genuine Lamborghini - New (to order)
              BRACKET Genuine Lamborghini - Used In stock
              # 012
              MPN: 470971592A
              BRACKET
              RIGHT
              from £16.45
              from £16.45
              BRACKET Genuine Lamborghini - New In stock
              BRACKET Genuine Lamborghini - Used In stock
              # 013
              MPN: N10017307
              HEXAGON COLLAR NUT
              M5
              from £1.21
              from £1.21
              HEXAGON FLANGE NUTM5 Genuine Lamborghini - New In stock
              # 014
              MPN: N10612001
              WASHER
              5,3X15X1
              from £0.53
              from £0.53
              WASHER 5.3X15X1 Genuine Lamborghini - New In stock
              # 015
              MPN: 3W0907323
              CLIP
              from £4.86
              from £4.86
              CLIP Genuine Lamborghini - New (to order)
              # 016
              MPN: 470919197
              COUPLING ELEMENT
              (EUROPE spec vehicles)
              Supersession
              Supersession
              Genuine Lamborghini (no longer available to order)
              # 016
              MPN: 470919197B
              COUPLING ELEMENT
              (EUROPE spec vehicles)
              Supersession
              Supersession
              Genuine Lamborghini (no longer available to order)
              # 016
              MPN: 470919197C
              COUPLING ELEMENT
              from £381.47
              from £381.47
              Genuine Lamborghini (no longer available to order)
              Alternative (#470998161) COLD JOINT KIT Genuine Lamborghini - New (to order)
              # 016
              MPN: 470998161
              REPAIR SET
              (EUROPE spec vehicles)
              from £381.47
              from £381.47
              COLD JOINT KIT Genuine Lamborghini - New (to order)
              Genuine Lamborghini (no longer available to order)
              # 017
              MPN: N01100412
              HEXAGON NUT
              M4
              from £0.47
              from £0.47
              HEX.NUT M4 Genuine Lamborghini - New In stock
              6KT-MU M 4 I 4032 8 R645 Genuine Porsche Part - New (to order)
              # 018
              MPN: N01152221
              WASHER
              4,3X9X0,8
              from £0.53
              from £0.53
              This part replaces part number 008400401
              WASHER 4.3X9X0.8 Genuine Lamborghini - New In stock
              # 019
              MPN: N10653201
              HEX COLLARED BOLT
              M6X16
              from £1.13
              from £1.13
              HEXAGON FLANGE M6X16 Genuine Lamborghini - New In stock
              BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
              # 020
              MPN: N10703301
              HEX SOCKET OVAL HEAD COLLARED
              M5X35
              from £1.30
              from £1.30
              HEXALOBULAR SOCKET Genuine Lamborghini - New In stock
              # 021
              MPN: N01508210
              HEXAGON COLLAR NUT
              M6
              from £0.47
              from £0.47
              HEXAGON FLANGE NUT M6 Genuine Lamborghini - New In stock
              Genuine Porsche Part (no longer available to order)
              # 022
              MPN: N10657201
              OVAL HEAD PANEL SCREW
              6,3X16
              from £0.51
              from £0.51
              FILLISTER HEAD ST6.3X16-R Genuine Lamborghini - New In stock
              FILLISTER HEAD ST6.3X16-R Genuine Lamborghini - New (other) In stock
              BOLT
              # 023
              MPN: 410863939
              DAMPING ELEMENT
              from £1.69
              from £1.69
              FOOT SUPPORT PIASTRA POSAPIEDI Genuine Lamborghini - New (to order)
              # 024
              MPN: 470919475
              CONTROL UNIT FOR PARK STEERING ASSIST
              from £100.96
              from £100.96
              CONTROL UNIT,PARK Genuine Lamborghini - New (to order)
              # 025
              MPN: N0115478
              WASHER
              6,5X14X1,6
              from £0.53
              from £0.53
              WASHER Genuine Lamborghini - New In stock
              # 026
              MPN: N10653201
              HEX COLLARED BOLT
              M6X16
              from £1.13
              from £1.13
              HEXAGON FLANGE M6X16 Genuine Lamborghini - New In stock
              BOLT, HEX. HD. WITH SHOULDER Genuine Porsche Part - New (to order)
              # 027
              -
              BRACKET
              FROM MY20
              # 028
              -
              HEX SOCKET OVAL HEAD COLLARED
              FROM MY20
