43.02.00 - Steering
Lamborghini Diablo SV (1999) Steering Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table
- You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: 008400801
WASHER
RONDELLA
Supersession
Supersession
# 002
MPN: 008410810
WASHER
RONDELLA
Supersession
Supersession
# 003
MPN: 008100830
SCREW
VITE
from £0.53
from £0.53
# 004
MPN: 004337924
STRUT
STRUT
from £103.23
from £103.23
# 005
MPN: 008200824
NUT
DADO
from £0.53
from £0.53
# 006
MPN: 410407295
SHIM
SPESSORE Dl REGfSTtO
from £2.73
from £2.73
# 007
MPN: 0043004072
SUPPORT
SUPPORTO
from £272.79
from £272.79
# 007
MPN: 0043005340
SUPPORT
(Valid for GB - July 1999) SUPPORTO
from £286.88
from £286.88
# 007
MPN: 0043005340
SUPPORT
(Valid for AUSTRALIA - July 1999) SUPPORTO
from £286.88
from £286.88
# 008
MPN: 008700830
SCREW
VITE
from £0.53
from £0.53
# 009
MPN: 008410810
WASHER
RONDELLA
Supersession
Supersession
# 010
MPN: 008200801
NUT
DADO
Supersession
Supersession
# 011
MPN: WHT002646
RETAINER RING
ANELLO RITEGNO
from £0.73
from £0.73
# 012
MPN: 008573701
RETAINER RING
ANELLO RITEGNO
from £0.54
from £0.54
# 013
MPN: 008502011
BEARING
CUSCINETTO
from £36.19
from £36.19
# 014
MPN: 0043002199
SMALL SHAFT
ALBERINO
from £84.58
from £84.58
# 015
MPN: 004337941
TOOTHED LOCK STRIK.
TOOTHED MATCH
from £36.15
from £36.15
# 016
MPN: WHT001187
WASHER
RONDELLA
from £0.55
from £0.55
This part replaces part number 008400502
# 017
MPN: 008700522
SCREW
VITE
from £0.53
from £0.53
# 018
MPN: 008502011
BEARING
CUSCINETTO
from £36.19
from £36.19
# 019
MPN: WHT002646
RETAINER RING
ANELLO RITEGNO
from £0.74
from £0.74
# 020
MPN: 0043002200
S. COLUMN SUPPORT
STEERING COLUMN SUPPORT
from £724.64
from £724.64
# 021
MPN: 004338318
PIN
SPINA
from £6.43
from £6.43
# 022
MPN: 004337939
SPACER
DISTANZIALE
from £28.11
from £28.11
# 023
MPN: 004337944
BUSHING
BOCCOLA
from £35.04
from £35.04
# 024
MPN: 008201231
NUT
DADO
from £0.99
from £0.99
# 025
MPN: 410407295D
WASHER
RONDELLA
from £17.99
from £17.99
# 026
MPN: 004337942
PIN
PERNO
from £179.42
from £179.42
# 027
MPN: 008900408
PIN
SPINA
# 028
MPN: 004338065
PIN
SPINA
from £4.64
from £4.64
# 029
MPN: 004338060
POSITION BALL
POSITION SPHERE
from £20.57
from £20.57
# 030
MPN: 004337946
SPACER
DISTANZIALE
from £156.70
from £156.70
# 031
MPN: 004337952
WASHER
RONDELLA
from £31.26
from £31.26
# 032
MPN: 004337947
SPRING
MOLLA
from £7.76
from £7.76
# 033
MPN: 004337948
TOOTHED BUCKET
TOOTHED GLASS
from £90.79
from £90.79
# 034
MPN: 009907111
POSITION BALL
POSITION SPHERE
from £6.76
from £6.76
# 035
MPN: 004338317
LEVER
LEVA
from £452.70
from £452.70
# 036
MPN: 008100824
SCREW
VITE
from £0.93
from £0.93
# 037
MPN: 0043004084
SPRING
MOLLA
from £92.45
from £92.45
# 038
MPN: 008700694
SCREW
VITE
from £0.93
from £0.93
# 039
MPN: 008400606
WASHER
RONDELLA
Supersession
Supersession
# 040
MPN: 009414416
SPRING
MOLLA
from £11.77
from £11.77
