311.01.00 - GEARBOX CONTROL TURRET
Lamborghini Diablo VT (1997) GEARBOX CONTROL TURRET Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot
in the parts diagram to locate the part in the table - You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
-
CASE
NOT FOR THIS MODEL
# 002
-
WASHER
NOT FOR THIS MODEL
# 003
MPN: 008740613
SCREW
from £0.53
from £0.53
# 004
MPN: 008700804
SCREW
from £1.07
from £1.07
# 005
MPN: 008410810
WASHER
Supersession
Supersession
# 006
MPN: 002431785
SHIM
Supersession
Supersession
# 007
MPN: 002433874
PLATE
from £749.42
from £749.42
# 008
-
COVER
NOT FOR THIS MODEL
# 009
MPN: 002432932
ADAPTER
from £49.83
from £49.83
This part replaces part number 002428889
# 010
MPN: 002427202
CYLINDER
from £54.48
from £54.48
# 011
MPN: 002432167
SPRING
from £7.79
from £7.79
# 012
MPN: 002427204
CAP
from £1.02
from £1.02
# 013
MPN: 008572201
RING
from £0.54
from £0.54
# 014
MPN: 002434091
BALL SOCKFT
from £154.46
from £154.46
# 015
MPN: 008410602
WASHER
from £29.19
from £29.19
# 016
MPN: 008700646
SCREW
from £0.53
from £0.53
# 017
MPN: 002433008
GEAR SELECTION LEVER
from £860.26
from £860.26
# 018
MPN: 002429160
SPRING
from £98.35
from £98.35
# 019
MPN: 002430984
UNIVERSAL JOINT
# 020
MPN: 008900305
PIN
from £0.53
from £0.53
# 021
-
RUBBER LINER
NOT FOR THIS MODEL
# 022
-
ROD
NOT FOR THIS MODEL
# 023
MPN: 008201223
NUT
# 024
-
TIE ROD
NOT FOR THIS MODEL
# 025
MPN: 008201224
NUT
# 026
-
ROD
NOT FOR THIS MODEL
# 027
MPN: 002427207
BUSHING
from £206.46
from £206.46
# 028
MPN: 002429161
SHAFT
from £195.38
from £195.38
# 029
-
KNOB
SEE ILLUSTRATION: 863.01
# 030
MPN: 002408637
REVERSE SWITCH
from £75.14
from £75.14
# 031
MPN: 008400801
WASHER
Supersession
Supersession
# 032
MPN: 008410806
WASHER
Supersession
Supersession
# 033
MPN: 008100826
SCREW
from £0.54
from £0.54
# 034
MPN: 006133761
WIRING
from £60.75
from £60.75
# 035
MPN: 002433020
BUSHING
FROM 12526 - COMPATIBLE ONLY WITH 002433018 AND 002433019
from £20.61
from £20.61
# 036
MPN: 240132003
CASE
from £1,048.74
from £1,048.74
# 037
MPN: 002433043
BOOT
from £68.37
from £68.37
# 038
MPN: 002434472
ROD
from £25.04
from £25.04
# 039
-
STUD
NOT FOR THIS MODEL
# 040
-
NUT
NOT FOR THIS MODEL
# 041
-
PLATE
NOT FOR THIS MODEL
# 042
MPN: 002434614
BOOT
# 043
MPN: 008830305
STRAP
Supersession
Supersession
