lamborghini diablo vt (1999) intake manifold parts diagram

133.12.00 - INTAKE MANIFOLD

Lamborghini Diablo VT (1999) INTAKE MANIFOLD Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
    #
    Part number
    Description
    Key
    Price
    # 001
    MPN: 0013001063
    COVER
    RIGHT - FROM ENGINE N. 1889
    from £3,400.47
    from £3,400.47
    *RH FEED MANIFOLD COVER Genuine Lamborghini - New (to order)
    # 002
    MPN: 0013001226
    SPACER
    From engine n. 1889
    from £27.92
    from £27.92
    SHIM Genuine Lamborghini - New (to order)
    # 003
    MPN: 001323717
    GASKET
    From engine n. 1889
    from £33.26
    from £33.26
    INTAKE MANIFOLD COVER GASKET Genuine Lamborghini - New (to order)
    # 004
    MPN: 490132008
    Inlet Manifold
    From engine n. 1889
    from £4,690.51
    from £4,690.51
    PAINT INTAKE MANIFOLD MY98 Genuine Lamborghini - New (to order)
    # 005
    MPN: 008300614
    STUD
    From engine n. 1889
    Supersession
    Supersession
    Genuine Lamborghini (no longer available to order)
    # 006
    MPN: 008400606
    WASHER
    From engine n. 1889
    Supersession
    Supersession
    Genuine Lamborghini (no longer available to order)
    # 007
    MPN: 008200606
    NUT
    From engine n. 1889
    Supersession
    Supersession
    Genuine Lamborghini (no longer available to order)
    # 008
    MPN: 008200605
    NUT
    From engine n. 1889
    from £1.97
    from £1.97
    M6 NCM 70 URAMA SIMMON NUT Genuine Lamborghini - New In stock
    # 009
    MPN: 008300613
    STUD
    From engine n. 1889
    from £3.13
    from £3.13
    STUD M6X14 UNI 5911 8G/Z Genuine Lamborghini - New (to order)
    # 010
    MPN: 0013001062
    COVER
    From engine n. 1889
    from £3,400.47
    from £3,400.47
    LH FEED MANIFOLD COVER Genuine Lamborghini - New (to order)
    # 011
    MPN: 008401621
    WASHER
    From engine n. 1889
    Supersession
    Supersession
    Genuine Lamborghini (no longer available to order)
    # 012
    MPN: 0013001440
    CONNECTION
    From engine n. 1889
    from £7.22
    from £7.22
    EYE TERMINAL Genuine Lamborghini - New (to order)
    # 013
    MPN: 0013001439
    SCREW
    From engine n. 1889
    from £13.56
    from £13.56
    MANIFOLD COVER SCREW Genuine Lamborghini - New (to order)
    # 014
    MPN: 001330455
    CONNECTION
    From engine n. 1889
    from £21.26
    from £21.26
    FAIRLEAD BOLT 5 MM Genuine Lamborghini - New (to order)
    # 015
    MPN: 001326311
    GASKET
    From engine n. 1889
    from £14.12
    from £14.12
    THROTTLE CASING GASKET Genuine Lamborghini - New In stock
    # 016
    MPN: 001326293
    L. THROTTLE HOLDER
    From engine n. 1889
    from £909.44
    from £909.44
    THROTTLE CASING Genuine Lamborghini - New (to order)
    # 017
    MPN: 008201003
    NUT
    From engine n. 1889
    from £2.07
    from £2.07
    10X1.25 SELF-LOCKINGNUT Genuine Lamborghini - New (to order)
    # 018
    MPN: 008401008
    WASHER
    From engine n. 1889
    Supersession
    Supersession
    Genuine Lamborghini (no longer available to order)
    # 019
    MPN: 008301043
    STUD
    From engine n. 1889
    from £3.37
    from £3.37
    STUD Genuine Lamborghini - New (to order)
    # 020
    MPN: 001330882
    CONNECTION
    From engine n. 1889
    Supersession
    Supersession
    Genuine Lamborghini (no longer available to order)
    # 021
    MPN: 001326181
    R. THROTTLE HOLDER
    RIGHT - FROM ENGINE N. 1889
    from £748.49
    from £748.49
    THROTTLE CASING Genuine Lamborghini - New (to order)
    # 022
    MPN: 008850602
    DOWEL
    From engine n. 1889
    Lamborghini PART 008850602 Genuine Lamborghini - New (to order)
    # 023
    MPN: 008300809
    STUD
    From engine n. 1889
    from £4.94
    from £4.94
    STUD M8X25 UNI 5911/8G/ZD Genuine Lamborghini - New (to order)
    # 024
    MPN: 008410810
    WASHER
    From engine n. 1889
    Supersession
    Supersession
    Genuine Lamborghini (no longer available to order)
    # 025
    MPN: 008200808
    NUT
    From engine n. 1889
    Supersession
    Supersession
    Genuine Lamborghini (no longer available to order)
    # 026
    MPN: 001732808
    GASKET
    From engine n. 1889
    from £15.01
    from £15.01
    THERMOSTAT HOUSING COVER SEAL Genuine Lamborghini - New (to order)
    # 027
    MPN: 0017006576
    THERMOSTAT
    from £193.15
    from £193.15
    This part replaces part number 001731206
    WATER THERMOSTAT Genuine Lamborghini - New In stock
    WATER THERMOSTAT Original Equipment - New In stock
    # 028
    MPN: 001732806
    COVER
    From engine n. 1889
    from £378.52
    from £378.52
    THERMOSTAT VALVE COVER Genuine Lamborghini - New In stock
    THERMOSTAT VALVE COVER Genuine Lamborghini - Used In stock
    # 029
    MPN: 008300803
    STUD
    From engine n. 1889
    from £7.71
    from £7.71
    STUD M8X30 UNI 5911/8G/ZD Genuine Lamborghini - New (to order)
    # 030
    MPN: 008200816
    NUT
    From engine n. 1889
    from £2.94
    from £2.94
    SPECIAL NUT Genuine Lamborghini - New In stock
    # 031
    MPN: 001327641
    POTENTIOMETER
    From engine n. 1889
    from £109.79
    from £109.79
    POTENTIOMETER Genuine Lamborghini - New (to order)
