lamborghini diablo vt (1999) wing front parts diagram

821.01.00 - WING FRONT

Lamborghini Diablo VT (1999) WING FRONT Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                          #
                          Part number
                          Description
                          Key
                          Price
                          # 001
                          MPN: 0066002232
                          FENDER
                          LEFT - FRONT (EUROPE, UK spec vehicles)
                          from £4,563.02
                          from £4,563.02
                          WITH SIDE HOLE FOR INDICATOR Genuine Lamborghini - New (to order)
                          # 001
                          MPN: 0066002238
                          FENDER
                          LEFT - FRONT (USA spec vehicles)
                          from £4,563.02
                          from £4,563.02
                          W/OUT SIDE HOLE FOR INDICATOR Genuine Lamborghini - New (to order)
                          # 002
                          MPN: 0066002230
                          FENDER
                          RIGHT - FRONT (USA spec vehicles)
                          from £4,563.02
                          from £4,563.02
                          WITH SIDE HOLE FOR INDICATOR Genuine Lamborghini - New (to order)
                          # 002
                          MPN: 0066002236
                          FENDER
                          RIGHT - FRONT (EUROPE, UK spec vehicles)
                          from £4,563.02
                          from £4,563.02
                          W/OUT SIDE HOLE FOR INDICATOR Genuine Lamborghini - New (to order)
                          # 003
                          MPN: 009430122
                          NET
                          from £63.25
                          from £63.25
                          AIR INTAKE ON BUMPERNET Genuine Lamborghini - New (to order)
                          # 004
                          MPN: 009453002
                          AIR DUCT
                          from £286.56
                          from £286.56
                          FRONT DYNAMIC AIR INTAKE Genuine Lamborghini - New (to order)
                          # 005
                          MPN: 009453129
                          PIPE
                          from £176.25
                          from £176.25
                          DYNAMIC AIR CORRUGATED PIPE Genuine Lamborghini - New (to order)
                          # 006
                          MPN: 009430123
                          NET
                          from £61.55
                          from £61.55
                          AIR VENT NET Genuine Lamborghini - New (to order)
                          # 007
                          MPN: 009453003
                          AIR DUCT
                          from £581.26
                          from £581.26
                          FRONT DYNAMIC AIR INTAKE Genuine Lamborghini - New (to order)
                          # 008
                          MPN: 009453130
                          PIPE
                          from £191.31
                          from £191.31
                          DYNAMIC AIR CORRUGATED PIPE Genuine Lamborghini - New (to order)
                          # 009
                          MPN: 009410109
                          BRAKET
                          RIGHT
                          from £161.42
                          from £161.42
                          FRONT RIGHT FENDER BRACKET Genuine Lamborghini - New (to order)
                          # 010
                          MPN: 009410110
                          BRAKET
                          LEFT
                          from £161.42
                          from £161.42
                          FRONT LEFT FENDER BRACKET Genuine Lamborghini - New (to order)
                          # 011
                          MPN: 009490111
                          GASKET
                          FRONT
                          from £27.92
                          from £27.92
                          BONNET SEAL Genuine Lamborghini - New (to order)
                          # 012
                          MPN: 009490112
                          UNION
                          from £14.94
                          from £14.94
                          BONNET SEAL Genuine Lamborghini - New (to order)
                          # 013
                          MPN: 008700692
                          SCREW
                          from £0.47
                          from £0.47
                          VITE TBEI M6X12 10.9 BRUNITA Genuine Lamborghini - New (to order)
                          # 014
                          MPN: 008400629
                          WASHER
                          from £0.91
                          from £0.91
                          NYLON WASHER 6.4X14X1.2 NFE 27 611 Genuine Lamborghini - New In stock
                          # 015
                          MPN: 008100601
                          SCREW
                          Supersession
                          Supersession
                          Genuine Lamborghini (no longer available to order)
                          # 016
                          MPN: 008100601
                          SCREW
                          Supersession
                          Supersession
                          Genuine Lamborghini (no longer available to order)
                          # 017
                          MPN: 008400606
                          WASHER
                          Supersession
                          Supersession
                          Genuine Lamborghini (no longer available to order)
