lamborghini gallardo coupe (2004) steering gear parts diagram

422.01.00 - STEERING GEAR

Lamborghini Gallardo Coupe (2004) STEERING GEAR Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
                                #
                                Part number
                                Description
                                Key
                                Price
                                # 000
                                -
                                STEERING SYSTEM
                                # 000
                                -
                                STEERING SYSTEM
                                # 000
                                MPN: 0R1400605
                                STEERING SYSTEM
                                ONLY AVAILABLE FOR CAMPAIGN L714-R01.12- LHD (EUROPE, USA spec vehicles)
                                from £1,278.02
                                from £1,278.02
                                KIT 1 POWER STEERING UPDATE Genuine Lamborghini - New (to order)
                                # 000
                                MPN: 0R1400606
                                STEERING SYSTEM
                                ONLY AVAILABLE FOR CAMPAIGN L714-R02.12- RHD (UK spec vehicles)
                                from £1,370.40
                                from £1,370.40
                                KIT 2 POWER STEERING UPDATE Genuine Lamborghini - New (to order)
                                # 001
                                MPN: 400422857A
                                RETURN HOSE
                                OIL RETURN
                                from £374.74
                                from £374.74
                                RETURN HOSE Genuine Lamborghini - New (to order)
                                RETURN HOSE Genuine Lamborghini - Used In stock
                                # 002
                                MPN: 400422973
                                EXPANSION HOSE
                                OIL FLOW
                                from £149.33
                                from £149.33
                                PRESSURE LINE Genuine Lamborghini - New (to order)
                                PRESSURE LINE Genuine Lamborghini - Used In stock
                                # 002
                                MPN: 401422893E
                                EXPANSION HOSE
                                OIL FOW - ALSO ORDER THE CODE 400422973- LHD (EUROPE, USA spec vehicles)
                                from £587.10
                                from £587.10
                                HOSE Genuine Lamborghini - New (to order)
                                # 002
                                MPN: 402422893J
                                EXPANSION HOSE
                                OIL FLOW - ALSO ORDER THE CODE 402422973- RHD (UK spec vehicles)
                                from £326.71
                                from £326.71
                                TUBO FLESSIBILE Genuine Lamborghini - New (to order)
                                TUBO FLESSIBILE Genuine Lamborghini - Used In stock
                                # 003
                                MPN: 400422269A
                                BANJO BOLT
                                from £11.76
                                from £11.76
                                This part replaces part number 005124347
                                HOLLOW SCREW Genuine Lamborghini - New (to order)
                                # 004
                                MPN: 400422383A
                                SEAL RING
                                from £4.85
                                from £4.85
                                SEAL RING Genuine Lamborghini - New (to order)
                                # 005
                                MPN: 400422859A
                                RETURN PIPE
                                from £42.04
                                from £42.04
                                UNION Genuine Lamborghini - New (to order)
                                UNION Genuine Lamborghini - Used In stock
                                # 006
                                MPN: 400422373
                                OIL CONTAINER
                                from £506.46
                                from £506.46
                                OIL TANK,STEERING Genuine Lamborghini - New (to order)
                                OIL TANK,STEERING Genuine Lamborghini - Used In stock
                                # 008
                                MPN: 008100826
                                HEXAGON BOLT
                                M8X16
                                from £0.53
                                from £0.53
                                SCREW M8X16 UNI 5739/8G/Z Genuine Lamborghini - New (to order)
                                # 009
                                MPN: 400422493A
                                BRACKET FOR FLUID RESERVOIR
                                from £11.20
                                from £11.20
                                POWER STEERING OIL TANK SUPPOR Genuine Lamborghini - New (to order)
                                POWER STEERING OIL TANK SUPPOR Genuine Lamborghini - Used In stock
                                # 010
                                MPN: N0902322
                                HEXAGON HEAD BOLT (COMBI)
                                M6X10
                                from £0.53
                                from £0.53
                                SCREW M6X10 Genuine Lamborghini - New In stock
                                # 011
                                MPN: N10124303
                                OVAL HEXAGON SOCKET HEAD BOLT
                                M6X20
                                Supersession
                                Supersession
                                Genuine Lamborghini (no longer available to order)
                                # 012
                                MPN: 400422279A
                                BANJO BOLT
                                from £6.91
                                from £6.91
                                PIPE UNION Genuine Lamborghini - New In stock
                                # 013
                                MPN: N0138481
                                SEAL RING
                                16X22
                                from £0.53
                                from £0.53
                                This part replaces part number 008401621
                                WASHER Genuine Lamborghini - New In stock
                                seal ring - A 16 X 22 (N 0138481) Genuine Porsche Part - New (to order)
                                # 014
                                MPN: 400422843
                                CONNECTION PIECE
                                from £141.81
                                from £141.81
                                UNION FROM FLEXIBLE HOSE TO PUMP Genuine Lamborghini - New In stock
                                # 015
                                MPN: 400145153C
                                HYDRAULIC PUMP
                                BEFORE ENGINE 07L00208 USE ALSO 07L109359G
                                from £886.26
                                from £886.26
                                VANE TYPE PUMP Genuine Lamborghini - New (to order)
                                # 016
                                MPN: N0245107
                                CLAMP
                                16-25X9X0,5
                                from £3.07
                                from £3.07
                                This part replaces part number N10257901
                                HOSE CLIP Genuine Lamborghini - New (to order)
                                # 017
                                MPN: 400422891
                                RETURN HOSE
                                from £141.81
                                from £141.81
                                RETURN HOSE Genuine Lamborghini - New (to order)
                                # 018
                                MPN: 400611799B
                                BRACKET
                                from £0.54
                                from £0.54
                                SUPPORT, HOSE Genuine Lamborghini - New In stock
                                # 019
                                MPN: 400422891A
                                INTAKE HOSE
                                from £33.29
                                from £33.29
                                HOSE TO MULTIPLE MANIFOLD Genuine Lamborghini - New (to order)
                                HOSE TO MULTIPLE MANIFOLD Genuine Lamborghini - Used In stock
                                # 020
                                MPN: N0206103
                                CLAMP
                                26X15
                                from £4.20
                                from £4.20
                                HOLDING CLIP D1- 26.0X15 Genuine Lamborghini - New (to order)
                                # 021
                                MPN: N90847901
                                HEX COLLARED BOLT
                                M6X15
                                Supersession
                                Supersession
                                Genuine Lamborghini (no longer available to order)
                                # 022
                                MPN: 400422887
                                OIL HOSE
                                from £212.71
                                from £212.71
                                RUBBER PIPE FROM OIL TANK TO PUMP Genuine Lamborghini - New (to order)
                                # 023
                                MPN: 400422293B
                                CONNECTOR UNION
                                from £28.76
                                from £28.76
                                HOSE CONNECTION Genuine Lamborghini - New (to order)
                                # 025
                                -
                                INPUT SHAFT
                                # 025
                                MPN: 057145225D
                                INPUT SHAFT
                                from £34.32
                                from £34.32
                                DRIVE SHAFT Genuine Lamborghini - New (to order)
                                # 026
                                -
                                STOP BUFFER
                                # 026
                                MPN: 079145115B
                                STOP BUFFER
                                from £7.53
                                from £7.53
                                PUFFER Genuine Lamborghini - New (to order)
                                # 027
                                MPN: N0245107
                                CLAMP
                                16-25X9X0,5
                                from £3.07
                                from £3.07
                                This part replaces part number N10257901
                                HOSE CLIP Genuine Lamborghini - New (to order)
                                # 028
                                MPN: WHT000417
                                SEAL RING
                                16,6X2,6
                                from £1.65
                                from £1.65
                                This part replaces part number N0282112 - and 1 more. Click to view details
                                SEALING WASHER Genuine Lamborghini - New In stock
                                # 029
                                MPN: 400611757
                                BRACKET
                                from £1.41
                                from £1.41
                                PIN Genuine Lamborghini - New In stock
                                # 030
                                MPN: 400611799C
                                BRACKET
                                16
                                from £0.62
                                from £0.62
                                SUPPORT, HOSE Genuine Lamborghini - New (to order)
