lamborghini gallardo coupe (2008) brake pedal parts diagram

721.05.00 - BRAKE PEDAL

Lamborghini Gallardo Coupe (2008) BRAKE PEDAL Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Key
Price
# 001
MPN: 400721363A
SPRING
E-GEAR (EUROPE spec vehicles)
from £12.32
from £12.32
TENSION SPRING Genuine Lamborghini - New (to order)
# 002
MPN: 400721389
BUSH
(EUROPE spec vehicles)
from £20.61
from £20.61
BUSH Genuine Lamborghini - New (to order)
# 003
MPN: N0124402
RETAINING WASHER
12 (EUROPE spec vehicles)
from £0.53
from £0.53
LOCK WASHER Genuine Lamborghini - New (to order)
# 004
MPN: N91024201
PIN
14H7X52X.47 (EUROPE spec vehicles)
from £10.38
from £10.38
SHAFT FOR SERVOBRAKE LEVER 14H7X37X32 Genuine Lamborghini - New (to order)
# 005
MPN: 401721313B
LEVER
FOR LHD CARS- LHD (EUROPE spec vehicles)
from £202.79
from £202.79
BRAKEBOOSTER LEVER WELD. ASSEMBLY Genuine Lamborghini - New (to order)
BRAKEBOOSTER LEVER WELD. ASSEMBLY Genuine Lamborghini - Used In stock
# 006
MPN: N90833202
HEXAGON BOLT
M6X22 (EUROPE spec vehicles)
from £0.54
from £0.54
DUO HEXAGON FLANGEM6X22 Genuine Lamborghini - New (to order)
DUO HEXAGON FLANGEM6X22 Genuine Lamborghini - New (other) In stock
BOLT
# 007
MPN: N01100636
HEXAGON NUT
M6 (EUROPE spec vehicles)
from £1.06
from £1.06
This part replaces part number N01100625
HEX.NUT Genuine Lamborghini - New (to order)
HEX. NUT Genuine Porsche Part - New (to order)
# 008
MPN: N0110051
HEXAGON NUT
M5 (EUROPE spec vehicles)
from £5.03
from £5.03
HEX.NUT Genuine Lamborghini - New (to order)
# 009
MPN: N10579401
HEXAGON BOLT
M5X40 (EUROPE spec vehicles)
from £1.88
from £1.88
HEX.HD. SCREW Genuine Lamborghini - New In stock
# 010
MPN: 401721141B
BRAKE PEDAL
LHD - AUTOMATIC GEARBOX- LHD (EUROPE spec vehicles)
from £346.75
from £346.75
BRAKE PEDAL, COMPLETE Genuine Lamborghini - New (to order)
BRAKE PEDAL, COMPLETE Genuine Lamborghini - Used In stock
# 011
MPN: 400723323
ADJUSTMENT PART
(EUROPE spec vehicles)
from £82.11
from £82.11
ADJUSTMENT PART Genuine Lamborghini - New (to order)
ADJUSTMENT PART Genuine Lamborghini - Used In stock
# 012
MPN: N0126481
RETAINING WASHER
8 (EUROPE spec vehicles)
from £0.53
from £0.53
LOCK WASHER Genuine Lamborghini - New In stock
# 017
MPN: N91024101
PIN
10G8X25X18 (EUROPE spec vehicles)
from £41.47
from £41.47
PIN 10H7X23X19 Genuine Lamborghini - New (to order)
PIN 10H7X23X19 Genuine Lamborghini - Used In stock
# 018
MPN: 400721174D
CAP FOR FOOT BRAKE PEDAL
E-GEAR (EUROPE spec vehicles)
from £14.83
from £14.83
PEDAL PAD Genuine Lamborghini - New (to order)
PEDAL PAD Genuine Lamborghini - Used In stock
# 019
MPN: 400721780A
COVER
(EUROPE spec vehicles)
from £101.15
from £101.15
COVER Genuine Lamborghini - New (to order)
COVER Genuine Lamborghini - Used In stock
