lamborghini gallardo spyder (2006) steering gear rhd parts diagram

422.47.40 - STEERING GEAR RHD

Lamborghini Gallardo Spyder (2006) STEERING GEAR RHD Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
#
Part number
Description
Key
Price
# 001
MPN: 400422883
CONNECTION PIECE
UNTIL THE VIN 6LA3976 (UK spec vehicles)
from £36.75
from £36.75
SCREW NECK Genuine Lamborghini - New (to order)
# 002
MPN: N0138481
SEAL RING
16X22 (UK spec vehicles)
from £0.54
from £0.54
This part replaces part number 008401621
WASHER Genuine Lamborghini - New In stock
seal ring - A 16 X 22 (N 0138481) Genuine Porsche Part - New (to order)
# 003
MPN: 400251189B
CLAMP
(UK spec vehicles)
from £6.53
from £6.53
CLAMP Genuine Lamborghini - New (to order)
# 004
MPN: N90967701
TORX SOCKET HEAD BOLT
UNTIL THE VIN 6LA3976-M5X35 (UK spec vehicles)
from £0.61
from £0.61
CHEESE HEAD SCREW Genuine Lamborghini - New (to order)
Torx (N 90967701) Genuine Porsche Part - New (to order)
# 005
MPN: 400422346A
ADAPTER
UNTIL THE VIN 6LA3976 (UK spec vehicles)
from £31.20
from £31.20
ADAPTER Genuine Lamborghini - New In stock
ADAPTER Genuine Lamborghini - Used In stock
# 006
MPN: 086317171A
CLAMP
(UK spec vehicles)
from £1.69
from £1.69
CLAMP Genuine Lamborghini - New In stock
# 007
MPN: 402422857
oil pressure line
UNTIL THE VIN 6LA3976 (UK spec vehicles)
from £78.95
from £78.95
FEED PIPE Genuine Lamborghini - New (to order)
# 008
MPN: 402422869B
SUPPLY PIPE
(UK spec vehicles)
from £368.35
from £368.35
FEED PIPE Genuine Lamborghini - New (to order)
# 009
MPN: 400422095
GROMMET
18X25X3 (UK spec vehicles)
from £29.53
from £29.53
GROMMET Genuine Lamborghini - New (to order)
# 010
MPN: 3W0971838
CABLE TIES
4,6X193MM 6,5/0,3-3,0MM (UK spec vehicles)
from £0.79
from £0.79
CABLE TIE BASE 6.50X200 Genuine Lamborghini - New (to order)
# 011
MPN: 400422886
OIL COOLER
(UK spec vehicles)
from £95.83
from £95.83
Genuine Lamborghini (no longer available to order)
OIL COOLER Genuine Lamborghini - Used In stock
# 012
MPN: 400422871A
BRACKET
(UK spec vehicles)
from £10.37
from £10.37
BRACKET Genuine Lamborghini - New (to order)
BRACKET Genuine Lamborghini - Used In stock
# 013
MPN: N0206026
CLAMP
15X15 (UK spec vehicles)
from £1.21
from £1.21
HOLDING CLIP Genuine Lamborghini - New In stock
# 014
MPN: N10544301
SOCKET HEAD BOLT
M5X25 (UK spec vehicles)
from £0.53
from £0.53
CYL.SCREW Genuine Lamborghini - New (to order)
# 016
MPN: 400422381
PRESSURE SPRING
(UK spec vehicles)
from £1.80
from £1.80
This part replaces part number 0062002430
STAINLESS STEEL SPRING 9X11X10 0 MM Genuine Lamborghini - New (to order)
