103.06.00 - IMPULSE SENDER
Lamborghini LP550-2 Coupe (2014) IMPULSE SENDER Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot in the parts diagram to locate the part in the table
- You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: 06D103377
WASHER
from £3.55
from £3.55
# 002
-
DOWEL PIN
# 003
MPN: 07L109257
CONTROL VALVE
from £86.90
from £86.90
# 004
MPN: N91068201
HEXAGON SOCKET FLAT HEAD BOLT
M4X10
from £0.47
from £0.47
# 005
MPN: N91127602
HEXAGON SOCKET FLAT HEAD BOLT
M6X35X16
from £1.04
from £1.04
# 006
MPN: N10196103
OVAL SOCKET HEAD BOLT WITH HEX DRIVE
M6X18
from £0.78
from £0.78
# 007
MPN: 07L905163C
IMPULSE SENDER
from £53.09
from £53.09
# 008
MPN: 07L109291
BUNGS
from £7.26
from £7.26
# 009
-
BUNGS
# 010
MPN: 06E103175C
NON-RETURN VALVE
from £23.78
from £23.78
This part replaces part number 06E103175B
# 011
MPN: 026103113
END CAP
from £2.18
from £2.18
# 012
MPN: N0145555
THREADED PIN
M8X44
from £1.99
from £1.99
# 013
MPN: N0119078
END CAP
14
from £0.61
from £0.61
# 014
MPN: N0294542
SEALING PLUG
M10X1
from £0.84
from £0.84
# 015
MPN: 06B103113C
END CAP
26
from £4.88
from £4.88
# 016
MPN: 420199455
GUARD PLATE
LEFT
from £53.62
from £53.62
# 017
-
SEAL
# 018
-
DUMMY COVER
# 019
-
HEX COLLARED BOLT
# 020
-
COMPLETE CYLINDER HEAD
# 021
MPN: N90780901
OVAL HEXAGON SOCKET HEAD BOLT
M6X16
from £0.53
from £0.53
