325.01.00 - FLANGED SHAFT WITH BEARING
Lamborghini Evo Spyder (2020) FLANGED SHAFT WITH BEARING Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot in the parts diagram to locate the part in the table
- You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: 0BZ525357
FLANGED SHAFT
LEFT
from £582.77
from £582.77
# 002
MPN: 4T0398003
1 SET OF SELF-LOCKING SCREWS
M10X30
from £52.23
from £52.23
# 003
MPN: N10745301
OVAL HEXAGON SOCKET HEAD BOLT
M8X30
from £1.75
from £1.75
# 004
MPN: 4T0300029
cover for axle differential
from £748.78
from £748.78
# 005
MPN: 0BZ301131A
O-RING
228X3,5
from £10.24
from £10.24
# 006
MPN: 01S409086
RADIAL SHAFT SEAL
40-54-7/11
from £41.03
from £41.03
# 007
MPN: 4T0301193
SEAL RING
from £19.63
from £19.63
# 008
MPN: 01E311235
GROOVED BALL BEARING
35X62X14
from £53.62
from £53.62
# 009
MPN: 4T0301193
SEAL RING
from £19.63
from £19.63
# 010
-
AUTOMATIC GEARBOX
# 011
MPN: 01J409179D
cover for axle differential
from £81.80
from £81.80
# 012
MPN: 016409399B
RADIAL SHAFT SEAL
45X60X8
from £17.12
from £17.12
# 013
-
GUARD PLATE
# 014
MPN: 0BZ525356
FLANGED SHAFT
RIGHT
from £437.52
from £437.52
# 015
MPN: 01J323863
O-RING
from £4.06
from £4.06
# 016
MPN: 4T0301193A
SEAL RING
# 017
MPN: 4T0525077
PINION AND CROWN WHEEL
from £217.89
from £217.89
# 018
MPN: 4T0525077A
PINION AND CROWN WHEEL
from £101.16
from £101.16
