955.02.00 - HEADLIGHT WASHER SYSTEM
Lamborghini Evo Spyder (2020) HEADLIGHT WASHER SYSTEM Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot in the parts diagram to locate the part in the table
- You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: 4T1955970
WIRING HARNESS FOR HEADLIGHT WASHER SYSTEM
LHD (EUROPE, USA spec vehicles)
from £42.11
from £42.11
# 001
MPN: 4T2955970
WIRING HARNESS FOR HEADLIGHT WASHER SYSTEM
RHD (UK spec vehicles)
from £42.85
from £42.85
# 002
MPN: 4T0955964A
PIPE
from £50.94
from £50.94
# 003
-
INJECTOR UNIT FOR HEADLIGHT CLEANING
# 004
MPN: 5M0955985C
WATER JET
from £2.95
from £2.95
# 004
MPN: 5M0955986C
SPRAY NOZZLE, HEATED
HEATED
Supersession
Supersession
# 005
-
PIPE
# 006
MPN: 4T0955972A
CORRUGATED PIPE
from £13.98
from £13.98
# 007
MPN: 4T1955449B
CONTAINER FOR CLEANING MATERIAL
LHD (EUROPE, USA spec vehicles)
from £59.32
from £59.32
# 007
MPN: 4T2955449B
CONTAINER FOR CLEANING MATERIAL
RHD (UK spec vehicles)
from £32.63
from £32.63
# 008
MPN: 4T1955945A
CONTAINER FOR CLEANING MATERIAL
LHD (EUROPE, USA spec vehicles)
from £28.68
from £28.68
# 008
MPN: 4T2955945A
CONTAINER FOR CLEANING MATERIAL
RHD (UK spec vehicles)
from £28.68
from £28.68
# 009
MPN: 420955997
GROMMET
from £1.98
from £1.98
# 010
-
CLAMP
# 011
-
TERMINAL
# 012
MPN: 3D0971838K
CABLE TIES
from £0.80
from £0.80
# 013
MPN: 7L5971847B
CABLE TIE WITH TERMINAL SOCKET
from £1.90
from £1.90
# 014
MPN: N91173301
HEX. NUT WITH WASHER
from £1.47
from £1.47
# 015
-
COVER
# 016
-
HEXAGON SOCKET HEAD PANEL BOLT
# 017
MPN: N91042302
OVAL HEXAGON SOCKET HEAD BOLT
M6X16
from £0.63
from £0.63
# 018
MPN: 4T0955193
SEAL
from £3.07
from £3.07
