121.09.00 - COOLER FOR COOLANT
Lamborghini Evo Spyder 2WD (2020) COOLER FOR COOLANT Parts Diagram
View the exploded parts diagram to find the part you are looking for
- You can reposition the diagram by dragging it
- You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
- You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
- You can click on a hotspot in the parts diagram to locate the part in the table
- You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
# 001
MPN: 4S0121252B
ADDITIONAL COOLER FOR COOLANT
LEFT A. RIGHT
from £242.10
from £242.10
# 002
MPN: 4S0121203C
RADIATOR FAN WITH FAN RING
400W
from £557.70
from £557.70
This part replaces part number 4S0121203B
# 003
MPN: 4T0809963
AIR GUIDE
LEFT
from £28.19
from £28.19
# 003
MPN: 4T0809964
AIR GUIDE
RIGHT
from £28.19
from £28.19
# 004
MPN: 4T0807167
AIR GUIDE
LEFT
from £8.13
from £8.13
# 004
MPN: 4T0807168
AIR GUIDE
RIGHT
from £8.13
from £8.13
# 005
MPN: 4T0807161C
AIR GUIDE
LEFT
from £17.34
from £17.34
# 005
MPN: 4T0807162C
AIR GUIDE
RIGHT
from £18.51
from £18.51
# 006
MPN: 4T0807157F
AIR GUIDE
LEFT
from £152.18
from £152.18
# 007
MPN: 4T0815533
BRACKET
from £27.20
from £27.20
# 008
MPN: 4S0121259C
BRACKET
LEFT
from £116.60
from £116.60
# 008
MPN: 4S0121260C
BRACKET
RIGHT
from £77.73
from £77.73
# 009
MPN: 4T0805289
BRACKET
from £22.48
from £22.48
# 010
MPN: N90918702
HEXAGON SOCKET HEAD PANEL BOLT
4X12
from £0.50
from £0.50
# 011
MPN: N10664901
SOCKET HEAD COLLARED BOLT WITH INNER MULTIPOINT HEAD
M8X16
from £1.69
from £1.69
# 012
MPN: N90342503
SPEED NUT
M6X19,5X18
from £0.98
from £0.98
# 013
MPN: N91073301
HEXAGON SOCKET FLAT HEAD BOLT
M6X12
from £0.50
from £0.50
# 014
MPN: N91136801
HEXAGON SOCKET HEAD PANEL BOLT
4,2X11
from £0.53
from £0.53
# 015
MPN: N91057001
OVAL HEAD PANEL SCREW
5X16
from £0.50
from £0.50
# 016
MPN: N91042302
OVAL HEXAGON SOCKET HEAD BOLT
M6X16
from £0.63
from £0.63
# 017
MPN: 420121275A
RUBBER BUSH
from £3.85
from £3.85
# 018
MPN: 4S0121275
RUBBER BUSH
CENTRE INNER
from £6.45
from £6.45
# 019
MPN: N0154487
SPEED NUT
INCLUDED IN REF.7-4,2X16,3X11
from £0.66
from £0.66
# 020
MPN: N0902772
HEX. HD. SELF-TAP BOLT (COMBI)
from £0.98
from £0.98
# 021
MPN: 701867299E
CLIP
from £0.52
from £0.52
# 022
MPN: 420955997
GROMMET
from £1.98
from £1.98
# 023
MPN: 4T0807158F
AIR GUIDE
RIGHT
from £152.18
from £152.18
