lamborghini lp580-2 coupe (2018) aerial parts diagram

035.02.00 - aerial

Lamborghini LP580-2 COUPE (2018) AERIAL Parts Diagram

View the exploded parts diagram to find the part you are looking for
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using theandbuttons
  • You can reset the diagram using thebutton
View all the part pricing and availability information on the parts table to the rightbelow
  • You can click on a hotspot in the parts diagram to locate the part in the table
  • You can use the options filter, in the filter tab, to hide parts not relevant to your search
Switch between other part diagrams using theandbuttons, or use the diagram images below
We recommend viewing this page in landscape orientation for the best experience
Part Key
ST
Part in stock
PS
Available in a part set
SS
Part supersession in stock
PS
Available in a part set to order (subject to availability)
SO
Part available to order (subject to availability)
PK
Available in a part kit
            #
            Part number
            Description
            Price
            # 001
            MPN: 4G0907410
            CONTROL UNIT FOR OPENING GARAGE DOOR
            (EUROPE, UK spec vehicles)
            from £475.56
            from £475.56
            # 001
            MPN: 4G0907410A
            CONTROL UNIT FOR OPENING GARAGE DOOR
            (USA spec vehicles)
            from £864.65
            from £864.65
            # 002
            MPN: 470807777
            BRACKET
            from £6.59
            from £6.59
            # 003
            MPN: N10657201
            OVAL HEAD PANEL SCREW
            6,3X16
            from £0.51
            from £0.51
            # 004
            MPN: 4S0035225A
            AERIAL AMPLIFIER
            FM-WINDSCREEN FRAME RIGHT (EUROPE, UK spec vehicles)
            from £59.23
            from £59.23
            # 004
            MPN: 4S0035225D
            AERIAL AMPLIFIER
            FM/DAB-WINDSCREEN FRAME RIGHT
            from £32.58
            from £32.58
            # 004
            MPN: 4S0035225G
            AERIAL AMPLIFIER
            FZV-WINDSCREEN FRAME LEFT
            from £32.58
            from £32.58
            # 005
            MPN: 4S0035503A
            -SDARS- AERIAL
            NAR (USA spec vehicles)
            from £269.77
            from £269.77
            # 006
            -
            ARM
            # 006
            -
            ARM
            # 007
            MPN: 4S0035225
            AERIAL AMPLIFIER
            AM/FM-REAR
            from £66.10
            from £66.10
            # 008
            -
            BRACKET
            # 009
            MPN: 4T8035507A
            aerial
            FM
            from £102.03
            from £102.03
            # 010
            MPN: 8F0919889
            aerial
            GPS-'GPS'
            from £32.53
            from £32.53
            # 011
            MPN: 4T0971650
            CONNECTION CABLE
            LHD (EUROPE, USA spec vehicles)
            from £22.85
            from £22.85
            # 011
            MPN: 4T2971650
            CONNECTION CABLE
            RHD (UK spec vehicles)
            from £24.26
            from £24.26
            # 012
            -
            aerial
            # 013
            -
            SENSOR FOR RAIN AND LIGHT RECOGNITION
            # 014
            MPN: 7L6937545
            BRACKET FOR CONNECTOR HOUSING
            1 POINT
            from £1.57
            from £1.57
            # 015
            MPN: 1J0906029A
            BRACKET FOR CONNECTOR HOUSING
            6R0 973 735 1J0 973 835
            from £4.28
            from £4.28
            # 016
            -
            AERIAL AMPLIFIER
            # 017
            -
            BRACKET
            # 018
            -
            FLAT ROUND HEAD BOLT
            # 019
            MPN: 8S7035503B
            aerial
            from £34.10
            from £34.10
            # 020
            -
            SOUND ABSORBER PIECE
            # 021
            MPN: 3D0971838L
            CABLE TIE WITH TERMINAL SOCKET
            4,6X200MM
            from £1.90
            from £1.90
            # 022
            MPN: N10009506
            HEXAGON HEAD BOLT (COMBI)
            from £0.59
            from £0.59
            # 023
            MPN: 1K0937545M
            BRACKET FOR CONNECTOR HOUSING
            from £1.70
            from £1.70
            # 024
            MPN: N10017307
            HEXAGON COLLAR NUT
            from £1.23
            from £1.23
            # 025
            MPN: 3W0971838
            CABLE TIES
            4,6X193MM 6,5/0,3-3,0MM
            from £0.79
            from £0.79
